FIFF tag-kind, block-kind and type-code numerical definitions, authoritative for FIFFLIB. More...
Go to the source code of this file.
Variables | |
| constexpr auto | FIFFC_MAJOR_VERSION = 1L |
| constexpr auto | FIFFC_MINOR_VERSION = 3L |
| constexpr auto | FIFFT_VOID = 0 |
| constexpr auto | FIFFT_BYTE = 1 |
| constexpr auto | FIFFT_SHORT = 2 |
| constexpr auto | FIFFT_INT = 3 |
| constexpr auto | FIFFT_FLOAT = 4 |
| constexpr auto | FIFFT_DOUBLE = 5 |
| constexpr auto | FIFFT_JULIAN = 6 |
| constexpr auto | FIFFT_USHORT = 7 |
| constexpr auto | FIFFT_UINT = 8 |
| constexpr auto | FIFFT_ULONG = 9 |
| constexpr auto | FIFFT_STRING = 10 |
| constexpr auto | FIFFT_ASCII = 10 |
| constexpr auto | FIFFT_LONG = 11 |
| constexpr auto | FIFFT_DAU_PACK13 = 13 |
| constexpr auto | FIFFT_DAU_PACK14 = 14 |
| constexpr auto | FIFFT_DAU_PACK16 = 16 |
| constexpr auto | FIFFT_COMPLEX_FLOAT = 20 |
| constexpr auto | FIFFT_COMPLEX_DOUBLE = 21 |
| constexpr auto | FIFFT_OLD_PACK = 23 |
| constexpr auto | FIFFT_CH_INFO_STRUCT = 30 |
| constexpr auto | FIFFT_ID_STRUCT = 31 |
| constexpr auto | FIFFT_DIR_ENTRY_STRUCT = 32 |
| constexpr auto | FIFFT_DIG_POINT_STRUCT = 33 |
| constexpr auto | FIFFT_CH_POS_STRUCT = 34 |
| constexpr auto | FIFFT_COORD_TRANS_STRUCT = 35 |
| constexpr auto | FIFFT_DIG_STRING_STRUCT = 36 |
| constexpr auto | FIFFT_STREAM_SEGMENT_STRUCT = 37 |
| constexpr auto | FIFFT_DATA_REF_STRUCT = 38 |
| constexpr auto | FIFFC_MATRIX_MAX_DIM = 9 |
| constexpr auto | FIFFTS_FS_MASK = 0xFF000000 |
| constexpr auto | FIFFTS_BASE_MASK = 0x00000FFF |
| constexpr auto | FIFFTS_MC_MASK = 0x00FF0000 |
| constexpr auto | FIFFTS_FS_SCALAR = 0x00000000 |
| constexpr auto | FIFFTS_FS_MATRIX = 0x40000000 |
| constexpr auto | FIFFTS_MC_DENSE = 0x00000000 |
| constexpr auto | FIFFTS_MC_CCS = 0x00100000 |
| constexpr auto | FIFFTS_MC_RCS = 0x00200000 |
| constexpr auto | FIFF_NEW_FILE = 1 |
| constexpr auto | FIFF_CLOSE_FILE = 2 |
| constexpr auto | FIFF_DISCARD_FILE = 3 |
| constexpr auto | FIFF_ERROR_MESSAGE = 4 |
| constexpr auto | FIFF_SUSPEND_READING = 5 |
| constexpr auto | FIFF_FATAL_ERROR_MESSAGE = 6 |
| constexpr auto | FIFF_CONNECTION_CHECK = 7 |
| constexpr auto | FIFF_SUSPEND_FILING = 8 |
| constexpr auto | FIFF_RESUME_FILING = 9 |
| constexpr auto | FIFF_RAW_PREBASE = 10 |
| constexpr auto | FIFF_RAW_PICK_LIST = 11 |
| constexpr auto | FIFF_ECHO = 12 |
| constexpr auto | FIFF_RESUME_READING = 13 |
| constexpr auto | FIFF_DACQ_SYSTEM_TYPE = 14 |
| constexpr auto | FIFF_SELECT_RAW_CH = 15 |
| constexpr auto | FIFF_PLAYBACK_MODE = 16 |
| constexpr auto | FIFF_CONTINUE_FILE = 17 |
| constexpr auto | FIFF_JITTER_MAX = 18 |
| constexpr auto | FIFF_STREAM_SEGMENT = 19 |
| constexpr auto | FIFFV_DACQ_SYSTEM_DAU = 0 |
| constexpr auto | FIFFV_DACQ_SYSTEM_VXI = 1 |
| constexpr auto | FIFFV_DACQ_SYSTEM_RPU = 2 |
| constexpr auto | FIFFV_DACQ_SYSTEM_ORION = 3 |
| constexpr auto | FIFF_FILE_ID = 100 |
| constexpr auto | FIFF_DIR_POINTER = 101 |
| constexpr auto | FIFF_DIR = 102 |
| constexpr auto | FIFF_BLOCK_ID = 103 |
| constexpr auto | FIFF_BLOCK_START = 104 |
| constexpr auto | FIFF_BLOCK_END = 105 |
| constexpr auto | FIFF_FREE_LIST = 106 |
| constexpr auto | FIFF_FREE_BLOCK = 107 |
| constexpr auto | FIFF_NOP = 108 |
| constexpr auto | FIFF_PARENT_FILE_ID = 109 |
| constexpr auto | FIFF_PARENT_BLOCK_ID = 110 |
| constexpr auto | FIFF_BLOCK_NAME = 111 |
| constexpr auto | FIFF_BLOCK_VERSION = 112 |
| constexpr auto | FIFF_CREATOR = 113 |
| constexpr auto | FIFF_MODIFIER = 114 |
| constexpr auto | FIFF_REF_ROLE = 115 |
| constexpr auto | FIFF_REF_FILE_ID = 116 |
| constexpr auto | FIFF_REF_FILE_NUM = 117 |
| constexpr auto | FIFF_REF_FILE_NAME = 118 |
| constexpr auto | FIFF_REF_BLOCK_ID = 120 |
| constexpr auto | FIFF_DACQ_PARS = 150 |
| constexpr auto | FIFF_DACQ_STIM = 151 |
| constexpr auto | FIFFB_ROOT = 999 |
| constexpr auto | FIFFB_MEAS = 100 |
| constexpr auto | FIFFB_MEAS_INFO = 101 |
| constexpr auto | FIFFB_RAW_DATA = 102 |
| constexpr auto | FIFFB_PROCESSED_DATA = 103 |
| constexpr auto | FIFFB_EVOKED = 104 |
| constexpr auto | FIFFB_ASPECT = 105 |
| constexpr auto | FIFFB_SUBJECT = 106 |
| constexpr auto | FIFFB_ISOTRAK = 107 |
| constexpr auto | FIFFB_HPI_MEAS = 108 |
| constexpr auto | FIFFB_HPI_RESULT = 109 |
| constexpr auto | FIFFB_HPI_COIL = 110 |
| constexpr auto | FIFFB_PROJECT = 111 |
| constexpr auto | FIFFB_CONTINUOUS_DATA = 112 |
| constexpr auto | FIFFB_VOID = 114 |
| constexpr auto | FIFFB_EVENTS = 115 |
| constexpr auto | FIFFB_INDEX = 116 |
| constexpr auto | FIFFB_DACQ_PARS = 117 |
| constexpr auto | FIFFB_REF = 118 |
| constexpr auto | FIFFB_SMSH_RAW_DATA = 119 |
