MNE-CPP  0.1.9
A Framework for Electrophysiology
Public Types | Signals | Public Member Functions | List of all members
DISPLIB::EvokedSetModel Class Reference

The EvokedSetModel class implements the data access model for evoked set data. More...

#include <evokedsetmodel.h>

Public Types

typedef QSharedPointer< EvokedSetModelSPtr

typedef QSharedPointer< const EvokedSetModelConstSPtr


Signals

void newSelection (QList< qint32 > selection)

void newAverageColorMap (const QSharedPointer< QMap< QString, QColor > > qMapAverageColor)

void newAverageActivationMap (const QSharedPointer< QMap< QString, bool > > qMapAverageActivation)


Public Member Functions

 EvokedSetModel (QObject *parent=0)

bool isInit () const

qint32 getNumSamples () const

virtual int rowCount (const QModelIndex &parent=QModelIndex()) const

virtual int columnCount (const QModelIndex &parent=QModelIndex()) const

QVariant data (int row, int column, int role=Qt::DisplayRole) const

virtual QVariant data (const QModelIndex &index, int role=Qt::DisplayRole) const

virtual QVariant headerData (int section, Qt::Orientation orientation, int role=Qt::DisplayRole) const

void init ()

void setEvokedSet (QSharedPointer< FIFFLIB::FiffEvokedSet > pEvokedSet)

QSharedPointer< FIFFLIB::FiffEvokedSetgetEvokedSet ()

void updateData ()

QSharedPointer< QMap< QString, QColor > > getAverageColor () const

QSharedPointer< QMap< QString, bool > > getAverageActivation () const

void setAverageColor (const QSharedPointer< QMap< QString, QColor > > qMapAverageColor)

void setAverageActivation (const QSharedPointer< QMap< QString, bool > > qMapAverageActivation)

FIFFLIB::fiff_int_t getKind (qint32 row) const

bool getIsChannelBad (qint32 row) const

FIFFLIB::fiff_int_t getUnit (qint32 row) const

FIFFLIB::fiff_int_t getCoil (qint32 row) const

const QMap< qint32, qint32 > & getIdxSelMap () const

int getNumberOfTimeSpacers () const

QPair< QVariant, QVariant > getBaselineInfo () const

int getNumAverages () const

qint32 getNumPreStimSamples () const

float getSamplingFrequency () const

void selectRows (const QList< qint32 > &selection)

void resetSelection ()

qint32 numVLines () const

bool isFreezed () const

void updateProjection (const QList< FIFFLIB::FiffProj > &projs)

void updateCompensator (int to)

void toggleFreeze ()


Detailed Description

The EvokedSetModel class implements the data access model for evoked set data.

DECLARE CLASS EvokedSetModel

Definition at line 101 of file evokedsetmodel.h.

Inheritance diagram for DISPLIB::EvokedSetModel:
Inheritance graph

Member Typedef Documentation

◆ ConstSPtr

typedef QSharedPointer<const EvokedSetModel> DISPLIB::EvokedSetModel::ConstSPtr

Const shared pointer type for EvokedSetModel.

Definition at line 107 of file evokedsetmodel.h.

◆ SPtr

Shared pointer type for EvokedSetModel.

Definition at line 106 of file evokedsetmodel.h.

Constructor & Destructor Documentation

◆ EvokedSetModel()

EvokedSetModel::EvokedSetModel ( QObject *  parent = 0)

Constructs an real-time multi sample array table model for the given parent.

Parameters
[in]parentparent of the table model.

Definition at line 70 of file evokedsetmodel.cpp.

Member Function Documentation

◆ columnCount()

int EvokedSetModel::columnCount ( const QModelIndex &  parent = QModelIndex()) const
virtual

Returns the number of columns for the children of the given parent.

Parameters
[in]parentnot used.
Returns
number of columns.

Definition at line 103 of file evokedsetmodel.cpp.

◆ data() [1/2]

QVariant EvokedSetModel::data ( int  row,
int  column,
int  role = Qt::DisplayRole
) const

Data for the row and column and given display role

Parameters
[in]rowindex row.
[in]columnindex column.
[in]roledisplay role to access.
Returns
the accessed data.

