Symbolic FIFF tag, block, value, unit and channel-type constants shared across FIFFLIB. More...

This graph shows which files directly or indirectly include this file:

Namespaces
namespace	FIFFLIB
	FIFF file I/O, in-memory data structures and high-level readers/writers.

Macros
#define	FIFFC_FAIL -1
#define	FIFFC_OK 0
#define	FIFFV_TRUE 1
#define	FIFFV_FALSE 0
#define	FIFF_FAIL -1
#define	FIFF_OK 0
#define	FIFFV_QUAT_0 700
#define	FIFFV_QUAT_1 701
#define	FIFFV_QUAT_2 702
#define	FIFFV_QUAT_3 703
#define	FIFFV_QUAT_4 704
#define	FIFFV_QUAT_5 705
#define	FIFFV_QUAT_6 706
#define	FIFFV_HPI_G 707
#define	FIFFV_HPI_ERR 708
#define	FIFFV_HPI_MOV 709
#define	FIFFM_QUAT_CH(X)
#define	FIFFV_DIPOLE_WAVE_CH 1000 /* Dipole time curve */
#define	FIFFV_GOODNESS_FIT_CH 1001 /* Goodness of fit */
#define	FIFFM_CHPOS(x)
#define	FIFF_UNIT_NONE -1
#define	FIFF_UNIT_M 1
#define	FIFF_UNIT_KG 2
#define	FIFF_UNIT_SEC 3
#define	FIFF_UNIT_A 4
#define	FIFF_UNIT_K 5
#define	FIFF_UNIT_MOL 6
#define	FIFF_UNIT_RAD 7
#define	FIFF_UNIT_SR 8
#define	FIFF_UNIT_CD 9
#define	FIFF_UNIT_HZ 101
#define	FIFF_UNIT_N 102
#define	FIFF_UNIT_PA 103
#define	FIFF_UNIT_J 104
#define	FIFF_UNIT_W 105
#define	FIFF_UNIT_C 106
#define	FIFF_UNIT_V 107
#define	FIFF_UNIT_F 108
#define	FIFF_UNIT_OHM 109
#define	FIFF_UNIT_MHO 110
#define	FIFF_UNIT_WB 111
#define	FIFF_UNIT_T 112
#define	FIFF_UNIT_H 113
#define	FIFF_UNIT_CEL 114
#define	FIFF_UNIT_LM 115
#define	FIFF_UNIT_LX 116
#define	FIFF_UNIT_T_M 201 /* T/m */
#define	FIFF_UNIT_AM 202 /* Am */
#define	FIFF_UNIT_AM_M2 203 /* Am/m^2 */
#define	FIFF_UNIT_AM_M3 204 /* Am/m^3 */
#define	FIFF_UNITM_E 18
#define	FIFF_UNITM_PET 15
#define	FIFF_UNITM_T 12
#define	FIFF_UNITM_MEG 6
#define	FIFF_UNITM_K 3
#define	FIFF_UNITM_H 2
#define	FIFF_UNITM_DA 1
#define	FIFF_UNITM_NONE 0
#define	FIFF_UNITM_D -1
#define	FIFF_UNITM_C -2
#define	FIFF_UNITM_M -3
#define	FIFF_UNITM_MU -6
#define	FIFF_UNITM_N -9
#define	FIFF_UNITM_P -12
#define	FIFF_UNITM_F -15
#define	FIFF_UNITM_A -18
#define	FIFFV_COIL_NONE 0
#define	FIFFV_COIL_EEG 1
#define	FIFFV_COIL_NM_122 2
#define	FIFFV_COIL_NM_24 3
#define	FIFFV_COIL_NM_MCG_AXIAL 4
#define	FIFFV_COIL_EEG_BIPOLAR 5
#define	FIFFV_COIL_DIPOLE 200
#define	FIFFV_COIL_MCG_42 1000
#define	FIFFV_COIL_POINT_MAGNETOMETER 2000
#define	FIFFV_COIL_AXIAL_GRAD_5CM 2001
#define	FIFFV_COIL_VV_PLANAR_W 3011
#define	FIFFV_COIL_VV_PLANAR_T1 3012
#define	FIFFV_COIL_VV_PLANAR_T2 3013
#define	FIFFV_COIL_VV_PLANAR_T3 3014
#define	FIFFV_COIL_VV_MAG_W 3021
#define	FIFFV_COIL_VV_MAG_T1 3022
#define	FIFFV_COIL_VV_MAG_T2 3023
#define	FIFFV_COIL_VV_MAG_T3 3024
#define	FIFFV_COIL_MAGNES_MAG 4001
#define	FIFFV_COIL_MAGNES_GRAD 4002
#define	FIFFV_COIL_CTF_GRAD 5001
#define	FIFFV_COIL_CTF_REF_MAG 5002
#define	FIFFV_COIL_CTF_REF_GRAD 5003
#define	FIFFV_COIL_CTF_REF_GOFF 5004
#define	FIFFV_COIL_KIT_GRAD 6001
#define	FIFFV_COIL_KIT_REF_GRAD 6002
#define	FIFFV_COIL_BABY_GRAD 7001
#define	FIFFV_COIL_BABY_MAG 7002
#define	FIFFV_COIL_BABY_REF_MAG 7003
#define	FIFFV_COIL_BABY_REF_MAG2 7004
#define	FIFFV_COIL_ARTEMIS123_GRAD 7501
#define	FIFFV_COIL_ARTEMIS123_REF_MAG 7502
#define	FIFFV_COIL_ARTEMIS123_REF_GRAD 7503
#define	FIFFV_COIL_QUSPIN_ZFOPM_MAG 8001
#define	FIFFV_COIL_KRISS_GRAD 9001
#define	FIFFV_COIL_COMPUMEDICS_ADULT_GRAD 9101
#define	FIFFV_COIL_COMPUMEDICS_PEDIATRIC_GRAD 9102
#define	FIFFM_IS_VV_COIL(c)
#define	FIFFV_POINT_CHEST_LEFT 1
#define	FIFFV_POINT_CHEST_STERNUM 2
#define	FIFFV_POINT_CHEST_RIGHT 3
#define	FIFFV_COORD_UNKNOWN 0
#define	FIFFV_COORD_DEVICE 1
#define	FIFFV_COORD_ISOTRAK 2
#define	FIFFV_COORD_HPI 3
#define	FIFFV_COORD_HEAD 4
#define	FIFFV_COORD_MRI 5
#define	FIFFV_COORD_MRI_SLICE 6
#define	FIFFV_COORD_MRI_DISPLAY 7
#define	FIFFV_COORD_XRAY FIFF_COORD_MRI
#define	FIFFV_COORD_XRAY_SLICE FIFF_COORD_MRI_SLICE
#define	FIFFV_COORD_CT FIFF_COORD_MRI
#define	FIFFV_COORD_CT_SLICE FIFF_COORD_MRI_SLICE
#define	FIFFV_COORD_DICOM_DEVICE 8
#define	FIFFV_COORD_IMAGING_DEVICE 9
#define	FIFFV_COORD_TORSO 100
#define	FIFFV_MOVE 1
#define	FIFFV_NO_MOVE 0
#define	FIFFV_ARTEF_MAX 100
#define	FIFFV_ARTEF_NONE -1
#define	FIFFV_ARTEF_KEEP 0
#define	FIFFV_ARTEF_JUMP 1
#define	FIFFV_ARTEF_NOJUMP 2
#define	FIFFV_LAYER_BRAIN 1
#define	FIFFV_LAYER_CSF 2
#define	FIFFV_LAYER_SKULL 3
#define	FIFFV_LAYER_HEAD 4
#define	FIFFV_XFIT_MAP_SURF_SENSORS 0
#define	FIFFV_XFIT_MAP_SURF_HEAD 1
#define	FIFFV_XFIT_MAP_SURF_SPHERE 2
#define	FIFFV_NEXT_SEQ 0
#define	FIFFV_NEXT_NONE -1
#define	FIFFV_MAGN_CH 1
#define	FIFFV_EL_CH 2
#define	FIFFV_MEG_CH FIFFV_MAGN_CH
#define	FIFFV_MCG_CH 201
#define	FIFFV_REF_MEG_CH 301