| constexpr auto | FIFFB_SMSH_ASPECT = 120 |
| constexpr auto | FIFFB_HPI_SUBSYSTEM = 121 |
| constexpr auto | FIFFB_MRI = 200 |
| constexpr auto | FIFFB_MRI_SET = 201 |
| constexpr auto | FIFFB_MRI_SLICE = 202 |
| constexpr auto | FIFFB_MRI_SCENERY = 203 |
| constexpr auto | FIFFB_MRI_SCENE = 204 |
| constexpr auto | FIFFB_MRI_SEG = 205 |
| constexpr auto | FIFFB_MRI_SEG_REGION = 206 |
| constexpr auto | FIFFB_SPHERE = 300 |
| constexpr auto | FIFFB_BEM = 310 |
| constexpr auto | FIFFB_BEM_SURF = 311 |
| constexpr auto | FIFFB_CONDUCTOR_MODEL = 312 |
| constexpr auto | FIFFB_XFIT_PROJ = 313 |
| constexpr auto | FIFFB_XFIT_PROJ_ITEM = 314 |
| constexpr auto | FIFFB_XFIT_AUX = 315 |
| constexpr auto | FIFFB_BAD_CHANNELS = 359 |
| constexpr auto | FIFFB_VOL_INFO = 400 |
| constexpr auto | FIFFB_DATA_CORRECTION = 500 |
| constexpr auto | FIFFB_CHANNEL_DECOUPLER = 501 |
| constexpr auto | FIFFB_SSS_INFO = 502 |
| constexpr auto | FIFFB_SSS_CAL_ADJUST = 503 |
| constexpr auto | FIFFB_SSS_ST_INFO = 504 |
| constexpr auto | FIFFB_SSS_BASES = 505 |
| constexpr auto | FIFFB_SMARTSHIELD = 510 |
| constexpr auto | FIFFV_ASPECT_AVERAGE = 100 |
| constexpr auto | FIFFV_ASPECT_STD_ERR = 101 |
| constexpr auto | FIFFV_ASPECT_SINGLE = 102 |
| constexpr auto | FIFFV_ASPECT_SUBAVERAGE = 103 |
| constexpr auto | FIFFV_ASPECT_ALTAVERAGE = 104 |
| constexpr auto | FIFFV_ASPECT_SAMPLE = 105 |
| constexpr auto | FIFFV_ASPECT_POWER_DENSITY = 106 |
| constexpr auto | FIFFV_ASPECT_DIPOLE_WAVE = 200 |
| constexpr auto | FIFF_UTC_OFFSET = 159 |
| constexpr auto | FIFF_NCHAN = 200 |
| constexpr auto | FIFF_SFREQ = 201 |
| constexpr auto | FIFF_DATA_PACK = 202 |
| constexpr auto | FIFF_CH_INFO = 203 |
| constexpr auto | FIFF_MEAS_DATE = 204 |
| constexpr auto | FIFF_SUBJECT = 205 |
| constexpr auto | FIFF_COMMENT = 206 |
| constexpr auto | FIFF_NAVE = 207 |
| constexpr auto | FIFF_FIRST_SAMPLE = 208 |
| constexpr auto | FIFF_LAST_SAMPLE = 209 |
| constexpr auto | FIFF_ASPECT_KIND = 210 |
| constexpr auto | FIFF_REF_EVENT = 211 |
| constexpr auto | FIFF_EXPERIMENTER = 212 |
| constexpr auto | FIFF_DIG_POINT = 213 |
| constexpr auto | FIFF_CH_POS_VEC = 214 |
| constexpr auto | FIFF_HPI_SLOPES = 215 |
| constexpr auto | FIFF_HPI_NCOIL = 216 |
| constexpr auto | FIFF_REQ_EVENT = 217 |
| constexpr auto | FIFF_REQ_LIMIT = 218 |
| constexpr auto | FIFF_LOWPASS = 219 |
| constexpr auto | FIFF_BAD_CHS = 220 |
| constexpr auto | FIFF_ARTEF_REMOVAL = 221 |
| constexpr auto | FIFF_COORD_TRANS = 222 |
| constexpr auto | FIFF_HIGHPASS = 223 |
| constexpr auto | FIFF_CH_CALS_VEC = 224 |
| constexpr auto | FIFF_HPI_BAD_CHS = 225 |
| constexpr auto | FIFF_HPI_CORR_COEFF = 226 |
| constexpr auto | FIFF_EVENT_COMMENT = 227 |
| constexpr auto | FIFF_NO_SAMPLES = 228 |
| constexpr auto | FIFF_FIRST_TIME = 229 |
| constexpr auto | FIFF_SUBAVE_SIZE = 230 |
| constexpr auto | FIFF_SUBAVE_FIRST = 231 |
| constexpr auto | FIFF_NAME = 233 |
| constexpr auto | FIFF_DIG_STRING = 234 |
| constexpr auto | FIFF_LINE_FREQ = 235 |
| constexpr auto | FIFF_HPI_COIL_FREQ = 236 |
| constexpr auto | FIFF_SIGNAL_CHANNEL = 237 |
| constexpr auto | FIFFC_HPI_MAX_NCOIL = 1000 |
| constexpr auto | FIFF_HPI_COIL_MOMENTS = 240 |
| constexpr auto | FIFF_HPI_FIT_GOODNESS = 241 |
| constexpr auto | FIFF_HPI_FIT_ACCEPT = 242 |
| constexpr auto | FIFF_HPI_FIT_GOOD_LIMIT = 243 |
| constexpr auto | FIFF_HPI_FIT_DIST_LIMIT = 244 |
| constexpr auto | FIFF_HPI_COIL_NO = 245 |
| constexpr auto | FIFF_HPI_COILS_USED = 246 |
| constexpr auto | FIFF_HPI_DIGITIZATION_ORDER = 247 |
| constexpr auto | FIFFV_HPI_ACCEPT_PROGRAM = (1 << 0) |
| constexpr auto | FIFFV_HPI_ACCEPT_USER = (1 << 1) |
| constexpr auto | FIFFV_HPI_ACCEPT_NONE = 0 |
| constexpr auto | FIFF_CH_SCAN_NO = 250 |
| constexpr auto | FIFF_CH_LOGICAL_NO = 251 |
| constexpr auto | FIFF_CH_KIND = 252 |
| constexpr auto | FIFF_CH_RANGE = 253 |
| constexpr auto | FIFF_CH_CAL = 254 |
| constexpr auto | FIFF_CH_POS = 255 |
| constexpr auto | FIFF_CH_UNIT = 256 |
| constexpr auto | FIFF_CH_UNIT_MUL = 257 |
| constexpr auto | FIFF_CH_DACQ_NAME = 258 |
| constexpr auto | FIFF_SSS_FRAME = 263 |
| constexpr auto | FIFF_SSS_JOB = 264 |
| constexpr auto | FIFF_SSS_ORIGIN = 265 |
| constexpr auto | FIFF_SSS_ORD_IN = 266 |
| constexpr auto | FIFF_SSS_ORD_OUT = 267 |
| constexpr auto | FIFF_SSS_NMAG = 268 |
| constexpr auto | FIFF_SSS_COMPONENTS = 269 |
| constexpr auto | FIFF_SSS_CAL_CHANS = 270 |
| constexpr auto | FIFF_SSS_CAL_CORRS = 271 |
| constexpr auto | FIFF_SSS_ST_CORR = 272 |
| constexpr auto | FIFFV_SSS_JOB_NOTHING = 0 |
| constexpr auto | FIFFV_SSS_JOB_CTC = 1 |
