Coordinate transformation descriptor. More...

#include <fiff_coord_trans_old.h>

Public Types
typedef QSharedPointer< FiffCoordTransOld >	SPtr
typedef QSharedPointer< const FiffCoordTransOld >	ConstSPtr

Public Member Functions
	FiffCoordTransOld ()
	FiffCoordTransOld (const FiffCoordTransOld &p_FiffCoordTransOld)
	FiffCoordTransOld (int from, int to, float rot[3][3], float move[3])
	~FiffCoordTransOld ()
FiffCoordTrans	toNew ()
FiffCoordTransOld *	fiff_invert_transform () const

Static Public Member Functions
static FiffCoordTransOld *	catenate (FiffCoordTransOld t1, FiffCoordTransOld t2)
static int	add_inverse (FiffCoordTransOld *t)
static void	fiff_coord_trans (float r[3], const FiffCoordTransOld *t, int do_move)
static FiffCoordTransOld *	fiff_combine_transforms (int from, int to, FiffCoordTransOld t1, FiffCoordTransOld t2)
static void	fiff_coord_trans_inv (float r[3], FiffCoordTransOld *t, int do_move)
static const char *	mne_coord_frame_name (int frame)
static void	mne_print_coord_transform_label (FILE log, char label, FiffCoordTransOld *t)
static void	mne_print_coord_transform (FILE log, FiffCoordTransOld t)
static FiffCoordTransOld *	mne_read_transform (const QString &name, int from, int to)
static FiffCoordTransOld *	mne_read_transform_from_node (FIFFLIB::FiffStream::SPtr &stream, const FIFFLIB::FiffDirNode::SPtr &node, int from, int to)
static FiffCoordTransOld *	mne_read_mri_transform (const QString &name)
static FiffCoordTransOld *	mne_read_meas_transform (const QString &name)
static FiffCoordTransOld *	mne_read_transform_ascii (char *name, int from, int to)
static FiffCoordTransOld *	mne_read_FShead2mri_transform (char *name)
static FiffCoordTransOld *	mne_identity_transform (int from, int to)
static FiffCoordTransOld *	fiff_make_transform_card (int from, int to, float rL, float rN, float *rR)
static FiffCoordTransOld *	procrustes_align (int from_frame, int to_frame, float fromp, float top, float *w, int np, float max_diff)
static FiffCoordTransOld *	read_helper (QSharedPointer< FIFFLIB::FiffTag > &tag)

Public Attributes
FIFFLIB::fiff_int_t	from
FIFFLIB::fiff_int_t	to
Eigen::Matrix3f	rot
Eigen::Vector3f	move
Eigen::Matrix3f	invrot
Eigen::Vector3f	invmove

Friends
bool	operator== (const FiffCoordTransOld &a, const FiffCoordTransOld &b)

Detailed Description

Coordinate transformation descriptor.

Implements an Fiff Coordinate Descriptor (Replaces *fiffCoordTrans, fiffCoordTransRec; struct of MNE-C fiff_types.h).

Definition at line 80 of file fiff_coord_trans_old.h.

Member Typedef Documentation

◆ ConstSPtr

typedef QSharedPointer<const FiffCoordTransOld> FIFFLIB::FiffCoordTransOld::ConstSPtr

Const shared pointer type for FiffCoordTransOld.

Definition at line 84 of file fiff_coord_trans_old.h.

◆ SPtr

typedef QSharedPointer<FiffCoordTransOld> FIFFLIB::FiffCoordTransOld::SPtr

Shared pointer type for FiffCoordTransOld.

Definition at line 83 of file fiff_coord_trans_old.h.

Constructor & Destructor Documentation

◆ FiffCoordTransOld() [1/3]

FiffCoordTransOld::FiffCoordTransOld ( )

Constructs the FiffCoordTransOld

Definition at line 347 of file fiff_coord_trans_old.cpp.

◆ FiffCoordTransOld() [2/3]

FiffCoordTransOld::FiffCoordTransOld ( const FiffCoordTransOld & p_FiffCoordTransOld )

Copy constructor. Refactored: fiff_dup_transform (fiff_trans.c)

Parameters

[in] p_FiffCoordTransOld FiffCoordTransOld which should be copied.

Definition at line 353 of file fiff_coord_trans_old.cpp.

◆ FiffCoordTransOld() [3/3]

FiffCoordTransOld::FiffCoordTransOld	(	int	from,
		int	to,
		float	rot[3][3],
		float	move[3] )

Compose the coordinate transformation structure from a known forward transform Refactored: fiff_make_transform (make_volume_source_space.c)

Definition at line 393 of file fiff_coord_trans_old.cpp.

◆ ~FiffCoordTransOld()

FiffCoordTransOld::~FiffCoordTransOld ( )

Destroys the FiffCoordTransOld Refactored: (.c)

Definition at line 408 of file fiff_coord_trans_old.cpp.

Member Function Documentation

◆ add_inverse()

int FiffCoordTransOld::add_inverse ( FiffCoordTransOld * t )

static

Definition at line 429 of file fiff_coord_trans_old.cpp.

◆ catenate()

FiffCoordTransOld * FiffCoordTransOld::catenate	(	FiffCoordTransOld *	t1,
		FiffCoordTransOld *	t2 )

static

Definition at line 370 of file fiff_coord_trans_old.cpp.

◆ fiff_combine_transforms()

FiffCoordTransOld * FiffCoordTransOld::fiff_combine_transforms	(	int	from,
		int	to,
		FiffCoordTransOld *	t1,
		FiffCoordTransOld *	t2 )

static

Definition at line 479 of file fiff_coord_trans_old.cpp.