#define	FIFFV_EEG_CH FIFFV_EL_CH
#define	FIFFV_STIM_CH 3
#define	FIFFV_EOG_CH 202
#define	FIFFV_EMG_CH 302
#define	FIFFV_ECG_CH 402
#define	FIFFV_MISC_CH 502
#define	FIFFV_RESP_CH 602
#define	FIFFV_ECOG_CH 2001
#define	FIFFV_SEEG_CH 2002
#define	FIFFV_DBS_CH 2003
#define	FIFFV_COIL_EEG_ECOG 140
#define	FIFFV_COIL_EEG_SEEG 150
#define	FIFFV_COIL_EEG_DBS 160
#define	FIFFV_MNE_SURF_UNKNOWN -1
#define	FIFFV_MNE_SURF_LEFT_HEMI 101
#define	FIFFV_MNE_SURF_RIGHT_HEMI 102
#define	FIFFV_POINT_CARDINAL 1
#define	FIFFV_POINT_HPI 2
#define	FIFFV_POINT_EEG 3
#define	FIFFV_POINT_ECG FIFFV_POINT_EEG
#define	FIFFV_POINT_EXTRA 4
#define	FIFFV_POINT_LPA 1
#define	FIFFV_POINT_NASION 2
#define	FIFFV_POINT_RPA 3
#define	FIFFB_MNE 350
#define	FIFFB_MNE_SOURCE_SPACE 351
#define	FIFFB_MNE_FORWARD_SOLUTION 352
#define	FIFFB_MNE_PARENT_MRI_FILE 353
#define	FIFFB_MNE_PARENT_MEAS_FILE 354
#define	FIFFB_MNE_COV 355
#define	FIFFB_MNE_INVERSE_SOLUTION 356
#define	FIFFB_MNE_NAMED_MATRIX 357
#define	FIFFB_MNE_ENV 358
#define	FIFFB_MNE_BAD_CHANNELS 359
#define	FIFFB_MNE_VERTEX_MAP 360
#define	FIFFB_MNE_EVENTS 361
#define	FIFFB_MNE_MORPH_MAP 362
#define	FIFFB_MNE_CTF_COMP 370
#define	FIFFB_MNE_CTF_COMP_DATA 371
#define	FIFF_MNE_ROW_NAMES 3502
#define	FIFF_MNE_COL_NAMES 3503
#define	FIFF_MNE_NROW 3504
#define	FIFF_MNE_NCOL 3505
#define	FIFF_MNE_COORD_FRAME 3506
#define	FIFF_MNE_CH_NAME_LIST 3507
#define	FIFF_MNE_FILE_NAME 3508
#define	FIFF_MNE_SOURCE_SPACE_POINTS 3510
#define	FIFF_MNE_SOURCE_SPACE_NORMALS 3511
#define	FIFF_MNE_SOURCE_SPACE_NPOINTS 3512
#define	FIFF_MNE_SOURCE_SPACE_SELECTION 3513
#define	FIFF_MNE_SOURCE_SPACE_NUSE 3514
#define	FIFF_MNE_SOURCE_SPACE_NEAREST 3515
#define	FIFF_MNE_SOURCE_SPACE_NEAREST_DIST 3516
#define	FIFF_MNE_SOURCE_SPACE_ID 3517
#define	FIFF_MNE_SOURCE_SPACE_TYPE 3518
#define	FIFF_MNE_SOURCE_SPACE_NTRI 3590
#define	FIFF_MNE_SOURCE_SPACE_TRIANGLES 3591
#define	FIFF_MNE_SOURCE_SPACE_NUSE_TRI 3592
#define	FIFF_MNE_SOURCE_SPACE_USE_TRIANGLES 3593
#define	FIFF_MNE_SOURCE_SPACE_VOXEL_DIMS 3596
#define	FIFF_MNE_SOURCE_SPACE_INTERPOLATOR 3597
#define	FIFF_MNE_SOURCE_SPACE_MRI_FILE 3598
#define	FIFF_MNE_SOURCE_SPACE_DIST 3599
#define	FIFF_MNE_SOURCE_SPACE_DIST_LIMIT 3600
#define	FIFF_MNE_FORWARD_SOLUTION 3520
#define	FIFF_MNE_SOURCE_ORIENTATION 3521
#define	FIFF_MNE_INCLUDED_METHODS 3522
#define	FIFF_MNE_FORWARD_SOLUTION_GRAD 3523
#define	FIFF_MNE_COV_KIND 3530
#define	FIFF_MNE_COV_DIM 3531
#define	FIFF_MNE_COV 3532
#define	FIFF_MNE_COV_DIAG 3533
#define	FIFF_MNE_COV_EIGENVALUES 3534
#define	FIFF_MNE_COV_EIGENVECTORS 3535
#define	FIFF_MNE_COV_NFREE 3536
#define	FIFF_MNE_INVERSE_LEADS 3540
#define	FIFF_MNE_INVERSE_LEADS_WEIGHTED 3546
#define	FIFF_MNE_INVERSE_FIELDS 3541
#define	FIFF_MNE_INVERSE_SING 3542
#define	FIFF_MNE_PRIORS_USED 3543
#define	FIFF_MNE_INVERSE_FULL 3544
#define	FIFF_MNE_INVERSE_SOURCE_ORIENTATIONS 3545
#define	FIFF_MNE_ENV_WORKING_DIR 3550
#define	FIFF_MNE_ENV_COMMAND_LINE 3551
#define	FIFF_MNE_PROJ_ITEM_ACTIVE 3560
#define	FIFF_MNE_EVENT_LIST 3561
#define	FIFF_MNE_HEMI 3562
#define	FIFF_MNE_MORPH_MAP 3570
#define	FIFF_MNE_MORPH_MAP_FROM 3571
#define	FIFF_MNE_MORPH_MAP_TO 3572
#define	FIFF_MNE_CTF_COMP_KIND 3580
#define	FIFF_MNE_CTF_COMP_DATA 3581
#define	FIFF_MNE_CTF_COMP_CALIBRATED 3582
#define	FIFF_MNE_RT_COMMAND 3700
#define	FIFF_MNE_RT_CLIENT_ID 3701
#define	FIFFB_MNE_RT_MEAS_INFO 3710
#define	FIFFV_MNE_FIXED_ORI 1
#define	FIFFV_MNE_FREE_ORI 2
#define	FIFFV_MNE_MEG 1
#define	FIFFV_MNE_EEG 2
#define	FIFFV_MNE_MEG_EEG 3
#define	FIFFV_MNE_UNKNOWN_COV 0
#define	FIFFV_MNE_SENSOR_COV 1
#define	FIFFV_MNE_NOISE_COV 1
#define	FIFFV_MNE_SOURCE_COV 2
#define	FIFFV_MNE_FMRI_PRIOR_COV 3
#define	FIFFV_MNE_SIGNAL_COV 4
#define	FIFFV_MNE_DEPTH_PRIOR_COV 5
#define	FIFFV_MNE_ORIENT_PRIOR_COV 6
#define	FIFFV_MNE_SPACE_UNKNOWN -1
#define	FIFFV_MNE_SPACE_SURFACE 1
#define	FIFFV_MNE_SPACE_VOLUME 2
#define	FIFFV_MNE_SPACE_DISCRETE 3
#define	FIFFV_MNE_COV_CH_UNKNOWN -1
#define	FIFFV_MNE_COV_CH_MEG_MAG 0
#define	FIFFV_MNE_COV_CH_MEG_GRAD 1
#define	FIFFV_MNE_COV_CH_EEG 2
#define	FIFFV_MNE_PROJ_ITEM_EEG_AVREF 10
#define	FIFFV_MNE_COORD_TUFTS_EEG 300
#define	FIFFV_MNE_COORD_CTF_DEVICE 1001
#define	FIFFV_MNE_COORD_CTF_HEAD 1004
#define	FIFFV_MNE_COORD_MRI_VOXEL 2001
#define	FIFFV_MNE_COORD_RAS 2002
#define	FIFFV_MNE_COORD_MNI_TAL 2003
#define	FIFFV_MNE_COORD_FS_TAL_GTZ 2004
#define	FIFFV_MNE_COORD_FS_TAL_LTZ 2005
#define	FIFFV_MNE_COORD_FS_TAL 2006

Detailed Description

Symbolic FIFF tag, block, value, unit and channel-type constants shared across FIFFLIB.

