firfilter.h File Reference

Discoverable design / apply façade over the FilterKernel FIR engine. More...

#include "dsp_global.h"
#include "filterkernel.h"
#include <Eigen/Core>

Include dependency graph for firfilter.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	UTILSLIB::FirFilter
	Discoverable façade over the FilterKernel FIR-filter engine. More...

Namespaces
namespace	UTILSLIB
	Shared utilities (I/O helpers, spectral analysis, layout management, warp algorithms).

Detailed Description

Discoverable design / apply façade over the FilterKernel FIR engine.

SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2026 MNE-CPP Authors

Author

Christoph Dinh chris.nosp@m.toph.nosp@m..dinh.nosp@m.@mne.nosp@m.-cpp..nosp@m.org

Since

2.1.0

Date

March 2026

FirFilter mirrors the IirFilter API surface (design, apply, applyZeroPhase, applyZeroPhaseMatrix) so callers see one consistent way of building and running FIR or IIR filters in mne-cpp. Internally every call delegates to FilterKernel, which executes the actual frequency-domain overlap-add convolution against the precomputed FFT of the impulse response.

All cutoff / bandwidth parameters are specified in Hz; normalisation against the sampling frequency happens inside the design step. Because the underlying kernels are linear-phase Type-I FIRs, the zero-phase helpers simply remove the deterministic (NumTaps-1)/2 group delay after a single forward pass — no forward / backward filtering is required.

Definition in file firfilter.h.