Definition at line 506 of file evokedsetmodel.cpp.

◆ data() [2/2]

QVariant EvokedSetModel::data ( const QModelIndex &  index,
int  role = Qt::DisplayRole
) const
virtual

Returns the data stored under the given role for the item referred to by the index.

Parameters
[in]indexdetermines item location.
[in]rolerole to return.
Returns
accessed data.

Definition at line 110 of file evokedsetmodel.cpp.

◆ getAverageActivation()

QSharedPointer< QMap< QString, bool > > EvokedSetModel::getAverageActivation ( ) const

Get the current average activations

Returns
Pointer to the current average activations.

Definition at line 415 of file evokedsetmodel.cpp.

◆ getAverageColor()

QSharedPointer< QMap< QString, QColor > > EvokedSetModel::getAverageColor ( ) const

Get the current average colors

Returns
Pointer to the current average colors.

Definition at line 408 of file evokedsetmodel.cpp.

◆ getBaselineInfo()

QPair< QVariant, QVariant > EvokedSetModel::getBaselineInfo ( ) const

Returns the current baseline information

Returns
the current baseline information as a from to QPair.

Definition at line 587 of file evokedsetmodel.cpp.

◆ getCoil()

fiff_int_t EvokedSetModel::getCoil ( qint32  row) const

Returns the coil type of a given channel number

Parameters
[in]rowrow number which correspodns to a given channel.
Returns
coil type of given channel number.

Definition at line 474 of file evokedsetmodel.cpp.

◆ getIdxSelMap()

const QMap< qint32, qint32 > & EvokedSetModel::getIdxSelMap ( ) const

Returns a map which conatins the channel idx and its corresponding selection status

Returns
the channel idx to selection status.

Definition at line 513 of file evokedsetmodel.cpp.

◆ getIsChannelBad()

bool EvokedSetModel::getIsChannelBad ( qint32  row) const

Returns true or fals whether the provided channel is bad.

Parameters
[in]rowrow number which correspodns to a given channel.
Returns
Returns true or fals whether the provided channel is bad.

Definition at line 448 of file evokedsetmodel.cpp.

◆ getKind()

fiff_int_t EvokedSetModel::getKind ( qint32  row) const

Returns the kind of a given channel number

Parameters
[in]rowrow number which correspodns to a given channel.
Returns
kind of given channel number.

Definition at line 436 of file evokedsetmodel.cpp.

◆ getNumAverages()

int EvokedSetModel::getNumAverages ( ) const

Returns the current number of stored averages

Returns
the current number of stored averages.

Definition at line 595 of file evokedsetmodel.cpp.

◆ getNumberOfTimeSpacers()

int EvokedSetModel::getNumberOfTimeSpacers ( ) const

Returns the current number for the time spacers

Returns
the current number for the time spacers.

Definition at line 573 of file evokedsetmodel.cpp.

◆ getNumPreStimSamples()

qint32 EvokedSetModel::getNumPreStimSamples ( ) const

Returns the number of pre-stimulus samples

Returns
the number of pre-stimulus samples.

Definition at line 533 of file evokedsetmodel.cpp.

◆ getNumSamples()

qint32 EvokedSetModel::getNumSamples ( ) const

Returns the number of samples.

Returns
The number of samples.

Definition at line 493 of file evokedsetmodel.cpp.

◆ getSamplingFrequency()

float EvokedSetModel::getSamplingFrequency ( ) const

Returns the current sampling frequency

Returns
the current sampling frequency.

Definition at line 559 of file evokedsetmodel.cpp.

◆ getUnit()

fiff_int_t EvokedSetModel::getUnit ( qint32  row) const

Returns the unit of a given channel number

Parameters
[in]rowrow number which correspodns to a given channel.
Returns
unit of given channel number.

Definition at line 462 of file evokedsetmodel.cpp.

◆ headerData()

QVariant EvokedSetModel::headerData ( int  section,
Qt::Orientation  orientation,
int  role = Qt::DisplayRole
) const
virtual

Returns the data for the given role and section in the header with the specified orientation.