Author: Christoph Dinh chris.nosp@m.toph.nosp@m..dinh.nosp@m.@mne.nosp@m.-cpp..nosp@m.org; Limin Sun limin.nosp@m.sun@.nosp@m.nmr.m.nosp@m.gh.h.nosp@m.arvar.nosp@m.d.ed.nosp@m.u; Christof Pieloth pielo.nosp@m.th@l.nosp@m.abp.h.nosp@m.twk-.nosp@m.leipz.nosp@m.ig.d.nosp@m.e; Lorenz Esch loren.nosp@m.z.es.nosp@m.ch@tu.nosp@m.-ilm.nosp@m.enau..nosp@m.de; Juan GPC jgarc.nosp@m.iapr.nosp@m.ieto@.nosp@m.mgh..nosp@m.harva.nosp@m.rd.e.nosp@m.du; Gabriel Motta gabri.nosp@m.elbe.nosp@m.nmott.nosp@m.a@gm.nosp@m.ail.c.nosp@m.om

Since: 0.1.0

Date: August 2012

Mirrors the fiff_constants.h header shipped with the original MNE-C toolchain and the matching tables in mne.io.constants in MNE-Python, so a kind / block / unit number written by either implementation is recognized verbatim here. The naming convention (also documented in fiff_file.h) is:

FIFF_ - tag kind (e.g. FIFF_NCHAN, FIFF_SFREQ).
FIFFB_ - block type (e.g. FIFFB_MEAS, FIFFB_RAW_DATA).
FIFFV_ - enumerated value with semantic meaning in some context (e.g. FIFFV_COIL_VV_PLANAR_T1, FIFFV_COORD_HEAD).
FIFFC_ - implementation constant, never appears in a file.
FIFFT_ - tag data type (scalar / matrix descriptor).

The numeric values must never drift from the Elekta FIFF specification; any new constant added here must match the value already used by the neuromag acquisition stack and by MNE-Python, otherwise FIFF files become non-portable.

Definition in file fiff_constants.h.

Macro Definition Documentation

◆ FIFF_FAIL

#define FIFF_FAIL -1

Definition at line 58 of file fiff_constants.h.

◆ FIFF_MNE_CH_NAME_LIST

#define FIFF_MNE_CH_NAME_LIST 3507

Definition at line 345 of file fiff_constants.h.

◆ FIFF_MNE_COL_NAMES

#define FIFF_MNE_COL_NAMES 3503

Definition at line 338 of file fiff_constants.h.

◆ FIFF_MNE_COORD_FRAME

#define FIFF_MNE_COORD_FRAME 3506

Coordinate frame employed. Defaults:

Definition at line 341 of file fiff_constants.h.

◆ FIFF_MNE_COV

#define FIFF_MNE_COV 3532

Full matrix in packed representation (lower triangle)

Definition at line 386 of file fiff_constants.h.

◆ FIFF_MNE_COV_DIAG

#define FIFF_MNE_COV_DIAG 3533

Diagonal matrix

Definition at line 387 of file fiff_constants.h.

◆ FIFF_MNE_COV_DIM

#define FIFF_MNE_COV_DIM 3531

Matrix dimension

Definition at line 385 of file fiff_constants.h.

◆ FIFF_MNE_COV_EIGENVALUES

#define FIFF_MNE_COV_EIGENVALUES 3534

Eigenvalues and eigenvectors of the above

Definition at line 388 of file fiff_constants.h.

◆ FIFF_MNE_COV_EIGENVECTORS

#define FIFF_MNE_COV_EIGENVECTORS 3535

Definition at line 389 of file fiff_constants.h.

◆ FIFF_MNE_COV_KIND

#define FIFF_MNE_COV_KIND 3530

What kind of a covariance matrix

Definition at line 384 of file fiff_constants.h.

◆ FIFF_MNE_COV_NFREE

#define FIFF_MNE_COV_NFREE 3536

Number of degrees of freedom

Definition at line 390 of file fiff_constants.h.

◆ FIFF_MNE_CTF_COMP_CALIBRATED

#define FIFF_MNE_CTF_COMP_CALIBRATED 3582

Are the coefficients calibrated?

Definition at line 433 of file fiff_constants.h.

◆ FIFF_MNE_CTF_COMP_DATA

#define FIFF_MNE_CTF_COMP_DATA 3581

The compensation data itself

Definition at line 432 of file fiff_constants.h.

◆ FIFF_MNE_CTF_COMP_KIND

#define FIFF_MNE_CTF_COMP_KIND 3580

What kind of compensation

Definition at line 431 of file fiff_constants.h.

◆ FIFF_MNE_ENV_COMMAND_LINE

#define FIFF_MNE_ENV_COMMAND_LINE 3551

The command used to create the file

Definition at line 412 of file fiff_constants.h.

◆ FIFF_MNE_ENV_WORKING_DIR

#define FIFF_MNE_ENV_WORKING_DIR 3550

Working directory where the file was created

Definition at line 411 of file fiff_constants.h.

◆ FIFF_MNE_EVENT_LIST

#define FIFF_MNE_EVENT_LIST 3561

An event list (for STI 014)

Definition at line 418 of file fiff_constants.h.

◆ FIFF_MNE_FILE_NAME

#define FIFF_MNE_FILE_NAME 3508

This removes the collision with fiff_stream.h (used to be 3501)

Definition at line 346 of file fiff_constants.h.

◆ FIFF_MNE_FORWARD_SOLUTION

#define FIFF_MNE_FORWARD_SOLUTION 3520

Definition at line 376 of file fiff_constants.h.

◆ FIFF_MNE_FORWARD_SOLUTION_GRAD

#define FIFF_MNE_FORWARD_SOLUTION_GRAD 3523

Definition at line 379 of file fiff_constants.h.

◆ FIFF_MNE_HEMI

#define FIFF_MNE_HEMI 3562

Hemisphere association for general purposes

Definition at line 419 of file fiff_constants.h.

◆ FIFF_MNE_INCLUDED_METHODS

#define FIFF_MNE_INCLUDED_METHODS 3522

Definition at line 378 of file fiff_constants.h.

◆ FIFF_MNE_INVERSE_FIELDS

#define FIFF_MNE_INVERSE_FIELDS 3541

The eigenfields

Definition at line 398 of file fiff_constants.h.

◆ FIFF_MNE_INVERSE_FULL

#define FIFF_MNE_INVERSE_FULL 3544

Inverse operator as one matrix

Definition at line 401 of file fiff_constants.h.

◆ FIFF_MNE_INVERSE_LEADS

#define FIFF_MNE_INVERSE_LEADS 3540

The eigenleads

Definition at line 396 of file fiff_constants.h.

◆ FIFF_MNE_INVERSE_LEADS_WEIGHTED

#define FIFF_MNE_INVERSE_LEADS_WEIGHTED 3546

The eigenleads (already weighted with R^0.5)

Definition at line 397 of file fiff_constants.h.

◆ FIFF_MNE_INVERSE_SING

#define FIFF_MNE_INVERSE_SING 3542

The singular values

Definition at line 399 of file fiff_constants.h.

◆ FIFF_MNE_INVERSE_SOURCE_ORIENTATIONS

#define FIFF_MNE_INVERSE_SOURCE_ORIENTATIONS 3545

orientation of one source per row

Definition at line 404 of file fiff_constants.h.

◆ FIFF_MNE_MORPH_MAP

#define FIFF_MNE_MORPH_MAP 3570

Mapping of closest vertices on the sphere

Definition at line 424 of file fiff_constants.h.

◆ FIFF_MNE_MORPH_MAP_FROM

#define FIFF_MNE_MORPH_MAP_FROM 3571

Which subject is this map from

Definition at line 425 of file fiff_constants.h.

◆ FIFF_MNE_MORPH_MAP_TO

#define FIFF_MNE_MORPH_MAP_TO 3572

Which subject is this map to

Definition at line 426 of file fiff_constants.h.

◆ FIFF_MNE_NCOL

#define FIFF_MNE_NCOL 3505

Definition at line 340 of file fiff_constants.h.

◆ FIFF_MNE_NROW

#define FIFF_MNE_NROW 3504

Definition at line 339 of file fiff_constants.h.

