Lab Streaming Layer (LSL) integration for real-time data exchange. More...

Classes
class	stream_info
	Value-type descriptor of a single LSL stream: semantic metadata plus transport endpoint, API-compatible with liblsl's stream_info. More...
class	StreamInletPrivate
class	stream_inlet
	Client-side LSL endpoint: connects to a resolved outlet over TCP and exposes pulled samples as float chunks. More...
class	StreamOutletPrivate
class	stream_outlet
	Server-side LSL endpoint: binds a TCP data server, advertises the stream on the LSL discovery multicast group, and fans samples out to every connected inlet. More...

Enumerations
enum class	ChannelFormat : int { Undefined = 0 , Float32 = 1 , Double64 = 2 , String = 3 , Int32 = 4 , Int16 = 5 , Int8 = 6 , Int64 = 7 }

Functions
const char *	buildDateTime ()
const char *	buildHash ()
const char *	buildHashLong ()
std::vector< stream_info >	resolve_streams (double timeout=1.0)
	Resolve all streams currently available on the network.
std::vector< stream_info >	resolve_stream (const std::string &prop, const std::string &value, double timeout=1.0)
	Resolve streams by a specific property value.

Detailed Description

Lab Streaming Layer (LSL) integration for real-time data exchange.

Enumeration Type Documentation

◆ ChannelFormat

enum class LSLLIB::ChannelFormat : int

strong

Data format of a channel (mirroring the values used in the original LSL protocol).

Enumerator
Undefined	Undefined format.
Float32	32-bit IEEE 754 floating point.
Double64	64-bit IEEE 754 floating point.
String	Variable-length string.
Int32	32-bit signed integer.
Int16	16-bit signed integer.
Int8	8-bit signed integer.
Int64	64-bit signed integer.

Definition at line 59 of file lsl_stream_info.h.

Function Documentation

◆ buildDateTime()

const char * LSLLIB::buildDateTime ( )

Returns build date and time.

Definition at line 32 of file lsl_global.cpp.

◆ buildHash()

const char * LSLLIB::buildHash ( )

Returns abbreviated build git hash.

Definition at line 36 of file lsl_global.cpp.

◆ buildHashLong()

const char * LSLLIB::buildHashLong ( )

Returns full build git hash.

Definition at line 40 of file lsl_global.cpp.

◆ resolve_stream()

std::vector< LSLLIB::stream_info > LSLLIB::resolve_stream	(	const std::string &	prop,
		const std::string &	value,
		double	timeout = 1.0 )

Resolve streams by a specific property value.

Listens on the UDP multicast discovery channel and returns only streams whose specified property matches the given value.

Parameters

[in]	prop	The stream property to match (e.g. "name", "type", "source_id").
[in]	value	The value that the property must have.
[in]	timeout	Duration (in seconds) to listen for stream announcements. Default: 1.0.

Returns: A vector of matching stream_info objects.

Definition at line 149 of file lsl_stream_discovery.cpp.

◆ resolve_streams()

std::vector< LSLLIB::stream_info > LSLLIB::resolve_streams ( double timeout = 1.0 )

Resolve all streams currently available on the network.

Listens on the UDP multicast discovery channel for stream announcements from outlets. This call blocks for the specified timeout duration while collecting results.

Parameters

[in] timeout Duration (in seconds) to listen for stream announcements. Default: 1.0.

Returns: A vector of stream_info objects for all discovered streams.

Definition at line 68 of file lsl_stream_discovery.cpp.
