brainsurface.h File Reference

Renderable cortical / BEM mesh with interleaved vertex attributes and Qt-RHI buffer management. More...

#include "../disp3D_global.h"
#include "../core/rendertypes.h"
#include <QVector>
#include <QVector3D>
#include <QColor>
#include <memory>
#include <vector>
#include <fs/fs_surface.h>
#include <fs/fs_annotation.h>
#include <mne/mne_bem.h>
#include <Eigen/Core>

Include dependency graph for brainsurface.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	VertexData
	Interleaved vertex attributes (position, normal, color, curvature) for brain surface GPU upload. More...
class	BrainSurface
	Renderable cortical surface mesh with per-vertex color, curvature data, and GPU buffer management. More...

Detailed Description

Renderable cortical / BEM mesh with interleaved vertex attributes and Qt-RHI buffer management.

SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2026 MNE-CPP Authors

Author

Christoph Dinh chris.nosp@m.toph.nosp@m..dinh.nosp@m.@mne.nosp@m.-cpp..nosp@m.org

Since

2.0.0

Date

March 2026

BrainSurface is the core 3-D primitive of disp3D. It owns the interleaved VertexData stream (position, normal, packed-ABGR base / annotation colour, surface-id) and the matching index buffer, plus the QRhi vertex / index buffer pair that the renderer binds for every draw.

Per-vertex colour is computed once on the CPU from one of four sources selected by VisualizationMode — flat base colour, FsAnnotation parcellation, scientific curvature shading (Lambertian ambient + sulcal darkening), or a source-time-course value mapped through the active colormap — then packed into the second colour slot so a single fragment shader covers every mode by blending the two colour streams.

The class accepts geometry from a FSLIB::FsSurface, an MNELIB::MNEBemSurface or raw Eigen matrices, and can carry a TissueType tag so the renderer knows whether the mesh is a cortex, skin, skull or generic shell for alpha / lighting tuning.

Definition in file brainsurface.h.