| constexpr auto | FIFFV_SSS_JOB_FILTER = 2 |
| constexpr auto | FIFFV_SSS_JOB_VIRT = 3 |
| constexpr auto | FIFFV_SSS_JOB_HEAD_POS = 4 |
| constexpr auto | FIFFV_SSS_JOB_MOVEC_FIT = 5 |
| constexpr auto | FIFFV_SSS_JOB_MOVEC_QUA = 6 |
| constexpr auto | FIFFV_SSS_JOB_REC_ALL = 7 |
| constexpr auto | FIFFV_SSS_JOB_REC_IN = 8 |
| constexpr auto | FIFFV_SSS_JOB_REC_OUT = 9 |
| constexpr auto | FIFFV_SSS_JOB_ST = 10 |
| constexpr auto | FIFF_SSS_BASE_IN = 273 |
| constexpr auto | FIFF_SSS_BASE_OUT = 274 |
| constexpr auto | FIFF_SSS_BASE_VIRT = 275 |
| constexpr auto | FIFF_SSS_NORM = 276 |
| constexpr auto | FIFF_SSS_ITERATE = 277 |
| constexpr auto | FIFF_GANTRY_ANGLE = 282 |
| constexpr auto | FIFF_DATA_BUFFER = 300 |
| constexpr auto | FIFF_DATA_SKIP = 301 |
| constexpr auto | FIFF_EPOCH = 302 |
| constexpr auto | FIFF_DATA_SKIP_SAMP = 303 |
| constexpr auto | FIFF_DATA_BUFFER2 = 304 |
| constexpr auto | FIFF_TIME_STAMP = 305 |
| constexpr auto | FIFF_SUBJ_ID = 400 |
| constexpr auto | FIFF_SUBJ_FIRST_NAME = 401 |
| constexpr auto | FIFF_SUBJ_MIDDLE_NAME = 402 |
| constexpr auto | FIFF_SUBJ_LAST_NAME = 403 |
| constexpr auto | FIFF_SUBJ_BIRTH_DAY = 404 |
| constexpr auto | FIFF_SUBJ_SEX = 405 |
| constexpr auto | FIFF_SUBJ_HAND = 406 |
| constexpr auto | FIFF_SUBJ_WEIGHT = 407 |
| constexpr auto | FIFF_SUBJ_HEIGHT = 408 |
| constexpr auto | FIFF_SUBJ_COMMENT = 409 |
| constexpr auto | FIFF_SUBJ_HIS_ID = 410 |
| constexpr auto | FIFF_PROJ_ID = 500 |
| constexpr auto | FIFF_PROJ_NAME = 501 |
| constexpr auto | FIFF_PROJ_AIM = 502 |
| constexpr auto | FIFF_PROJ_PERSONS = 503 |
| constexpr auto | FIFF_PROJ_COMMENT = 504 |
| constexpr auto | FIFFV_SEX_UNKNOWN = 0 |
| constexpr auto | FIFFV_SEX_MALE = 1 |
| constexpr auto | FIFFV_SEX_FEMALE = 2 |
| constexpr auto | FIFFV_HAND_RIGHT = 1 |
| constexpr auto | FIFFV_HAND_LEFT = 2 |
| constexpr auto | FIFFV_HAND_AMBIDEXTROUS = 3 |
| constexpr auto | FIFF_EVENT_CHANNELS = 600 |
| constexpr auto | FIFF_EVENT_LIST = 601 |
| constexpr auto | FIFF_EVENT_CHANNEL = 602 |
| constexpr auto | FIFF_EVENT_BITS = 603 |
| constexpr auto | FIFFC_EVENT_FROMMASK = 0 |
| constexpr auto | FIFFC_EVENT_FROMBITS = 1 |
| constexpr auto | FIFFC_EVENT_TOMASK = 2 |
| constexpr auto | FIFFC_EVENT_TOBITS = 3 |
| constexpr auto | FIFF_SQUID_BIAS = 701 |
| constexpr auto | FIFF_SQUID_OFFSET = 702 |
| constexpr auto | FIFF_SQUID_GATE = 703 |
| constexpr auto | FIFF_DECOUPLER_MATRIX = 800 |
| constexpr auto | FIFFB_PROCESSING_HISTORY = 900 |
| constexpr auto | FIFFB_PROCESSING_RECORD = 901 |
| constexpr auto | FIFFV_ASPECT_IFII_LOW = 1100 |
| constexpr auto | FIFFV_ASPECT_IFII_HIGH = 1101 |
| constexpr auto | FIFFV_ASPECT_GATE = 1102 |
| constexpr auto | FIFF_REF_PATH = 1101 |
| constexpr auto | FIFF_MRI_SOURCE_FORMAT = 2002 |
| constexpr auto | FIFF_MRI_PIXEL_ENCODING = 2003 |
| constexpr auto | FIFF_MRI_PIXEL_DATA_OFFSET = 2004 |
| constexpr auto | FIFF_MRI_PIXEL_SCALE = 2005 |
| constexpr auto | FIFF_MRI_PIXEL_DATA = 2006 |
| constexpr auto | FIFF_MRI_PIXEL_OVERLAY_ENCODING = 2007 |
| constexpr auto | FIFF_MRI_PIXEL_OVERLAY_DATA = 2008 |
| constexpr auto | FIFF_MRI_BOUNDING_BOX = 2009 |
| constexpr auto | FIFF_MRI_WIDTH = 2010 |
| constexpr auto | FIFF_MRI_WIDTH_M = 2011 |
| constexpr auto | FIFF_MRI_HEIGHT = 2012 |
| constexpr auto | FIFF_MRI_HEIGHT_M = 2013 |
| constexpr auto | FIFF_MRI_DEPTH = 2014 |
| constexpr auto | FIFF_MRI_DEPTH_M = 2015 |
| constexpr auto | FIFF_MRI_THICKNESS = 2016 |
| constexpr auto | FIFF_MRI_SCENE_AIM = 2017 |
| constexpr auto | FIFF_MRI_ORIG_SOURCE_PATH = 2020 |
| constexpr auto | FIFF_MRI_ORIG_SOURCE_FORMAT = 2021 |
| constexpr auto | FIFF_MRI_ORIG_PIXEL_ENCODING = 2022 |
| constexpr auto | FIFF_MRI_ORIG_PIXEL_DATA_OFFSET = 2023 |
| constexpr auto | FIFF_MRI_VOXEL_DATA = 2030 |
| constexpr auto | FIFF_MRI_VOXEL_ENCODING = 2031 |
| constexpr auto | FIFF_MRI_MRILAB_SETUP = 2100 |
| constexpr auto | FIFF_MRI_SEG_REGION_ID = 2200 |
| constexpr auto | FIFFV_MRI_FORMAT_UNKNOWN = 0 |
| constexpr auto | FIFFV_MRI_FORMAT_MAGNETOM_SHORT = 1 |
| constexpr auto | FIFFV_MRI_FORMAT_MAGNETOM_LONG = 2 |
| constexpr auto | FIFFV_MRI_FORMAT_MERIT = 3 |
| constexpr auto | FIFFV_MRI_FORMAT_SIGNA = 4 |
| constexpr auto | FIFFV_MRI_FORMAT_PIXEL_RAW = 5 |
| constexpr auto | FIFFV_MRI_FORMAT_PIXEL_RAW_PACKED = 6 |
| constexpr auto | FIFFV_MRI_FORMAT_MAGNETOM_NEW = 7 |
| constexpr auto | FIFFV_MRI_FORMAT_FIFF = 8 |
| constexpr auto | FIFFV_MRI_FORMAT_ACR_NEMA = 9 |
| constexpr auto | FIFFV_MRI_FORMAT_DICOM_3 = 10 |
| constexpr auto | FIFFV_MRI_FORMAT_VISTA = 11 |
| constexpr auto | FIFFV_MRI_PIXEL_UNKNOWN = 0 |
| constexpr auto | FIFFV_MRI_PIXEL_BYTE = 1 |