◆ FIFF_MNE_PRIORS_USED

#define FIFF_MNE_PRIORS_USED 3543

Which kind of priors have been used for the source covariance matrix

Definition at line 400 of file fiff_constants.h.

◆ FIFF_MNE_PROJ_ITEM_ACTIVE

#define FIFF_MNE_PROJ_ITEM_ACTIVE 3560

Is this projection item active?

Definition at line 417 of file fiff_constants.h.

◆ FIFF_MNE_ROW_NAMES

#define FIFF_MNE_ROW_NAMES 3502

Definition at line 337 of file fiff_constants.h.

◆ FIFF_MNE_RT_CLIENT_ID

#define FIFF_MNE_RT_CLIENT_ID 3701

Fiff Real-Time mne_t_server client id.

Definition at line 439 of file fiff_constants.h.

◆ FIFF_MNE_RT_COMMAND

#define FIFF_MNE_RT_COMMAND 3700

Fiff Real-Time Command.

Definition at line 438 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_ORIENTATION

#define FIFF_MNE_SOURCE_ORIENTATION 3521

Fixed or free

Definition at line 377 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_DIST

#define FIFF_MNE_SOURCE_SPACE_DIST 3599

Distances between vertices in use (along the surface)

Definition at line 370 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_DIST_LIMIT

#define FIFF_MNE_SOURCE_SPACE_DIST_LIMIT 3600

If distance is above this limit (in the volume) it has not been calculated

Definition at line 371 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_ID

#define FIFF_MNE_SOURCE_SPACE_ID 3517

Identifier

Definition at line 358 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_INTERPOLATOR

#define FIFF_MNE_SOURCE_SPACE_INTERPOLATOR 3597

Matrix to interpolate a volume source space into a mri volume

Definition at line 367 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_MRI_FILE

#define FIFF_MNE_SOURCE_SPACE_MRI_FILE 3598

MRI file used in the interpolation

Definition at line 368 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NEAREST

#define FIFF_MNE_SOURCE_SPACE_NEAREST 3515

Nearest source space vertex for all vertices

Definition at line 356 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NEAREST_DIST

#define FIFF_MNE_SOURCE_SPACE_NEAREST_DIST 3516

Distance to the Nearest source space vertex for all vertices

Definition at line 357 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NORMALS

#define FIFF_MNE_SOURCE_SPACE_NORMALS 3511

The vertex normals

Definition at line 352 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NPOINTS

#define FIFF_MNE_SOURCE_SPACE_NPOINTS 3512

How many vertices

Definition at line 353 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NTRI

#define FIFF_MNE_SOURCE_SPACE_NTRI 3590

Number of triangles

Definition at line 361 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NUSE

#define FIFF_MNE_SOURCE_SPACE_NUSE 3514

How many are in use

Definition at line 355 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_NUSE_TRI

#define FIFF_MNE_SOURCE_SPACE_NUSE_TRI 3592

Number of triangles corresponding to the number of vertices in use

Definition at line 363 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_POINTS

#define FIFF_MNE_SOURCE_SPACE_POINTS 3510

The vertices

Definition at line 351 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_SELECTION

#define FIFF_MNE_SOURCE_SPACE_SELECTION 3513

Which are selected to the source space

Definition at line 354 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_TRIANGLES

#define FIFF_MNE_SOURCE_SPACE_TRIANGLES 3591

The triangulation

Definition at line 362 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_TYPE

#define FIFF_MNE_SOURCE_SPACE_TYPE 3518

FsSurface or volume

Definition at line 359 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_USE_TRIANGLES

#define FIFF_MNE_SOURCE_SPACE_USE_TRIANGLES 3593

The triangulation of the used vertices in the source space

Definition at line 364 of file fiff_constants.h.

◆ FIFF_MNE_SOURCE_SPACE_VOXEL_DIMS

#define FIFF_MNE_SOURCE_SPACE_VOXEL_DIMS 3596

Voxel space dimensions in a volume source space

Definition at line 366 of file fiff_constants.h.

◆ FIFF_OK

#define FIFF_OK 0

Definition at line 59 of file fiff_constants.h.

◆ FIFF_UNIT_A

#define FIFF_UNIT_A 4

Definition at line 94 of file fiff_constants.h.

◆ FIFF_UNIT_AM

#define FIFF_UNIT_AM 202 /* Am */

Definition at line 133 of file fiff_constants.h.

◆ FIFF_UNIT_AM_M2

#define FIFF_UNIT_AM_M2 203 /* Am/m^2 */

Definition at line 134 of file fiff_constants.h.

◆ FIFF_UNIT_AM_M3

#define FIFF_UNIT_AM_M3 204 /* Am/m^3 */

Definition at line 135 of file fiff_constants.h.

◆ FIFF_UNIT_C

#define FIFF_UNIT_C 106

Definition at line 117 of file fiff_constants.h.

◆ FIFF_UNIT_CD

#define FIFF_UNIT_CD 9

Definition at line 107 of file fiff_constants.h.

◆ FIFF_UNIT_CEL

#define FIFF_UNIT_CEL 114

Definition at line 125 of file fiff_constants.h.

◆ FIFF_UNIT_F

#define FIFF_UNIT_F 108

Definition at line 119 of file fiff_constants.h.

◆ FIFF_UNIT_H

#define FIFF_UNIT_H 113

Definition at line 124 of file fiff_constants.h.

◆ FIFF_UNIT_HZ

#define FIFF_UNIT_HZ 101

Definition at line 112 of file fiff_constants.h.

◆ FIFF_UNIT_J

#define FIFF_UNIT_J 104

Definition at line 115 of file fiff_constants.h.

◆ FIFF_UNIT_K

#define FIFF_UNIT_K 5

Definition at line 95 of file fiff_constants.h.

◆ FIFF_UNIT_KG

#define FIFF_UNIT_KG 2

Definition at line 92 of file fiff_constants.h.

◆ FIFF_UNIT_LM

#define FIFF_UNIT_LM 115

Definition at line 126 of file fiff_constants.h.

◆ FIFF_UNIT_LX

#define FIFF_UNIT_LX 116

Definition at line 127 of file fiff_constants.h.

◆ FIFF_UNIT_M

#define FIFF_UNIT_M 1

Definition at line 91 of file fiff_constants.h.

◆ FIFF_UNIT_MHO

#define FIFF_UNIT_MHO 110

Definition at line 121 of file fiff_constants.h.

◆ FIFF_UNIT_MOL

#define FIFF_UNIT_MOL 6

Definition at line 96 of file fiff_constants.h.

◆ FIFF_UNIT_N

#define FIFF_UNIT_N 102

Definition at line 113 of file fiff_constants.h.

◆ FIFF_UNIT_NONE

#define FIFF_UNIT_NONE -1

Definition at line 86 of file fiff_constants.h.

◆ FIFF_UNIT_OHM

#define FIFF_UNIT_OHM 109

Definition at line 120 of file fiff_constants.h.

◆ FIFF_UNIT_PA

#define FIFF_UNIT_PA 103

Definition at line 114 of file fiff_constants.h.

◆ FIFF_UNIT_RAD

#define FIFF_UNIT_RAD 7

Definition at line 101 of file fiff_constants.h.

◆ FIFF_UNIT_SEC

#define FIFF_UNIT_SEC 3

Definition at line 93 of file fiff_constants.h.

◆ FIFF_UNIT_SR

#define FIFF_UNIT_SR 8

Definition at line 102 of file fiff_constants.h.

◆ FIFF_UNIT_T

#define FIFF_UNIT_T 112

Definition at line 123 of file fiff_constants.h.

◆ FIFF_UNIT_T_M

#define FIFF_UNIT_T_M 201 /* T/m */

Definition at line 132 of file fiff_constants.h.

◆ FIFF_UNIT_V

#define FIFF_UNIT_V 107

Definition at line 118 of file fiff_constants.h.

◆ FIFF_UNIT_W

#define FIFF_UNIT_W 105

Definition at line 116 of file fiff_constants.h.

◆ FIFF_UNIT_WB

#define FIFF_UNIT_WB 111

Definition at line 122 of file fiff_constants.h.

◆ FIFF_UNITM_A

#define FIFF_UNITM_A -18

Definition at line 155 of file fiff_constants.h.

◆ FIFF_UNITM_C

#define FIFF_UNITM_C -2

Definition at line 149 of file fiff_constants.h.

