kmeans.h File Reference

K-means partitional clustering with multiple distance metrics, initialisations and empty-cluster policies. More...

#include "math_global.h"
#include <random>
#include <string>
#include <QSharedPointer>
#include <Eigen/Core>

Include dependency graph for kmeans.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	UTILSLIB::KMeans
	Lloyd-style K-means clustering with configurable metric, seeding and replicates. More...

Namespaces
namespace	UTILSLIB
	Shared utilities (I/O helpers, spectral analysis, layout management, warp algorithms).

Enumerations
enum class	UTILSLIB::KMeansDistance {   UTILSLIB::SquaredEuclidean , UTILSLIB::CityBlock , UTILSLIB::Cosine , UTILSLIB::Correlation ,   UTILSLIB::Hamming }
	Distance metric for K-Means clustering. More...
enum class	UTILSLIB::KMeansStart { UTILSLIB::Sample , UTILSLIB::Uniform , UTILSLIB::Cluster }
	Initialization strategy for K-Means clustering. More...
enum class	UTILSLIB::KMeansEmptyAction { UTILSLIB::Error , UTILSLIB::Drop , UTILSLIB::Singleton }
	Action to take when a K-Means cluster becomes empty. More...

Detailed Description

K-means partitional clustering with multiple distance metrics, initialisations and empty-cluster policies.

SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2026 MNE-CPP Authors

Author

Christoph Dinh chris.nosp@m.toph.nosp@m..dinh.nosp@m.@mne.nosp@m.-cpp..nosp@m.org

Since

2.0.0

Date

March 2026

Lloyd-style K-means partitions n p-dimensional samples into k clusters by alternating an assignment step (each point goes to the nearest centroid under the selected metric) with an update step (centroid ← mean of its members) until the total within-cluster distortion stops decreasing or the iteration cap is hit. Per-iteration cost is O(n*k*p), which dominates everything else in MATHLIB and makes the algorithm suitable for the cortical-patch decimation and dipole-cluster prior workflows that consume it inside INVERSELIB.

The implementation mirrors MATLAB's kmeans/kmeans2 in feature set: five distance metrics (squared Euclidean, city-block, cosine, correlation, Hamming) selectable via KMeansDistance, three seeding strategies (random sample, uniform within data range, subsample-then-cluster) via KMeansStart, multiple replicates with best-of selection, and three empty-cluster policies (error, drop, singleton-from-farthest-point) via KMeansEmptyAction. An optional online update phase performs single-point Lloyd moves after the batch loop converges and is enabled by default to escape shallow local minima.

Reference: Lloyd (1982) "Least squares quantization in PCM"; Arthur & Vassilvitskii (2007) for the seeding intuition.

Definition in file kmeans.h.