| constexpr auto | FIFFV_MRI_PIXEL_WORD = 2 |
| constexpr auto | FIFFV_MRI_PIXEL_SWAP_WORD = 3 |
| constexpr auto | FIFFV_MRI_PIXEL_FLOAT = 4 |
| constexpr auto | FIFFV_MRI_PIXEL_BYTE_INDEXED_COLOR = 5 |
| constexpr auto | FIFFV_MRI_PIXEL_BYTE_RGB_COLOR = 6 |
| constexpr auto | FIFFV_MRI_PIXEL_BYTE_RLE_RGB_COLOR = 7 |
| constexpr auto | FIFFV_MRI_PIXEL_BIT_RLE = 8 |
| constexpr auto | FIFF_CONDUCTOR_MODEL_KIND = 3000 |
| constexpr auto | FIFFV_COND_MODEL_UNKNOWN = 0 |
| constexpr auto | FIFFV_COND_MODEL_SPHERE = 1 |
| constexpr auto | FIFFV_COND_MODEL_BEM_HOMOG = 2 |
| constexpr auto | FIFFV_COND_MODEL_BEM = 3 |
| constexpr auto | FIFF_SPHERE_ORIGIN = 3001 |
| constexpr auto | FIFF_SPHERE_COORD_FRAME = 3002 |
| constexpr auto | FIFF_SPHERE_LAYERS = 3003 |
| constexpr auto | FIFF_BEM_SURF_ID = 3101 |
| constexpr auto | FIFF_BEM_SURF_NAME = 3102 |
| constexpr auto | FIFF_BEM_SURF_NNODE = 3103 |
| constexpr auto | FIFF_BEM_SURF_NTRI = 3104 |
| constexpr auto | FIFF_BEM_SURF_NODES = 3105 |
| constexpr auto | FIFF_BEM_SURF_TRIANGLES = 3106 |
| constexpr auto | FIFF_BEM_SURF_NORMALS = 3107 |
| constexpr auto | FIFF_BEM_SURF_CURVS = 3108 |
| constexpr auto | FIFF_BEM_SURF_CURV_VALUES = 3109 |
| constexpr auto | FIFF_BEM_POT_SOLUTION = 3110 |
| constexpr auto | FIFF_BEM_APPROX = 3111 |
| constexpr auto | FIFF_BEM_COORD_FRAME = 3112 |
| constexpr auto | FIFF_BEM_SIGMA = 3113 |
| constexpr auto | FIFFV_BEM_SURF_ID_UNKNOWN = -1 |
| constexpr auto | FIFFV_BEM_SURF_ID_BRAIN = 1 |
| constexpr auto | FIFFV_BEM_SURF_ID_CSF = 2 |
| constexpr auto | FIFFV_BEM_SURF_ID_SKULL = 3 |
| constexpr auto | FIFFV_BEM_SURF_ID_HEAD = 4 |
| constexpr auto | FIFFV_BEM_SURF_ID_BLOOD = 11 |
| constexpr auto | FIFFV_BEM_SURF_ID_HEART = 12 |
| constexpr auto | FIFFV_BEM_SURF_ID_LUNGS = 13 |
| constexpr auto | FIFFV_BEM_SURF_ID_TORSO = 14 |
| constexpr auto | FIFFV_BEM_SURF_ID_NM122 = 21 |
| constexpr auto | FIFFV_BEM_SURF_UNIT_SPHERE = 22 |
| constexpr auto | FIFFV_BEM_SURF_ID_VV = 23 |
| constexpr auto | FIFFV_BEM_APPROX_CONST = 1 |
| constexpr auto | FIFFV_BEM_APPROX_LINEAR = 2 |
| constexpr auto | FIFF_SOURCE_DIPOLE = 3201 |
| constexpr auto | FIFF_XFIT_LEAD_PRODUCTS = 3401 |
| constexpr auto | FIFF_XFIT_MAP_PRODUCTS = 3402 |
| constexpr auto | FIFF_XFIT_GRAD_MAP_PRODUCTS = 3403 |
| constexpr auto | FIFF_XFIT_VOL_INTEGRATION = 3404 |
| constexpr auto | FIFF_XFIT_INTEGRATION_RADIUS = 3405 |
| constexpr auto | FIFF_XFIT_CONDUCTOR_MODEL_NAME = 3406 |
| constexpr auto | FIFF_XFIT_CONDUCTOR_MODEL_TRANS_NAME = 3407 |
| constexpr auto | FIFF_XFIT_CONT_SURF_TYPE = 3408 |
| constexpr auto | FIFF_PROJ_ITEM_KIND = 3411 |
| constexpr auto | FIFF_PROJ_ITEM_TIME = 3412 |
| constexpr auto | FIFF_PROJ_ITEM_IGN_CHS = 3413 |
| constexpr auto | FIFF_PROJ_ITEM_NVEC = 3414 |
| constexpr auto | FIFF_PROJ_ITEM_VECTORS = 3415 |
| constexpr auto | FIFF_PROJ_ITEM_DEFINITION = 3416 |
| constexpr auto | FIFF_PROJ_ITEM_CH_NAME_LIST = 3417 |
| constexpr auto | FIFFV_PROJ_ITEM_NONE = 0 |
| constexpr auto | FIFFV_PROJ_ITEM_FIELD = 1 |
| constexpr auto | FIFFV_PROJ_ITEM_DIP_FIX = 2 |
| constexpr auto | FIFFV_PROJ_ITEM_DIP_ROT = 3 |
| constexpr auto | FIFFV_PROJ_ITEM_HOMOG_GRAD = 4 |
| constexpr auto | FIFFV_PROJ_ITEM_HOMOG_FIELD = 5 |
| constexpr auto | FIFFV_PROJ_ITEM_EEG_AVREF = 10 |
| constexpr auto | FIFF_XPLOTTER_LAYOUT = 3501 |
| constexpr auto | FIFF_CH_NAME_LIST = 3507 |
| constexpr auto | FIFF_VOL_ID = 4001 |
| constexpr auto | FIFF_VOL_NAME = 4002 |
| constexpr auto | FIFF_VOL_OWNER_ID = 4003 |
| constexpr auto | FIFF_VOL_OWNER_NAME = 4004 |
| constexpr auto | FIFF_VOL_OWNER_REAL_NAME = 4005 |
| constexpr auto | FIFF_VOL_TYPE = 4006 |
| constexpr auto | FIFF_VOL_HOST = 4007 |
| constexpr auto | FIFF_VOL_REAL_ROOT = 4008 |
| constexpr auto | FIFF_VOL_SYMBOLIC_ROOT = 4009 |
| constexpr auto | FIFF_VOL_MOUNT_POINT = 4010 |
| constexpr auto | FIFF_VOL_BLOCKS = 4011 |
| constexpr auto | FIFF_VOL_FREE_BLOCKS = 4012 |
| constexpr auto | FIFF_VOL_AVAIL_BLOCKS = 4013 |
| constexpr auto | FIFF_VOL_BLOCK_SIZE = 4014 |
| constexpr auto | FIFF_VOL_DIRECTORY = 4015 |
| constexpr auto | FIFF_INDEX_KIND = 5001 |
| constexpr auto | FIFF_INDEX = 5002 |
| constexpr auto | FIFFV_ROLE_PREV_FILE = 1 |
| constexpr auto | FIFFV_ROLE_NEXT_FILE = 2 |
| constexpr auto | FIFFV_PROJ_BY_COMPLEMENT = 0 |
| constexpr auto | FIFFV_PROJ_BY_SPACE = 1 |
| constexpr auto | FIFFV_VOL_TYPE_HD = 1 |
| constexpr auto | FIFFV_VOL_TYPE_MOD = 2 |
| constexpr auto | FIFFV_NATIVE_ENDIAN = 0 |
| constexpr auto | FIFFV_LITTLE_ENDIAN = 1 |
| constexpr auto | FIFFV_BIG_ENDIAN = 2 |
FIFF tag-kind, block-kind and type-code numerical definitions, authoritative for FIFFLIB.
SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2012-2026 MNE-CPP Authors
Companion to fiff_constants.h that focuses on the value space of tag kinds (the FIFF_* numbers below 1000), of block kinds (FIFFB_*) and of the 32-bit FIFF type descriptors (FIFFT_*). The header doubles as the reference for the conventions used throughout the codebase: the upper byte of a type code encodes the fundamental structure (scalar vs. multidimensional matrix), the lower bytes encode the element type, and matrices additionally carry a dense / CCS / RCS sparse-coding indicator multiplexed into the same word (see fiff_tag.h for the bit masks).
These numbers are part of the on-disk FIFF format and are shared with mne.io.constants in MNE-Python; do not renumber them.
Definition in file fiff_file.h.
| #define FIFF_DESCRIPTION FIFF_COMMENT |
(Textual) Description of an object.
Definition at line 477 of file fiff_file.h.
| #define FIFF_MRI_SOURCE_PATH FIFF_REF_PATH |
Definition at line 634 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_COMMENT FIFF_COMMENT |
Definition at line 797 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_DESCRIPTION FIFF_DESCRIPTION |
Definition at line 798 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_DIPOLE FIFF_SOURCE_DIPOLE |
Definition at line 793 of file fiff_file.h.
| #define FIFF_SPARSE_CH_NAME_LIST FIFF_PROJ_ITEM_CH_NAME_LIST |
Definition at line 613 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_COMMENT FIFF_PROJ_ITEM_COMMENT |
Definition at line 808 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_DIPOLE FIFF_PROJ_ITEM_DIPOLE |
Definition at line 804 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_IGN_CHS FIFF_PROJ_ITEM_IGN_CHS |
Definition at line 805 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_KIND FIFF_PROJ_ITEM_KIND |
Definition at line 802 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_NVEC FIFF_PROJ_ITEM_NVEC |
Definition at line 806 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_TIME FIFF_PROJ_ITEM_TIME |
Definition at line 803 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_VECTORS FIFF_PROJ_ITEM_VECTORS |
Definition at line 807 of file fiff_file.h.
| #define FIFFB_MCG_AVE FIFFB_EVOKED |
Definition at line 358 of file fiff_file.h.
| #define FIFFB_PROJ FIFFB_XFIT_PROJ |
Definition at line 400 of file fiff_file.h.
| #define FIFFB_PROJ_ITEM FIFFB_XFIT_PROJ_ITEM |
Definition at line 401 of file fiff_file.h.
| #define FIFFC_VERSION (FIFFC_MAJOR_VERSION << 16 | FIFFC_MINOR_VERSION) |
Definition at line 213 of file fiff_file.h.
| #define FIFFM_MESSAGE_GROUP | ( | x | ) |
Definition at line 273 of file fiff_file.h.
| #define FIFFT_CCS_MATRIX (FIFFTS_FS_MATRIX | FIFFTS_MC_CCS) |
Definition at line 264 of file fiff_file.h.
| #define FIFFT_CCS_MATRIX_FLOAT (FIFFT_CCS_MATRIX | FIFFT_FLOAT) |
Definition at line 270 of file fiff_file.h.
| #define FIFFT_MATRIX (FIFFTS_FS_MATRIX | FIFFTS_MC_DENSE) |
Definition at line 263 of file fiff_file.h.
| #define FIFFT_MATRIX_DOUBLE (FIFFT_MATRIX | FIFFT_DOUBLE) |
Definition at line 269 of file fiff_file.h.
| #define FIFFT_MATRIX_FLOAT (FIFFT_MATRIX | FIFFT_FLOAT) |
Definition at line 268 of file fiff_file.h.
| #define FIFFT_MATRIX_INT (FIFFT_MATRIX | FIFFT_INT) |
Definition at line 267 of file fiff_file.h.
| #define FIFFT_RCS_MATRIX (FIFFTS_FS_MATRIX | FIFFTS_MC_RCS) |
Definition at line 265 of file fiff_file.h.
| #define FIFFT_RCS_MATRIX_FLOAT (FIFFT_RCS_MATRIX | FIFFT_FLOAT) |
Definition at line 271 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_BLOOD FIFF_BEM_SURF_ID_BLOOD |
Definition at line 762 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_BRAIN FIFF_BEM_SURF_ID_BRAIN |
Definition at line 757 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_CSF FIFF_BEM_SURF_ID_CSF |
Definition at line 758 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_HEAD FIFF_BEM_SURF_ID_HEAD |
Definition at line 760 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_HEART FIFF_BEM_SURF_ID_HEART |
Definition at line 763 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_LUNGS FIFF_BEM_SURF_ID_LUNGS |
Definition at line 764 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_SKULL FIFF_BEM_SURF_ID_SKULL |
Definition at line 759 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_TORSO FIFF_BEM_SURF_ID_TORSO |
Definition at line 765 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_UNKNOWN FIFF_BEM_SURF_ID_UNKNOWN |
Definition at line 756 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_DIP_FIX FIFFV_PROJ_ITEM_DIP_FIX |
Definition at line 823 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_DIP_ROT FIFFV_PROJ_ITEM_DIP_ROT |
Definition at line 824 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_FIELD FIFFV_PROJ_ITEM_FIELD |
Definition at line 822 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_HOMOG_FIELD FIFFV_PROJ_ITEM_HOMOG_FIELD |
Definition at line 826 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_HOMOG_GRAD FIFFV_PROJ_ITEM_HOMOG_GRAD |
Definition at line 825 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_NONE FIFFV_PROJ_ITEM_NONE |
Definition at line 821 of file fiff_file.h.
|
inlineconstexpr |
Artifact removal.
Definition at line 465 of file fiff_file.h.
|
inlineconstexpr |
Aspect label.
Definition at line 454 of file fiff_file.h.
|
inlineconstexpr |
List of bad channels.
Definition at line 464 of file fiff_file.h.
|
inlineconstexpr |
int approximation method, see below.
Definition at line 733 of file fiff_file.h.
|
inlineconstexpr |
The coordinate frame of the model.
Definition at line 734 of file fiff_file.h.
|
inlineconstexpr |
float ** The solution matrix.
Definition at line 732 of file fiff_file.h.
|
inlineconstexpr |
Conductivity of a compartment.
Definition at line 735 of file fiff_file.h.
|
inlineconstexpr |
float the two curvature values (nnode,2).
Definition at line 730 of file fiff_file.h.
|
inlineconstexpr |
float surface node first principal curvature unit vectors (nnode,3).
Definition at line 729 of file fiff_file.h.
|
inlineconstexpr |
int surface number.
Definition at line 722 of file fiff_file.h.
|
inlineconstexpr |
string surface name.
Definition at line 723 of file fiff_file.h.
|
inlineconstexpr |
int # of nodes on a surface.
Definition at line 724 of file fiff_file.h.
|
inlineconstexpr |
float surface nodes (nnode,3).
Definition at line 726 of file fiff_file.h.
|
inlineconstexpr |
float surface node normal unit vectors (nnode,3).
Definition at line 728 of file fiff_file.h.
|
inlineconstexpr |
int # number of triangles on a surface.
Definition at line 725 of file fiff_file.h.
|
inlineconstexpr |
int surface triangles (ntri,3).
Definition at line 727 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 319 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 317 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 325 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 318 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 326 of file fiff_file.h.
|
inlineconstexpr |
float "Calibration coefficients from output voltage to some real units".
Definition at line 512 of file fiff_file.h.
|
inlineconstexpr |
This will not occur in new files.
Definition at line 468 of file fiff_file.h.
|
inlineconstexpr |
string "Name of the channel in the data acquisition system. Same as fiffChInfoRec.name.".
Definition at line 516 of file fiff_file.h.
|
inlineconstexpr |
Channel descriptor.
Definition at line 447 of file fiff_file.h.
|
inlineconstexpr |
enum(ch_kind) "Channel type. Corresponds to fiffChInfoRec.kind field".
Definition at line 510 of file fiff_file.h.
|
inlineconstexpr |
int32 "Channel logical number. Corresponds to fiffChInfoRec.logNo field".
Definition at line 509 of file fiff_file.h.
|
inlineconstexpr |
Alias of FIFF_MNE_CH_NAME_LIST.
Definition at line 834 of file fiff_file.h.
|
inlineconstexpr |
ch_pos_rec "Channel position".
Definition at line 513 of file fiff_file.h.
|
inlineconstexpr |
Channel positions.
Definition at line 458 of file fiff_file.h.
|
inlineconstexpr |
float "Conversion from recorded number to (possibly virtual) voltage at the output".
Definition at line 511 of file fiff_file.h.
|
inlineconstexpr |
int32 "Channel scan number. Corresponds to fiffChInfoRec.scanNo field".
Definition at line 508 of file fiff_file.h.
|
inlineconstexpr |
enum(unit) "Unit of the data".
Definition at line 514 of file fiff_file.h.
|
inlineconstexpr |
int "Unit multiplier exponent.
Definition at line 515 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 279 of file fiff_file.h.
|
inlineconstexpr |
This is used in a questionable way...
Definition at line 450 of file fiff_file.h.
|
inlineconstexpr |
What kind of conductor model.
Definition at line 707 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 284 of file fiff_file.h.
|
inlineconstexpr |
Used to inform that data is saved into a continuation file.
Definition at line 294 of file fiff_file.h.
|
inlineconstexpr |
Coordinate transformation.
Definition at line 466 of file fiff_file.h.
|
inlineconstexpr |
Program that created the file (string) .
Definition at line 327 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 341 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 342 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 291 of file fiff_file.h.
|
inlineconstexpr |
Buffer containing measurement data.
Definition at line 547 of file fiff_file.h.
|
inlineconstexpr |
Int_32 data buffer in dacq outgen.
Definition at line 551 of file fiff_file.h.
|
inlineconstexpr |
How the raw data is packed.
Definition at line 446 of file fiff_file.h.
|
inlineconstexpr |
Data skip in buffers.
Definition at line 548 of file fiff_file.h.
|
inlineconstexpr |
Data skip in samples.
Definition at line 550 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 612 of file fiff_file.h.
|
inlineconstexpr |
Digitization point.
Definition at line 457 of file fiff_file.h.
|
inlineconstexpr |
String of digitized points.
Definition at line 478 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 316 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 315 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 280 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 289 of file fiff_file.h.
|
inlineconstexpr |
Buffer containing one epoch and channel.
Definition at line 549 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 281 of file fiff_file.h.
|
inlineconstexpr |
Event bits array.
Definition at line 592 of file fiff_file.h.
|
inlineconstexpr |
Event channel name.
Definition at line 591 of file fiff_file.h.
|
inlineconstexpr |
Event channel numbers.
Definition at line 585 of file fiff_file.h.
|
inlineconstexpr |
Comment about the events used in averaging.
Definition at line 471 of file fiff_file.h.
|
inlineconstexpr |
List of events (integers: (sample, before, after) triplets).
Definition at line 586 of file fiff_file.h.
|
inlineconstexpr |
Experimenter name.
Definition at line 456 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 283 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 314 of file fiff_file.h.
|
inlineconstexpr |
The first sample of an epoch.
Definition at line 452 of file fiff_file.h.
|
inlineconstexpr |
Time scale minimum.
Definition at line 473 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 321 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 320 of file fiff_file.h.
|
inlineconstexpr |
Tilt angle of the dewar in degrees.
Definition at line 546 of file fiff_file.h.
|
inlineconstexpr |
Analog highpass.
Definition at line 467 of file fiff_file.h.
|
inlineconstexpr |
List of channels considered to be bad in hpi.
Definition at line 469 of file fiff_file.h.
|
inlineconstexpr |
HPI coil excitation frequency.
Definition at line 481 of file fiff_file.h.
|
inlineconstexpr |
Estimated moment vectors for the HPI coil magnetic dipoles.
Definition at line 491 of file fiff_file.h.
|
inlineconstexpr |
Coil number listed by HPI measurement.
Definition at line 496 of file fiff_file.h.
|
inlineconstexpr |
List of coils finally used when the transformation was computed
Definition at line 497 of file fiff_file.h.
|
inlineconstexpr |
Hpi curve fit correlations.
Definition at line 470 of file fiff_file.h.
|
inlineconstexpr |
Which Isotrak digitization point corresponds to each of the coils energized
Definition at line 499 of file fiff_file.h.
|
inlineconstexpr |
Bitmask indicating acceptance (see below).
Definition at line 493 of file fiff_file.h.
|
inlineconstexpr |
Limit for the coil distance difference.
Definition at line 495 of file fiff_file.h.
|
inlineconstexpr |
Limit for the goodness-of-fit.
Definition at line 494 of file fiff_file.h.
|
inlineconstexpr |
Three floats indicating the goodness of fit.
Definition at line 492 of file fiff_file.h.
|
inlineconstexpr |
Number of HPI coils.
Definition at line 460 of file fiff_file.h.
|
inlineconstexpr |
HPI data.
Definition at line 459 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 858 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 857 of file fiff_file.h.
|
inlineconstexpr |
Used to tell the jitter in the timing of data packets.
Definition at line 295 of file fiff_file.h.
|
inlineconstexpr |
The last sample of an epoch.
Definition at line 453 of file fiff_file.h.
|
inlineconstexpr |
Line interference frequency.
Definition at line 480 of file fiff_file.h.
|
inlineconstexpr |
Analog lowpass.
Definition at line 463 of file fiff_file.h.
|
inlineconstexpr |
Measurement date.
Definition at line 448 of file fiff_file.h.
|
inlineconstexpr |
Program that modified the file (string).
Definition at line 328 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 643 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 648 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 649 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 646 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 647 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 661 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 656 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 655 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 654 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 653 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 639 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 637 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 636 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 641 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 640 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 638 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 651 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 663 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 635 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 650 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 658 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 659 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 644 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 645 of file fiff_file.h.
|
inlineconstexpr |
Intended to be a short name.
Definition at line 476 of file fiff_file.h.
|
inlineconstexpr |
Number of averages.
Definition at line 451 of file fiff_file.h.
|
inlineconstexpr |
Number of channels.
Definition at line 444 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 278 of file fiff_file.h.
|
inlineconstexpr |
Number of samples in an epoch.
Definition at line 472 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 322 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 324 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 323 of file fiff_file.h.
|
inlineconstexpr |
Tell that we are playing data back from the hard disks in the data acquisition front end.
Definition at line 293 of file fiff_file.h.
|
inlineconstexpr |
Projct description.
Definition at line 568 of file fiff_file.h.
|
inlineconstexpr |
Comment about the project. Special values used in the project tags.
Definition at line 570 of file fiff_file.h.
|
inlineconstexpr |
Project ID.
Definition at line 566 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 800 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 799 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 794 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 791 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 795 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 792 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 796 of file fiff_file.h.
|
inlineconstexpr |
Project name.
Definition at line 567 of file fiff_file.h.
|
inlineconstexpr |
Persons participating in the project.
Definition at line 569 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 288 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 287 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 335 of file fiff_file.h.
|
inlineconstexpr |
Reference event.
Definition at line 455 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 331 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 333 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 332 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 630 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 330 of file fiff_file.h.
|
inlineconstexpr |
Required event.
Definition at line 461 of file fiff_file.h.
|
inlineconstexpr |
Window for required event.
Definition at line 462 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 286 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 290 of file fiff_file.h.
|
inlineconstexpr |
Instruct rawdisp to select this channel.
Definition at line 292 of file fiff_file.h.
|
inlineconstexpr |
Sampling frequency (Hz).
Definition at line 445 of file fiff_file.h.
|
inlineconstexpr |
Signal channel name.
Definition at line 482 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 775 of file fiff_file.h.
|
inlineconstexpr |
Which coordinate frame are we using?
Definition at line 717 of file fiff_file.h.
|
inlineconstexpr |
Array of layer structures.
Definition at line 718 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 716 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 605 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 607 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 606 of file fiff_file.h.
|
inlineconstexpr |
DOUBLE matrix for SSS inside basis.
Definition at line 541 of file fiff_file.h.
|
inlineconstexpr |
DOUBLE matrix for SSS outside basis.
Definition at line 542 of file fiff_file.h.
|
inlineconstexpr |
DOUBLE matrix for SSS virtual basis.
Definition at line 543 of file fiff_file.h.
|
inlineconstexpr |
INT matrix (nmag x 2) for fine-calibrated channel numbers and types.
Definition at line 525 of file fiff_file.h.
|
inlineconstexpr |
FLOAT matrix (nmag x 14) for fine-calibration coefficients.
Definition at line 526 of file fiff_file.h.
|
inlineconstexpr |
Number of SSS moments.
Definition at line 524 of file fiff_file.h.
|
inlineconstexpr |
SSS coordinate frame.
Definition at line 518 of file fiff_file.h.
|
inlineconstexpr |
Nr of iterations in iterative SSS pseudo-inverse.
Definition at line 545 of file fiff_file.h.
|
inlineconstexpr |
SSS job.
Definition at line 519 of file fiff_file.h.
|
inlineconstexpr |
Number of MEG channels.
Definition at line 523 of file fiff_file.h.
|
inlineconstexpr |
Froebius norm of the inside basis.
Definition at line 544 of file fiff_file.h.
|
inlineconstexpr |
Order of the SSS inside expansion.
Definition at line 521 of file fiff_file.h.
|
inlineconstexpr |
Order of the SSS outside expansion.
Definition at line 522 of file fiff_file.h.
|
inlineconstexpr |
Origin of the SSS inside expansion.
Definition at line 520 of file fiff_file.h.
|
inlineconstexpr |
TSSS subspace correlation.
Definition at line 527 of file fiff_file.h.
|
inlineconstexpr |
A segment of data stream.
Definition at line 296 of file fiff_file.h.
|
inlineconstexpr |
The first epoch # contained in the subaverage.
Definition at line 475 of file fiff_file.h.
|
inlineconstexpr |
Size of a subaverage.
Definition at line 474 of file fiff_file.h.
|
inlineconstexpr |
Birthday of the subject.
Definition at line 558 of file fiff_file.h.
|
inlineconstexpr |
Comment about the subject.
Definition at line 563 of file fiff_file.h.
|
inlineconstexpr |
First name of the subject.
Definition at line 555 of file fiff_file.h.
|
inlineconstexpr |
Handedness of the subject.
Definition at line 560 of file fiff_file.h.
|
inlineconstexpr |
Height of the subject.
Definition at line 562 of file fiff_file.h.
|
inlineconstexpr |
ID used in the Hospital Information System.
Definition at line 564 of file fiff_file.h.
|
inlineconstexpr |
Subject ID.
Definition at line 554 of file fiff_file.h.
|
inlineconstexpr |
Last name of the subject.
Definition at line 557 of file fiff_file.h.
|
inlineconstexpr |
Middle name of the subject.
Definition at line 556 of file fiff_file.h.
|
inlineconstexpr |
Sex of the subject.
Definition at line 559 of file fiff_file.h.
|
inlineconstexpr |
Weight of the subject.
Definition at line 561 of file fiff_file.h.
|
inlineconstexpr |
This might be deleted later.
Definition at line 449 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 285 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 282 of file fiff_file.h.
|
inlineconstexpr |
Int_32[3] meas time stamp (sec,usec,sampleno).
Definition at line 552 of file fiff_file.h.
|
inlineconstexpr |
UTC offset of related meas_date (sHH:MM).
Definition at line 442 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 851 of file fiff_file.h.
|
inlineconstexpr |
Block size in bytes.
Definition at line 852 of file fiff_file.h.
|
inlineconstexpr |
Total # of blocks.
Definition at line 849 of file fiff_file.h.
|
inlineconstexpr |
Contents of the volume in a special format the data type will be FIFF_VOID.
Definition at line 853 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 850 of file fiff_file.h.
|
inlineconstexpr |
Where does the volume reside.
Definition at line 845 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 839 of file fiff_file.h.
|
inlineconstexpr |
Last mount point of the volume.
Definition at line 848 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 840 of file fiff_file.h.
|
inlineconstexpr |
User id of the owner.
Definition at line 841 of file fiff_file.h.
|
inlineconstexpr |
User name of the owner.
Definition at line 842 of file fiff_file.h.
|
inlineconstexpr |
User name of the owner.
Definition at line 843 of file fiff_file.h.
|
inlineconstexpr |
The root of the volume in in the machine where the file system is mounted.
Definition at line 846 of file fiff_file.h.
|
inlineconstexpr |
Symbolic link to the root of the volume (if any) system is mounted.
Definition at line 847 of file fiff_file.h.
|
inlineconstexpr |
See below...
Definition at line 844 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 784 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 785 of file fiff_file.h.
|
inlineconstexpr |
Xfit contour surface type.
Definition at line 786 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 781 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 783 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 779 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 780 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 782 of file fiff_file.h.
|
inlineconstexpr |
xplotter layout tag.
Definition at line 828 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 359 of file fiff_file.h.
|
inlineconstexpr |
Alias of FIFFB_MNE_BAD_CHANNELS.
Definition at line 406 of file fiff_file.h.
|
inlineconstexpr |
Boundary-element method.
Definition at line 394 of file fiff_file.h.
|
inlineconstexpr |
Boundary-element method surfaces.