◆ FIFF_UNITM_D

#define FIFF_UNITM_D -1

Definition at line 148 of file fiff_constants.h.

◆ FIFF_UNITM_DA

#define FIFF_UNITM_DA 1

Definition at line 146 of file fiff_constants.h.

◆ FIFF_UNITM_E

#define FIFF_UNITM_E 18

Definition at line 140 of file fiff_constants.h.

◆ FIFF_UNITM_F

#define FIFF_UNITM_F -15

Definition at line 154 of file fiff_constants.h.

◆ FIFF_UNITM_H

#define FIFF_UNITM_H 2

Definition at line 145 of file fiff_constants.h.

◆ FIFF_UNITM_K

#define FIFF_UNITM_K 3

Definition at line 144 of file fiff_constants.h.

◆ FIFF_UNITM_M

#define FIFF_UNITM_M -3

Definition at line 150 of file fiff_constants.h.

◆ FIFF_UNITM_MEG

#define FIFF_UNITM_MEG 6

Definition at line 143 of file fiff_constants.h.

◆ FIFF_UNITM_MU

#define FIFF_UNITM_MU -6

Definition at line 151 of file fiff_constants.h.

◆ FIFF_UNITM_N

#define FIFF_UNITM_N -9

Definition at line 152 of file fiff_constants.h.

◆ FIFF_UNITM_NONE

#define FIFF_UNITM_NONE 0

Definition at line 147 of file fiff_constants.h.

◆ FIFF_UNITM_P

#define FIFF_UNITM_P -12

Definition at line 153 of file fiff_constants.h.

◆ FIFF_UNITM_PET

#define FIFF_UNITM_PET 15

Definition at line 141 of file fiff_constants.h.

◆ FIFF_UNITM_T

#define FIFF_UNITM_T 12

Definition at line 142 of file fiff_constants.h.

◆ FIFFB_MNE

#define FIFFB_MNE 350

Definition at line 313 of file fiff_constants.h.

◆ FIFFB_MNE_BAD_CHANNELS

#define FIFFB_MNE_BAD_CHANNELS 359

Definition at line 322 of file fiff_constants.h.

◆ FIFFB_MNE_COV

#define FIFFB_MNE_COV 355

Definition at line 318 of file fiff_constants.h.

◆ FIFFB_MNE_CTF_COMP

#define FIFFB_MNE_CTF_COMP 370

Definition at line 330 of file fiff_constants.h.

◆ FIFFB_MNE_CTF_COMP_DATA

#define FIFFB_MNE_CTF_COMP_DATA 371

Definition at line 331 of file fiff_constants.h.

◆ FIFFB_MNE_ENV

#define FIFFB_MNE_ENV 358

Definition at line 321 of file fiff_constants.h.

◆ FIFFB_MNE_EVENTS

#define FIFFB_MNE_EVENTS 361

Definition at line 324 of file fiff_constants.h.

◆ FIFFB_MNE_FORWARD_SOLUTION

#define FIFFB_MNE_FORWARD_SOLUTION 352

Definition at line 315 of file fiff_constants.h.

◆ FIFFB_MNE_INVERSE_SOLUTION

#define FIFFB_MNE_INVERSE_SOLUTION 356

Definition at line 319 of file fiff_constants.h.

◆ FIFFB_MNE_MORPH_MAP

#define FIFFB_MNE_MORPH_MAP 362

Definition at line 325 of file fiff_constants.h.

◆ FIFFB_MNE_NAMED_MATRIX

#define FIFFB_MNE_NAMED_MATRIX 357

Definition at line 320 of file fiff_constants.h.

◆ FIFFB_MNE_PARENT_MEAS_FILE

#define FIFFB_MNE_PARENT_MEAS_FILE 354

Definition at line 317 of file fiff_constants.h.

◆ FIFFB_MNE_PARENT_MRI_FILE

#define FIFFB_MNE_PARENT_MRI_FILE 353

Definition at line 316 of file fiff_constants.h.

◆ FIFFB_MNE_RT_MEAS_INFO

#define FIFFB_MNE_RT_MEAS_INFO 3710

Fiff Real-Time Measurement Info.

Definition at line 444 of file fiff_constants.h.

◆ FIFFB_MNE_SOURCE_SPACE

#define FIFFB_MNE_SOURCE_SPACE 351

Definition at line 314 of file fiff_constants.h.

◆ FIFFB_MNE_VERTEX_MAP

#define FIFFB_MNE_VERTEX_MAP 360

Definition at line 323 of file fiff_constants.h.

◆ FIFFC_FAIL

#define FIFFC_FAIL -1

Definition at line 50 of file fiff_constants.h.

◆ FIFFC_OK

#define FIFFC_OK 0

Definition at line 51 of file fiff_constants.h.

◆ FIFFM_CHPOS

#define FIFFM_CHPOS ( x )

Value:

&((x)->chpos)

Definition at line 81 of file fiff_constants.h.

◆ FIFFM_IS_VV_COIL

#define FIFFM_IS_VV_COIL ( c )

Value:

((c)/1000 == 3)

Definition at line 198 of file fiff_constants.h.

◆ FIFFM_QUAT_CH

#define FIFFM_QUAT_CH ( X )

Value:

((X >= FIFFV_QUAT_0) && (X <= FIFFV_HPI_MOV)) /* Check for a quaternion channel */

X

constexpr int X

Definition compute_fwd.cpp:47

FIFFV_QUAT_0

#define FIFFV_QUAT_0

Definition fiff_constants.h:65

FIFFV_HPI_MOV

#define FIFFV_HPI_MOV

Definition fiff_constants.h:74

Definition at line 76 of file fiff_constants.h.

◆ FIFFV_ARTEF_JUMP

#define FIFFV_ARTEF_JUMP 1

Definition at line 238 of file fiff_constants.h.

◆ FIFFV_ARTEF_KEEP

#define FIFFV_ARTEF_KEEP 0

Definition at line 237 of file fiff_constants.h.

◆ FIFFV_ARTEF_MAX

#define FIFFV_ARTEF_MAX 100

Definition at line 235 of file fiff_constants.h.

◆ FIFFV_ARTEF_NOJUMP

#define FIFFV_ARTEF_NOJUMP 2

Definition at line 239 of file fiff_constants.h.

◆ FIFFV_ARTEF_NONE

#define FIFFV_ARTEF_NONE -1

Definition at line 236 of file fiff_constants.h.

◆ FIFFV_COIL_ARTEMIS123_GRAD

#define FIFFV_COIL_ARTEMIS123_GRAD 7501

Artemis123 gradiometer.

Definition at line 190 of file fiff_constants.h.

◆ FIFFV_COIL_ARTEMIS123_REF_GRAD

#define FIFFV_COIL_ARTEMIS123_REF_GRAD 7503

Artemis123 reference gradiometer.

Definition at line 192 of file fiff_constants.h.

◆ FIFFV_COIL_ARTEMIS123_REF_MAG

#define FIFFV_COIL_ARTEMIS123_REF_MAG 7502

Artemis123 reference magnetometer.

Definition at line 191 of file fiff_constants.h.

◆ FIFFV_COIL_AXIAL_GRAD_5CM

#define FIFFV_COIL_AXIAL_GRAD_5CM 2001

Generic axial gradiometer.

Definition at line 169 of file fiff_constants.h.

◆ FIFFV_COIL_BABY_GRAD

#define FIFFV_COIL_BABY_GRAD 7001

BabySQUID gradiometers.

Definition at line 186 of file fiff_constants.h.

◆ FIFFV_COIL_BABY_MAG

#define FIFFV_COIL_BABY_MAG 7002

BabyMEG inner layer magnetometers.

Definition at line 187 of file fiff_constants.h.

◆ FIFFV_COIL_BABY_REF_MAG

#define FIFFV_COIL_BABY_REF_MAG 7003

BabyMEG outer layer magnetometers.

Definition at line 188 of file fiff_constants.h.

◆ FIFFV_COIL_BABY_REF_MAG2

#define FIFFV_COIL_BABY_REF_MAG2 7004

BabyMEG reference magnetometer.

Definition at line 189 of file fiff_constants.h.

