INVLIB::InvDICS Class Reference

DICS beamformer (frequency-domain). More...

#include <inv_dics.h>

Static Public Member Functions
static InvBeamformer	makeDICS (const FIFFLIB::FiffInfo &info, const MNELIB::MNEForwardSolution &forward, const std::vector< Eigen::MatrixXd > &csdMatrices, const Eigen::VectorXd &frequencies, double reg=0.05, bool realFilter=true, const FIFFLIB::FiffCov &noiseCov=FIFFLIB::FiffCov(), BeamformerPickOri pickOri=BeamformerPickOri::None, BeamformerWeightNorm weightNorm=BeamformerWeightNorm::UnitNoiseGain, bool reduceRank=false, BeamformerInversion invMethod=BeamformerInversion::Matrix)
static InvSourceEstimate	applyDICSCsd (const std::vector< Eigen::MatrixXd > &csdMatrices, const Eigen::VectorXd &frequencies, const InvBeamformer &filters)
static InvSourceEstimate	applyDICS (const Eigen::MatrixXd &data, float tmin, float tstep, const InvBeamformer &filters, int freqIdx=0)

Detailed Description

DICS beamformer (frequency-domain).

Dynamic Imaging of Coherent Sources (DICS) beamformer for frequency-domain source localization using cross-spectral density (CSD) matrices.

Typical workflow:

// 1. Compute CSD matrices for frequency bands of interest (externally)
//    csdMatrices[i] = CSD at frequency[i], shape (n_channels, n_channels)

// 2. Build the DICS spatial filter
InvBeamformer filters = InvDICS::makeDICS(info, forward, csdMatrices, frequencies,
                                           reg, realFilter, pickOri, weightNorm);

// 3. Apply to CSD to get source power per frequency
InvSourceEstimate power = InvDICS::applyDICSCsd(csdMatrices, frequencies, filters);

Definition at line 98 of file inv_dics.h.

Member Function Documentation

applyDICS()

InvSourceEstimate InvDICS::applyDICS ( const Eigen::MatrixXd & data, float tmin, float tstep, const InvBeamformer & filters, int freqIdx = 0 )

static

Apply DICS beamformer to time-domain data at a single frequency.

This is an approximate application — for accurate frequency-domain source estimation, use applyDICSCsd() with CSD matrices.

Parameters

[in]	data	Data matrix (n_channels, n_times).
[in]	tmin	Start time (s).
[in]	tstep	Time step (s).
[in]	filters	Pre-computed DICS beamformer (must have exactly 1 frequency).
[in]	freqIdx	Index of the frequency filter to use (default 0).

Returns

Source time-course estimate.

Definition at line 264 of file inv_dics.cpp.

applyDICSCsd()

InvSourceEstimate InvDICS::applyDICSCsd ( const std::vector< Eigen::MatrixXd > & csdMatrices, const Eigen::VectorXd & frequencies, const InvBeamformer & filters )

static

Apply DICS beamformer to CSD matrices to estimate source power per frequency.

power_i(f) = trace(W_f_i @ CSD_f @ W_f_i^T)

Parameters

[in]	csdMatrices	CSD matrices (one per frequency).
[in]	frequencies	Center frequencies (Hz).
[in]	filters	Pre-computed DICS beamformer from makeDICS().

Returns

Source estimate where data has shape (n_sources, n_freqs) with power values.

Definition at line 211 of file inv_dics.cpp.

makeDICS()

InvBeamformer InvDICS::makeDICS ( const FIFFLIB::FiffInfo & info, const MNELIB::MNEForwardSolution & forward, const std::vector< Eigen::MatrixXd > & csdMatrices, const Eigen::VectorXd & frequencies, double reg = 0.05, bool realFilter = true, const FIFFLIB::FiffCov & noiseCov = FIFFLIB::FiffCov(), BeamformerPickOri pickOri = BeamformerPickOri::None, BeamformerWeightNorm weightNorm = BeamformerWeightNorm::UnitNoiseGain, bool reduceRank = false, BeamformerInversion invMethod = BeamformerInversion::Matrix )

static

Compute DICS beamformer spatial filters for one or more frequencies.

Parameters

[in]	info	Measurement info.
[in]	forward	Forward solution containing the leadfield.
[in]	csdMatrices	Cross-spectral density matrices, one per frequency bin. Each is (n_channels, n_channels), may be complex.
[in]	frequencies	Center frequency (Hz) for each CSD matrix.
[in]	reg	Regularization parameter (default 0.05).
[in]	realFilter	If true, take real part of CSD before computing filter (default true).
[in]	noiseCov	Noise covariance for whitening. If empty, identity whitening.
[in]	pickOri	Orientation selection mode.
[in]	weightNorm	Weight normalization strategy.
[in]	reduceRank	Reduce leadfield rank by 1.
[in]	invMethod	Denominator inversion method.

Returns

Beamformer with one filter weight matrix per frequency.

Definition at line 67 of file inv_dics.cpp.

---

The documentation for this class was generated from the following files:

• src/libraries/inv/beamformer/inv_dics.h
• src/libraries/inv/beamformer/inv_dics.cpp