Definition at line 395 of file fiff_file.h.
|
inlineconstexpr |
Cross-talk correction .
Definition at line 417 of file fiff_file.h.
|
inlineconstexpr |
One conductor model definition.
Definition at line 396 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 366 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 370 of file fiff_file.h.
|
inlineconstexpr |
Correction to data.
Definition at line 416 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 368 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 357 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 364 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 362 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 363 of file fiff_file.h.
|
inlineconstexpr |
HPI subsystem.
Definition at line 375 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 369 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 361 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 353 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 354 of file fiff_file.h.
|
inlineconstexpr |
MRI/CT data.
Definition at line 381 of file fiff_file.h.
|
inlineconstexpr |
Which are actually 3D scenes...
Definition at line 385 of file fiff_file.h.
|
inlineconstexpr |
These are for writing unrelated 'slices'.
Definition at line 384 of file fiff_file.h.
|
inlineconstexpr |
MRI segmentation data.
Definition at line 386 of file fiff_file.h.
|
inlineconstexpr |
One MRI segmentation region.
Definition at line 387 of file fiff_file.h.
|
inlineconstexpr |
MRI/CT volume.
Definition at line 382 of file fiff_file.h.
|
inlineconstexpr |
MRI/CT slice (image).
Definition at line 383 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 356 of file fiff_file.h.
|
inlineconstexpr |
Processing history block.
Definition at line 618 of file fiff_file.h.
|
inlineconstexpr |
Can contain several processing records.
Definition at line 619 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 365 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 355 of file fiff_file.h.
|
inlineconstexpr |
Fiff referencing mechanism.
Definition at line 371 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 352 of file fiff_file.h.
|
inlineconstexpr |
SmartShield data.
Definition at line 423 of file fiff_file.h.
|
inlineconstexpr |
SmartShield averaged data.
Definition at line 374 of file fiff_file.h.
|
inlineconstexpr |
SmartShield raw data.
Definition at line 373 of file fiff_file.h.
|
inlineconstexpr |
Concentric sphere model related.
Definition at line 393 of file fiff_file.h.
|
inlineconstexpr |
SSS bases.
Definition at line 421 of file fiff_file.h.
|
inlineconstexpr |
Fine-calibration adjustment data.
Definition at line 419 of file fiff_file.h.
|
inlineconstexpr |
SSS processing info.
Definition at line 418 of file fiff_file.h.
|
inlineconstexpr |
TSSS info.
Definition at line 420 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 360 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 367 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 411 of file fiff_file.h.
|
inlineconstexpr |
xfit saves its auxliary data into this block.
Definition at line 399 of file fiff_file.h.
|
inlineconstexpr |
xfit saves the linear projection information here.
Definition at line 397 of file fiff_file.h.
|
inlineconstexpr |
Each projection item goes here.
Definition at line 398 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 598 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 597 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 600 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 599 of file fiff_file.h.
|
inlineconstexpr |
Max value for FIFF_HPI_NCOIL.
Definition at line 484 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 210 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 250 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 211 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 230 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 220 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 238 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 242 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 236 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 235 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 243 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 246 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 232 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 233 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 234 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 241 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 244 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 240 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 224 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 223 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 239 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 222 of file fiff_file.h.
|
inlineconstexpr |
Julian day.
Definition at line 225 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 231 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 237 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 221 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 245 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 229 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 227 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 228 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 226 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 219 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 253 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 252 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 257 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 256 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 260 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 259 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 254 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 261 of file fiff_file.h.
|
inlineconstexpr |
Alternating subaverage.
Definition at line 433 of file fiff_file.h.
|
inlineconstexpr |
Normal average of epochs.
Definition at line 429 of file fiff_file.h.
|
inlineconstexpr |
Dipole amplitude curve.
Definition at line 436 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 626 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 625 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 624 of file fiff_file.h.
|
inlineconstexpr |
Power density spectrum.
Definition at line 435 of file fiff_file.h.
|
inlineconstexpr |
A sample cut out by graph.
Definition at line 434 of file fiff_file.h.
|
inlineconstexpr |
Single epoch cut out from the continuous data.
Definition at line 431 of file fiff_file.h.
|
inlineconstexpr |
Std. error of mean.
Definition at line 430 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 432 of file fiff_file.h.
|
inlineconstexpr |
The constant potential approach.
Definition at line 769 of file fiff_file.h.
|
inlineconstexpr |
The linear potential approach.
Definition at line 770 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 745 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 740 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 741 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 743 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 746 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 747 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 750 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 742 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 748 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 739 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 752 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 751 of file fiff_file.h.
|
inlineconstexpr |
The big-endian (Motorola) byte order.
Definition at line 890 of file fiff_file.h.
|
inlineconstexpr |
Multilayer BEM model.
Definition at line 714 of file fiff_file.h.
|
inlineconstexpr |
Homogeneous BEM model.
Definition at line 713 of file fiff_file.h.
|
inlineconstexpr |
Spherically symmetric.
Definition at line 712 of file fiff_file.h.
|
inlineconstexpr |
Not known.
Definition at line 711 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 301 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 304 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 303 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 302 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 580 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 579 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 578 of file fiff_file.h.
|
inlineconstexpr |
Following corresponsds to fields in channel info record.
Definition at line 504 of file fiff_file.h.
|
inlineconstexpr |
The fit was accepted by the software.
Definition at line 502 of file fiff_file.h.
|
inlineconstexpr |
The fit was accepted by user action.
Definition at line 503 of file fiff_file.h.
|
inlineconstexpr |
The little-endian (Intel) byte order.
Definition at line 889 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 686 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 687 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 685 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 679 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 684 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 678 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 680 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 682 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 683 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 681 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 677 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 688 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 700 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 693 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 697 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 698 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 699 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 696 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 695 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 692 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 694 of file fiff_file.h.
|
inlineconstexpr |
This refers to the byte order in the current system.
Definition at line 888 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 875 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 876 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 815 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 816 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 819 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 814 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 818 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 817 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 813 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 869 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 868 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 576 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 575 of file fiff_file.h.
|
inlineconstexpr |
Definition at line 574 of file fiff_file.h.
|
inlineconstexpr |
Only cross-talk correction.
Definition at line 530 of file fiff_file.h.
|
inlineconstexpr |
Spatial filtering (default).
Definition at line 531 of file fiff_file.h.
|
inlineconstexpr |
Estimate head positions, no movecomp.
Definition at line 533 of file fiff_file.h.
|
inlineconstexpr |
Estimate head positions, do movecomp.
Definition at line 534 of file fiff_file.h.
|
inlineconstexpr |
Do movecomp from prev estimated positions.
Definition at line 535 of file fiff_file.h.
|
inlineconstexpr |
Just copy input to output.
Definition at line 529 of file fiff_file.h.
|
inlineconstexpr |
Reconstruct fields from inside and outside moments.
Definition at line 536 of file fiff_file.h.
|
inlineconstexpr |
Reconstruct fields from inside moments.
Definition at line 537 of file fiff_file.h.
|
inlineconstexpr |
Reconstruct fields from outside moments.
Definition at line 538 of file fiff_file.h.
|
inlineconstexpr |
TSSS.
Definition at line 539 of file fiff_file.h.
|
inlineconstexpr |
Reconstruct virtual data.
Definition at line 532 of file fiff_file.h.
|
inlineconstexpr |
Hard disk.
Definition at line 882 of file fiff_file.h.
|
inlineconstexpr |
Magneto-optical disk.
Definition at line 883 of file fiff_file.h.
1.16.1