◆ FIFFV_COIL_COMPUMEDICS_ADULT_GRAD

#define FIFFV_COIL_COMPUMEDICS_ADULT_GRAD 9101

Compumedics adult gradiometer.

Definition at line 195 of file fiff_constants.h.

◆ FIFFV_COIL_COMPUMEDICS_PEDIATRIC_GRAD

#define FIFFV_COIL_COMPUMEDICS_PEDIATRIC_GRAD 9102

Compumedics pediatric gradiometer.

Definition at line 196 of file fiff_constants.h.

◆ FIFFV_COIL_CTF_GRAD

#define FIFFV_COIL_CTF_GRAD 5001

CTF axial gradiometer.

Definition at line 180 of file fiff_constants.h.

◆ FIFFV_COIL_CTF_REF_GOFF

#define FIFFV_COIL_CTF_REF_GOFF 5004

CTF offdiagonal reference gradiometer.

Definition at line 183 of file fiff_constants.h.

◆ FIFFV_COIL_CTF_REF_GRAD

#define FIFFV_COIL_CTF_REF_GRAD 5003

CTF reference gradiometer.

Definition at line 182 of file fiff_constants.h.

◆ FIFFV_COIL_CTF_REF_MAG

#define FIFFV_COIL_CTF_REF_MAG 5002

CTF reference magnetometer.

Definition at line 181 of file fiff_constants.h.

◆ FIFFV_COIL_DIPOLE

#define FIFFV_COIL_DIPOLE 200

Time-varying dipole definition The coil info contains dipole location (r0) and direction (ex).

Definition at line 166 of file fiff_constants.h.

◆ FIFFV_COIL_EEG

#define FIFFV_COIL_EEG 1

EEG electrode position in r0.

Definition at line 161 of file fiff_constants.h.

◆ FIFFV_COIL_EEG_BIPOLAR

#define FIFFV_COIL_EEG_BIPOLAR 5

Bipolar EEG lead.

Definition at line 165 of file fiff_constants.h.

◆ FIFFV_COIL_EEG_DBS

#define FIFFV_COIL_EEG_DBS 160

DBS electrode position in r0.

Definition at line 288 of file fiff_constants.h.

◆ FIFFV_COIL_EEG_ECOG

#define FIFFV_COIL_EEG_ECOG 140

ECoG electrode position in r0.

Definition at line 286 of file fiff_constants.h.

◆ FIFFV_COIL_EEG_SEEG

#define FIFFV_COIL_EEG_SEEG 150

sEEG electrode position in r0.

Definition at line 287 of file fiff_constants.h.

◆ FIFFV_COIL_KIT_GRAD

#define FIFFV_COIL_KIT_GRAD 6001

KIT MIT gradiometer.

Definition at line 184 of file fiff_constants.h.

◆ FIFFV_COIL_KIT_REF_GRAD

#define FIFFV_COIL_KIT_REF_GRAD 6002

KIT MIT reference magnetometer.

Definition at line 185 of file fiff_constants.h.

◆ FIFFV_COIL_KRISS_GRAD

#define FIFFV_COIL_KRISS_GRAD 9001

KRISS gradiometer.

Definition at line 194 of file fiff_constants.h.

◆ FIFFV_COIL_MAGNES_GRAD

#define FIFFV_COIL_MAGNES_GRAD 4002

Magnes WH gradiometer .

Definition at line 179 of file fiff_constants.h.

◆ FIFFV_COIL_MAGNES_MAG

#define FIFFV_COIL_MAGNES_MAG 4001

Magnes WH magnetometer.

Definition at line 178 of file fiff_constants.h.

◆ FIFFV_COIL_MCG_42

#define FIFFV_COIL_MCG_42 1000

For testing the MCG software.

Definition at line 167 of file fiff_constants.h.

◆ FIFFV_COIL_NM_122

#define FIFFV_COIL_NM_122 2

Neuromag 122 coils.

Definition at line 162 of file fiff_constants.h.

◆ FIFFV_COIL_NM_24

#define FIFFV_COIL_NM_24 3

Old 24 channel system in HUT.

Definition at line 163 of file fiff_constants.h.

◆ FIFFV_COIL_NM_MCG_AXIAL

#define FIFFV_COIL_NM_MCG_AXIAL 4

The axial devices in the HUCS MCG system.

Definition at line 164 of file fiff_constants.h.

◆ FIFFV_COIL_NONE

#define FIFFV_COIL_NONE 0

The location info contains no data.

Definition at line 160 of file fiff_constants.h.

◆ FIFFV_COIL_POINT_MAGNETOMETER

#define FIFFV_COIL_POINT_MAGNETOMETER 2000

Simple point magnetometer.

Definition at line 168 of file fiff_constants.h.

◆ FIFFV_COIL_QUSPIN_ZFOPM_MAG

#define FIFFV_COIL_QUSPIN_ZFOPM_MAG 8001

QuSpin ZFOPM magnetometer.

Definition at line 193 of file fiff_constants.h.

◆ FIFFV_COIL_VV_MAG_T1

#define FIFFV_COIL_VV_MAG_T1 3022

Vectorview SQ20483N magnetometer.

Definition at line 175 of file fiff_constants.h.

◆ FIFFV_COIL_VV_MAG_T2

#define FIFFV_COIL_VV_MAG_T2 3023

Vectorview SQ20483-A magnetometer.

Definition at line 176 of file fiff_constants.h.

◆ FIFFV_COIL_VV_MAG_T3

#define FIFFV_COIL_VV_MAG_T3 3024

Vectorview SQ20950N magnetometer.

Definition at line 177 of file fiff_constants.h.

◆ FIFFV_COIL_VV_MAG_W

#define FIFFV_COIL_VV_MAG_W 3021

VV prototype wirewound magnetometer.

Definition at line 174 of file fiff_constants.h.

◆ FIFFV_COIL_VV_PLANAR_T1

#define FIFFV_COIL_VV_PLANAR_T1 3012

Vectorview SQ20483N planar gradiometer.

Definition at line 171 of file fiff_constants.h.

◆ FIFFV_COIL_VV_PLANAR_T2

#define FIFFV_COIL_VV_PLANAR_T2 3013

Vectorview SQ20483N-A planar gradiometer.

Definition at line 172 of file fiff_constants.h.

◆ FIFFV_COIL_VV_PLANAR_T3

#define FIFFV_COIL_VV_PLANAR_T3 3014

Vectorview SQ20950N planar gradiometer.

Definition at line 173 of file fiff_constants.h.

◆ FIFFV_COIL_VV_PLANAR_W

#define FIFFV_COIL_VV_PLANAR_W 3011

VV prototype wirewound planar sensor.

Definition at line 170 of file fiff_constants.h.

◆ FIFFV_COORD_CT

#define FIFFV_COORD_CT FIFF_COORD_MRI

Definition at line 221 of file fiff_constants.h.

◆ FIFFV_COORD_CT_SLICE

#define FIFFV_COORD_CT_SLICE FIFF_COORD_MRI_SLICE

Definition at line 222 of file fiff_constants.h.

◆ FIFFV_COORD_DEVICE

#define FIFFV_COORD_DEVICE 1

Definition at line 212 of file fiff_constants.h.

◆ FIFFV_COORD_DICOM_DEVICE

#define FIFFV_COORD_DICOM_DEVICE 8

Definition at line 224 of file fiff_constants.h.

◆ FIFFV_COORD_HEAD

#define FIFFV_COORD_HEAD 4

Definition at line 215 of file fiff_constants.h.

◆ FIFFV_COORD_HPI

#define FIFFV_COORD_HPI 3

Definition at line 214 of file fiff_constants.h.

◆ FIFFV_COORD_IMAGING_DEVICE

#define FIFFV_COORD_IMAGING_DEVICE 9

Definition at line 225 of file fiff_constants.h.

◆ FIFFV_COORD_ISOTRAK

#define FIFFV_COORD_ISOTRAK 2

Definition at line 213 of file fiff_constants.h.

◆ FIFFV_COORD_MRI

#define FIFFV_COORD_MRI 5

Definition at line 216 of file fiff_constants.h.

◆ FIFFV_COORD_MRI_DISPLAY

#define FIFFV_COORD_MRI_DISPLAY 7

Definition at line 218 of file fiff_constants.h.

◆ FIFFV_COORD_MRI_SLICE

#define FIFFV_COORD_MRI_SLICE 6

Definition at line 217 of file fiff_constants.h.

