imagesc.h File Reference

MATLAB-style false-colour heat-map widget for Eigen matrices. More...

#include "../disp_global.h"
#include "graph.h"
#include <Eigen/Core>

Include dependency graph for imagesc.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	DISPLIB::ImageSc
	False-colour heat-map QWidget visualising an Eigen matrix with selectable colour map. More...

Namespaces
namespace	DISPLIB
	2-D display widgets and visualisation helpers (charts, topography, colour maps).

Detailed Description

MATLAB-style false-colour heat-map widget for Eigen matrices.

SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2018-2026 MNE-CPP Authors

Author

Lorenz Esch loren.nosp@m.z.es.nosp@m.ch@tu.nosp@m.-ilm.nosp@m.enau..nosp@m.de; Juan GPC jgarc.nosp@m.iapr.nosp@m.ieto@.nosp@m.mgh..nosp@m.harva.nosp@m.rd.e.nosp@m.du; Gabriel Motta gabri.nosp@m.elbe.nosp@m.nmott.nosp@m.a@gm.nosp@m.ail.c.nosp@m.om; Christoph Dinh chris.nosp@m.toph.nosp@m..dinh.nosp@m.@mne.nosp@m.-cpp..nosp@m.org

Since

0.1.0

Date

July 2018

ImageSc visualises an Eigen::MatrixXd / MatrixXf / MatrixXi as a 2-D image, mapping the data range linearly into a selectable colour map (Jet, Hot, Bone, ...) through ColorMap. It inherits the title / axis-label scaffolding from Graph and is the canvas of choice for sensor-by-sample heat maps, covariance matrices and any other rectangular numeric field that benefits from a glance-able false-colour rendering. Calling ImageSc::updateData repaints the scaled view with new contents.

Definition in file imagesc.h.