◆ fiff_coord_trans()

void FiffCoordTransOld::fiff_coord_trans	(	float	r[3],
		const FiffCoordTransOld *	t,
		int	do_move )

static

Definition at line 460 of file fiff_coord_trans_old.cpp.

◆ fiff_coord_trans_inv()

void FiffCoordTransOld::fiff_coord_trans_inv	(	float	r[3],
		FiffCoordTransOld *	t,
		int	do_move )

static

Definition at line 544 of file fiff_coord_trans_old.cpp.

◆ fiff_invert_transform()

FiffCoordTransOld * FiffCoordTransOld::fiff_invert_transform ( ) const

Definition at line 446 of file fiff_coord_trans_old.cpp.

◆ fiff_make_transform_card()

FiffCoordTransOld * FiffCoordTransOld::fiff_make_transform_card	(	int	from,
		int	to,
		float *	rL,
		float *	rN,
		float *	rR )

static

Definition at line 832 of file fiff_coord_trans_old.cpp.

◆ mne_coord_frame_name()

const char * FiffCoordTransOld::mne_coord_frame_name ( int frame )

static

Definition at line 573 of file fiff_coord_trans_old.cpp.

◆ mne_identity_transform()

FiffCoordTransOld * FiffCoordTransOld::mne_identity_transform	(	int	from,
		int	to )

static

Definition at line 821 of file fiff_coord_trans_old.cpp.

◆ mne_print_coord_transform()

void FiffCoordTransOld::mne_print_coord_transform	(	FILE *	log,
		FiffCoordTransOld *	t )

static

Definition at line 628 of file fiff_coord_trans_old.cpp.

◆ mne_print_coord_transform_label()

void FiffCoordTransOld::mne_print_coord_transform_label	(	FILE *	log,
		char *	label,
		FiffCoordTransOld *	t )

static

Definition at line 603 of file fiff_coord_trans_old.cpp.

◆ mne_read_FShead2mri_transform()

FiffCoordTransOld * FiffCoordTransOld::mne_read_FShead2mri_transform ( char * name )

static

Definition at line 814 of file fiff_coord_trans_old.cpp.

◆ mne_read_meas_transform()

FiffCoordTransOld * FiffCoordTransOld::mne_read_meas_transform ( const QString & name )

static

Definition at line 752 of file fiff_coord_trans_old.cpp.

◆ mne_read_mri_transform()

FiffCoordTransOld * FiffCoordTransOld::mne_read_mri_transform ( const QString & name )

static

Definition at line 742 of file fiff_coord_trans_old.cpp.

◆ mne_read_transform()

FiffCoordTransOld * FiffCoordTransOld::mne_read_transform	(	const QString &	name,
		int	from,
		int	to )

static

Definition at line 635 of file fiff_coord_trans_old.cpp.

◆ mne_read_transform_ascii()

FiffCoordTransOld * FiffCoordTransOld::mne_read_transform_ascii	(	char *	name,
		int	from,
		int	to )

static

Definition at line 762 of file fiff_coord_trans_old.cpp.

◆ mne_read_transform_from_node()

FiffCoordTransOld * FiffCoordTransOld::mne_read_transform_from_node	(	FIFFLIB::FiffStream::SPtr &	stream,
		const FIFFLIB::FiffDirNode::SPtr &	node,
		int	from,
		int	to )

static

Definition at line 696 of file fiff_coord_trans_old.cpp.

◆ procrustes_align()

FiffCoordTransOld * FiffCoordTransOld::procrustes_align	(	int	from_frame,
		int	to_frame,
		float **	fromp,
		float **	top,
		float *	w,
		int	np,
		float	max_diff )

static

Definition at line 885 of file fiff_coord_trans_old.cpp.

◆ read_helper()

FiffCoordTransOld * FiffCoordTransOld::read_helper ( QSharedPointer< FIFFLIB::FiffTag > & tag )

static

Definition at line 1013 of file fiff_coord_trans_old.cpp.

◆ toNew()

FiffCoordTrans FiffCoordTransOld::toNew ( )

Definition at line 414 of file fiff_coord_trans_old.cpp.

◆ operator==

bool operator==	(	const FiffCoordTransOld &	a,
		const FiffCoordTransOld &	b )

friend

Overloaded == operator to compare an object to this instance.

Parameters

[in] object The object which should be compared to.

Returns: true if equal, false otherwise.

Definition at line 217 of file fiff_coord_trans_old.h.

Member Data Documentation

◆ from

FIFFLIB::fiff_int_t FIFFLIB::FiffCoordTransOld::from

Source coordinate system.

Definition at line 195 of file fiff_coord_trans_old.h.

◆ invmove

Eigen::Vector3f FIFFLIB::FiffCoordTransOld::invmove

The inverse transform (translation part).

Definition at line 200 of file fiff_coord_trans_old.h.

◆ invrot

Eigen::Matrix3f FIFFLIB::FiffCoordTransOld::invrot

The inverse transform (rotation part).

Definition at line 199 of file fiff_coord_trans_old.h.

◆ move

Eigen::Vector3f FIFFLIB::FiffCoordTransOld::move

The forward transform (translation part).

Definition at line 198 of file fiff_coord_trans_old.h.

◆ rot

Eigen::Matrix3f FIFFLIB::FiffCoordTransOld::rot

The forward transform (rotation part).

Definition at line 197 of file fiff_coord_trans_old.h.

◆ to

FIFFLIB::fiff_int_t FIFFLIB::FiffCoordTransOld::to

Destination coordinate system.

Definition at line 196 of file fiff_coord_trans_old.h.

The documentation for this class was generated from the following files:

src/libraries/fiff/c/fiff_coord_trans_old.h
src/libraries/fiff/c/fiff_coord_trans_old.cpp