◆ FIFFV_COORD_TORSO

#define FIFFV_COORD_TORSO 100

Definition at line 227 of file fiff_constants.h.

◆ FIFFV_COORD_UNKNOWN

#define FIFFV_COORD_UNKNOWN 0

Definition at line 211 of file fiff_constants.h.

◆ FIFFV_COORD_XRAY

#define FIFFV_COORD_XRAY FIFF_COORD_MRI

Definition at line 219 of file fiff_constants.h.

◆ FIFFV_COORD_XRAY_SLICE

#define FIFFV_COORD_XRAY_SLICE FIFF_COORD_MRI_SLICE

Definition at line 220 of file fiff_constants.h.

◆ FIFFV_DBS_CH

#define FIFFV_DBS_CH 2003

Deep brain stimulation electrodes.

Definition at line 281 of file fiff_constants.h.

◆ FIFFV_DIPOLE_WAVE_CH

#define FIFFV_DIPOLE_WAVE_CH 1000 /* Dipole time curve */

Definition at line 78 of file fiff_constants.h.

◆ FIFFV_ECG_CH

#define FIFFV_ECG_CH 402

Definition at line 272 of file fiff_constants.h.

◆ FIFFV_ECOG_CH

#define FIFFV_ECOG_CH 2001

Electrocorticography (subdural grids/strips).

Definition at line 279 of file fiff_constants.h.

◆ FIFFV_EEG_CH

#define FIFFV_EEG_CH FIFFV_EL_CH

Definition at line 267 of file fiff_constants.h.

◆ FIFFV_EL_CH

#define FIFFV_EL_CH 2

Definition at line 263 of file fiff_constants.h.

◆ FIFFV_EMG_CH

#define FIFFV_EMG_CH 302

Definition at line 271 of file fiff_constants.h.

◆ FIFFV_EOG_CH

#define FIFFV_EOG_CH 202

Definition at line 270 of file fiff_constants.h.

◆ FIFFV_FALSE

#define FIFFV_FALSE 0

Definition at line 54 of file fiff_constants.h.

◆ FIFFV_GOODNESS_FIT_CH

#define FIFFV_GOODNESS_FIT_CH 1001 /* Goodness of fit */

Definition at line 79 of file fiff_constants.h.

◆ FIFFV_HPI_ERR

#define FIFFV_HPI_ERR 708

Estimation error in continuous hpi.

Definition at line 73 of file fiff_constants.h.

◆ FIFFV_HPI_G

#define FIFFV_HPI_G 707

Goodness-of-fit in continuous hpi.

Definition at line 72 of file fiff_constants.h.

◆ FIFFV_HPI_MOV

#define FIFFV_HPI_MOV 709

Estimated head movement speed in continuous hpi.

Definition at line 74 of file fiff_constants.h.

◆ FIFFV_LAYER_BRAIN

#define FIFFV_LAYER_BRAIN 1

Definition at line 244 of file fiff_constants.h.

◆ FIFFV_LAYER_CSF

#define FIFFV_LAYER_CSF 2

Definition at line 245 of file fiff_constants.h.

◆ FIFFV_LAYER_HEAD

#define FIFFV_LAYER_HEAD 4

Definition at line 247 of file fiff_constants.h.

◆ FIFFV_LAYER_SKULL

#define FIFFV_LAYER_SKULL 3

Definition at line 246 of file fiff_constants.h.

◆ FIFFV_MAGN_CH

#define FIFFV_MAGN_CH 1

Definition at line 262 of file fiff_constants.h.

◆ FIFFV_MCG_CH

#define FIFFV_MCG_CH 201

Definition at line 265 of file fiff_constants.h.

◆ FIFFV_MEG_CH

#define FIFFV_MEG_CH FIFFV_MAGN_CH

Definition at line 264 of file fiff_constants.h.

◆ FIFFV_MISC_CH

#define FIFFV_MISC_CH 502

Definition at line 273 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_CTF_DEVICE

#define FIFFV_MNE_COORD_CTF_DEVICE 1001

CTF device coordinates

Definition at line 490 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_CTF_HEAD

#define FIFFV_MNE_COORD_CTF_HEAD 1004

CTF head coordinates

Definition at line 491 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_FS_TAL

#define FIFFV_MNE_COORD_FS_TAL 2006

FreeSurfer Talairach coordinates

Definition at line 497 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_FS_TAL_GTZ

#define FIFFV_MNE_COORD_FS_TAL_GTZ 2004

FreeSurfer Talairach coordinates (MNI z > 0)

Definition at line 495 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_FS_TAL_LTZ

#define FIFFV_MNE_COORD_FS_TAL_LTZ 2005

FreeSurfer Talairach coordinates (MNI z < 0)

Definition at line 496 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_MNI_TAL

#define FIFFV_MNE_COORD_MNI_TAL 2003

MNI Talairach coordinates

Definition at line 494 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_MRI_VOXEL

#define FIFFV_MNE_COORD_MRI_VOXEL 2001

The MRI voxel coordinates

Definition at line 492 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_RAS

#define FIFFV_MNE_COORD_RAS 2002

FsSurface RAS coordinates with non-zero origin

Definition at line 493 of file fiff_constants.h.

◆ FIFFV_MNE_COORD_TUFTS_EEG

#define FIFFV_MNE_COORD_TUFTS_EEG 300

For Tufts EEG data

Definition at line 489 of file fiff_constants.h.

◆ FIFFV_MNE_COV_CH_EEG

#define FIFFV_MNE_COV_CH_EEG 2

EEG [V]

Definition at line 479 of file fiff_constants.h.

◆ FIFFV_MNE_COV_CH_MEG_GRAD

#define FIFFV_MNE_COV_CH_MEG_GRAD 1

Planar gradiometer [T/m]

Definition at line 478 of file fiff_constants.h.

◆ FIFFV_MNE_COV_CH_MEG_MAG

#define FIFFV_MNE_COV_CH_MEG_MAG 0

Axial gradiometer or magnetometer [T]

Definition at line 477 of file fiff_constants.h.

◆ FIFFV_MNE_COV_CH_UNKNOWN

#define FIFFV_MNE_COV_CH_UNKNOWN -1

No idea

Definition at line 476 of file fiff_constants.h.

◆ FIFFV_MNE_DEPTH_PRIOR_COV

#define FIFFV_MNE_DEPTH_PRIOR_COV 5

The depth weighting prior

Definition at line 462 of file fiff_constants.h.

◆ FIFFV_MNE_EEG

#define FIFFV_MNE_EEG 2

Definition at line 453 of file fiff_constants.h.

◆ FIFFV_MNE_FIXED_ORI

#define FIFFV_MNE_FIXED_ORI 1

Definition at line 449 of file fiff_constants.h.

◆ FIFFV_MNE_FMRI_PRIOR_COV

#define FIFFV_MNE_FMRI_PRIOR_COV 3

Definition at line 460 of file fiff_constants.h.

◆ FIFFV_MNE_FREE_ORI

#define FIFFV_MNE_FREE_ORI 2

Definition at line 450 of file fiff_constants.h.

◆ FIFFV_MNE_MEG

#define FIFFV_MNE_MEG 1

Definition at line 452 of file fiff_constants.h.

◆ FIFFV_MNE_MEG_EEG

#define FIFFV_MNE_MEG_EEG 3

Definition at line 454 of file fiff_constants.h.

◆ FIFFV_MNE_NOISE_COV

#define FIFFV_MNE_NOISE_COV 1

This is what it should have been called

Definition at line 458 of file fiff_constants.h.

◆ FIFFV_MNE_ORIENT_PRIOR_COV

#define FIFFV_MNE_ORIENT_PRIOR_COV 6

The orientation prior

Definition at line 463 of file fiff_constants.h.

◆ FIFFV_MNE_PROJ_ITEM_EEG_AVREF

#define FIFFV_MNE_PROJ_ITEM_EEG_AVREF 10

Definition at line 484 of file fiff_constants.h.

◆ FIFFV_MNE_SENSOR_COV

#define FIFFV_MNE_SENSOR_COV 1

Definition at line 457 of file fiff_constants.h.