Parameters
[in]sectionFor horizontal headers, the section number corresponds to the column number. Similarly, for vertical headers, the section number corresponds to the row number.
[in]orientationQt::Horizontal or Qt::Vertical.
[in]rolerole to show.
Returns
accessed eader data.

Definition at line 214 of file evokedsetmodel.cpp.

◆ isFreezed()

bool EvokedSetModel::isFreezed ( ) const

Returns current freezing status

Returns
the current freezing status.

Definition at line 566 of file evokedsetmodel.cpp.

◆ isInit()

bool EvokedSetModel::isInit ( ) const

Returns whether this class is initalized.

Returns
Flag specifying whether this class is initalized.

Definition at line 486 of file evokedsetmodel.cpp.

◆ newAverageActivationMap

void DISPLIB::EvokedSetModel::newAverageActivationMap ( const QSharedPointer< QMap< QString, bool > >  qMapAverageActivation)
signal

Emmited when new average activation is available

Parameters
[in]qMapAverageActivationthe average activation map.

◆ newAverageColorMap

void DISPLIB::EvokedSetModel::newAverageColorMap ( const QSharedPointer< QMap< QString, QColor > >  qMapAverageColor)
signal

Emmited when new average color is available

Parameters
[in]qMapAverageColorthe average color map.

◆ newSelection

void DISPLIB::EvokedSetModel::newSelection ( QList< qint32 >  selection)
signal

Emmited when new selcetion was made

Parameters
[in]selectionlist of all selected channels.

◆ numVLines()

qint32 EvokedSetModel::numVLines ( ) const

Returns the number of vertical lines (one per second)

Returns
number of vertical lines.

Definition at line 520 of file evokedsetmodel.cpp.

◆ resetSelection()

void EvokedSetModel::resetSelection ( )

Resets the current selection (selects all channels)

Definition at line 627 of file evokedsetmodel.cpp.

◆ rowCount()

int EvokedSetModel::rowCount ( const QModelIndex &  parent = QModelIndex()) const
virtual

Returns the number of rows under the given parent. When the parent is valid it means that rowCount is returning the number of children of parent.

Parameters
[in]parentnot used.
Returns
number of rows.

Definition at line 92 of file evokedsetmodel.cpp.

◆ selectRows()

void EvokedSetModel::selectRows ( const QList< qint32 > &  selection)

Selects the given list of channel indeces and unselect all other channels

Parameters
[in]selectionchannel index list to select.

Definition at line 602 of file evokedsetmodel.cpp.

◆ setAverageActivation()

void EvokedSetModel::setAverageActivation ( const QSharedPointer< QMap< QString, bool > >  qMapAverageActivation)

Set the average activations

Parameters
[in]qMapAverageActivationPointer to the new average activations.

Definition at line 429 of file evokedsetmodel.cpp.

◆ setAverageColor()

void EvokedSetModel::setAverageColor ( const QSharedPointer< QMap< QString, QColor > >  qMapAverageColor)

Set the average colors

Parameters
[in]qMapAverageColorPointer to the new average colors.

Definition at line 422 of file evokedsetmodel.cpp.

◆ setEvokedSet()

void EvokedSetModel::setEvokedSet ( QSharedPointer< FIFFLIB::FiffEvokedSet pEvokedSet)

Sets corresponding evoked set

Parameters
[in]pEvokedSetThe evoked set.

Definition at line 247 of file evokedsetmodel.cpp.

◆ toggleFreeze()

void EvokedSetModel::toggleFreeze ( )

Toggle freeze for all channels when a channel is double clicked

Definition at line 774 of file evokedsetmodel.cpp.

◆ updateCompensator()

void EvokedSetModel::updateCompensator ( int  to)

Update the compensator

Parameters
[in]toCompensator to use in fiff constant format FiffCtfComp.kind (NOT FiffCtfComp.ctfkind).

Definition at line 715 of file evokedsetmodel.cpp.

◆ updateData()

void EvokedSetModel::updateData ( )

Update stored data

Definition at line 308 of file evokedsetmodel.cpp.

◆ updateProjection()

void EvokedSetModel::updateProjection ( const QList< FIFFLIB::FiffProj > &  projs)

Update projections

Definition at line 646 of file evokedsetmodel.cpp.


The documentation for this class was generated from the following files:
