DISP3DLIB Namespace Reference

3-D brain visualisation using the Qt RHI rendering backend. More...

Classes
class	GeometryInfo
	This class holds static methods for sensor-to-mesh mapping and surface constrained distance calculation on a mesh. More...
class	Interpolation
	This class holds methods for creating distance-based weight matrices and for interpolating signals. More...
struct	ElectrodeContact
	Single contact on a depth electrode shaft. More...
struct	ElectrodeShaft
	One shaft of a stereotactic depth electrode (sEEG). More...
class	ElectrodeObject
	Data model for stereotactic depth electrode (sEEG) visualization. More...
class	SliceObject
	Data model for a single 2-D MRI volume slice. More...
class	RtSensorDataWorker
	Background worker for real-time sensor data streaming. More...
class	RtSensorInterpolationMatWorker
	Background worker for computing sensor field mapping matrices. More...
class	RtSourceDataWorker
	Background worker for real-time source estimate streaming. More...
class	RtSourceInterpolationMatWorker
	Background worker for computing source interpolation matrices. More...

Typedefs
using	FieldMap = FWDLIB::FwdFieldMap

Enumerations
enum class	SliceOrientation { Axial = 0 , Sagittal , Coronal }
	Orientation for an orthogonal MRI slice. More...

Functions
const char *	buildDateTime ()
const char *	buildHash ()
const char *	buildHashLong ()

Detailed Description

3-D brain visualisation using the Qt RHI rendering backend.

Typedef Documentation

FieldMap

using DISP3DLIB::FieldMap = FWDLIB::FwdFieldMap

Deprecated

Use FWDLIB::FwdFieldMap instead.

Definition at line 22 of file field_map.h.

Enumeration Type Documentation

SliceOrientation

enum class DISP3DLIB::SliceOrientation

strong

Orientation for an orthogonal MRI slice.

Enumerator
Axial	XY plane (Z = const).
Sagittal	YZ plane (X = const).
Coronal	XZ plane (Y = const).

Definition at line 70 of file sliceobject.h.

Function Documentation

buildDateTime()

const char * DISP3DLIB::buildDateTime

(

)

Returns build date and time.

Definition at line 49 of file disp3D_global.cpp.

buildHash()

const char * DISP3DLIB::buildHash

(

)

Returns abbreviated build git hash.

Definition at line 50 of file disp3D_global.cpp.

buildHashLong()

const char * DISP3DLIB::buildHashLong

(

)

Returns full build git hash.

Definition at line 51 of file disp3D_global.cpp.