◆ FIFFV_MNE_SIGNAL_COV

#define FIFFV_MNE_SIGNAL_COV 4

This will be potentially employed in beamformers

Definition at line 461 of file fiff_constants.h.

◆ FIFFV_MNE_SOURCE_COV

#define FIFFV_MNE_SOURCE_COV 2

Definition at line 459 of file fiff_constants.h.

◆ FIFFV_MNE_SPACE_DISCRETE

#define FIFFV_MNE_SPACE_DISCRETE 3

Definition at line 471 of file fiff_constants.h.

◆ FIFFV_MNE_SPACE_SURFACE

#define FIFFV_MNE_SPACE_SURFACE 1

Definition at line 469 of file fiff_constants.h.

◆ FIFFV_MNE_SPACE_UNKNOWN

#define FIFFV_MNE_SPACE_UNKNOWN -1

Definition at line 468 of file fiff_constants.h.

◆ FIFFV_MNE_SPACE_VOLUME

#define FIFFV_MNE_SPACE_VOLUME 2

Definition at line 470 of file fiff_constants.h.

◆ FIFFV_MNE_SURF_LEFT_HEMI

#define FIFFV_MNE_SURF_LEFT_HEMI 101

Definition at line 294 of file fiff_constants.h.

◆ FIFFV_MNE_SURF_RIGHT_HEMI

#define FIFFV_MNE_SURF_RIGHT_HEMI 102

Definition at line 295 of file fiff_constants.h.

◆ FIFFV_MNE_SURF_UNKNOWN

#define FIFFV_MNE_SURF_UNKNOWN -1

Definition at line 293 of file fiff_constants.h.

◆ FIFFV_MNE_UNKNOWN_COV

#define FIFFV_MNE_UNKNOWN_COV 0

Definition at line 456 of file fiff_constants.h.

◆ FIFFV_MOVE

#define FIFFV_MOVE 1

Definition at line 229 of file fiff_constants.h.

◆ FIFFV_NEXT_NONE

#define FIFFV_NEXT_NONE -1

Definition at line 257 of file fiff_constants.h.

◆ FIFFV_NEXT_SEQ

#define FIFFV_NEXT_SEQ 0

Definition at line 256 of file fiff_constants.h.

◆ FIFFV_NO_MOVE

#define FIFFV_NO_MOVE 0

Definition at line 230 of file fiff_constants.h.

◆ FIFFV_POINT_CARDINAL

#define FIFFV_POINT_CARDINAL 1

Definition at line 300 of file fiff_constants.h.

◆ FIFFV_POINT_CHEST_LEFT

#define FIFFV_POINT_CHEST_LEFT 1

Definition at line 204 of file fiff_constants.h.

◆ FIFFV_POINT_CHEST_RIGHT

#define FIFFV_POINT_CHEST_RIGHT 3

Definition at line 206 of file fiff_constants.h.

◆ FIFFV_POINT_CHEST_STERNUM

#define FIFFV_POINT_CHEST_STERNUM 2

Definition at line 205 of file fiff_constants.h.

◆ FIFFV_POINT_ECG

#define FIFFV_POINT_ECG FIFFV_POINT_EEG

Definition at line 303 of file fiff_constants.h.

◆ FIFFV_POINT_EEG

#define FIFFV_POINT_EEG 3

Definition at line 302 of file fiff_constants.h.

◆ FIFFV_POINT_EXTRA

#define FIFFV_POINT_EXTRA 4

Definition at line 304 of file fiff_constants.h.

◆ FIFFV_POINT_HPI

#define FIFFV_POINT_HPI 2

Definition at line 301 of file fiff_constants.h.

◆ FIFFV_POINT_LPA

#define FIFFV_POINT_LPA 1

Definition at line 306 of file fiff_constants.h.

◆ FIFFV_POINT_NASION

#define FIFFV_POINT_NASION 2

Definition at line 307 of file fiff_constants.h.

◆ FIFFV_POINT_RPA

#define FIFFV_POINT_RPA 3

Definition at line 308 of file fiff_constants.h.

◆ FIFFV_QUAT_0

#define FIFFV_QUAT_0 700

Quaternion parameter q0; obsolete for unit quaternion.

Definition at line 65 of file fiff_constants.h.

◆ FIFFV_QUAT_1

#define FIFFV_QUAT_1 701

Quaternion parameter q1; rotation.

Definition at line 66 of file fiff_constants.h.

◆ FIFFV_QUAT_2

#define FIFFV_QUAT_2 702

Quaternion parameter q2; rotation.

Definition at line 67 of file fiff_constants.h.

◆ FIFFV_QUAT_3

#define FIFFV_QUAT_3 703

Quaternion parameter q3; rotation.

Definition at line 68 of file fiff_constants.h.

◆ FIFFV_QUAT_4

#define FIFFV_QUAT_4 704

Quaternion parameter q4; translation.

Definition at line 69 of file fiff_constants.h.

◆ FIFFV_QUAT_5

#define FIFFV_QUAT_5 705

Quaternion parameter q5; translation.

Definition at line 70 of file fiff_constants.h.

◆ FIFFV_QUAT_6

#define FIFFV_QUAT_6 706

Quaternion parameter q6; translation.

Definition at line 71 of file fiff_constants.h.

◆ FIFFV_REF_MEG_CH

#define FIFFV_REF_MEG_CH 301

CTF coil and channel type.

Definition at line 266 of file fiff_constants.h.

◆ FIFFV_RESP_CH

#define FIFFV_RESP_CH 602

Respiration monitoring

Definition at line 274 of file fiff_constants.h.

◆ FIFFV_SEEG_CH

#define FIFFV_SEEG_CH 2002

Stereoelectroencephalography (depth electrodes).

Definition at line 280 of file fiff_constants.h.

◆ FIFFV_STIM_CH

#define FIFFV_STIM_CH 3

Definition at line 268 of file fiff_constants.h.

◆ FIFFV_TRUE

#define FIFFV_TRUE 1

Definition at line 53 of file fiff_constants.h.

◆ FIFFV_XFIT_MAP_SURF_HEAD

#define FIFFV_XFIT_MAP_SURF_HEAD 1

Xfit contours on a head surface.

Definition at line 250 of file fiff_constants.h.

◆ FIFFV_XFIT_MAP_SURF_SENSORS

#define FIFFV_XFIT_MAP_SURF_SENSORS 0

Xfit contours on the sensor array.

Definition at line 249 of file fiff_constants.h.

◆ FIFFV_XFIT_MAP_SURF_SPHERE

#define FIFFV_XFIT_MAP_SURF_SPHERE 2

Xfit contours on a spherical surface.

Definition at line 251 of file fiff_constants.h.

Namespaces

Macros

Detailed Description

Macro Definition Documentation

◆ FIFF_FAIL

◆ FIFF_MNE_CH_NAME_LIST

◆ FIFF_MNE_COL_NAMES

◆ FIFF_MNE_COORD_FRAME

◆ FIFF_MNE_COV

◆ FIFF_MNE_COV_DIAG

◆ FIFF_MNE_COV_DIM

◆ FIFF_MNE_COV_EIGENVALUES

◆ FIFF_MNE_COV_EIGENVECTORS

◆ FIFF_MNE_COV_KIND

◆ FIFF_MNE_COV_NFREE

◆ FIFF_MNE_CTF_COMP_CALIBRATED

◆ FIFF_MNE_CTF_COMP_DATA

◆ FIFF_MNE_CTF_COMP_KIND

◆ FIFF_MNE_ENV_COMMAND_LINE

◆ FIFF_MNE_ENV_WORKING_DIR

◆ FIFF_MNE_EVENT_LIST

◆ FIFF_MNE_FILE_NAME

◆ FIFF_MNE_FORWARD_SOLUTION

◆ FIFF_MNE_FORWARD_SOLUTION_GRAD

◆ FIFF_MNE_HEMI

◆ FIFF_MNE_INCLUDED_METHODS

◆ FIFF_MNE_INVERSE_FIELDS

◆ FIFF_MNE_INVERSE_FULL

◆ FIFF_MNE_INVERSE_LEADS

◆ FIFF_MNE_INVERSE_LEADS_WEIGHTED

◆ FIFF_MNE_INVERSE_SING

◆ FIFF_MNE_INVERSE_SOURCE_ORIENTATIONS

◆ FIFF_MNE_MORPH_MAP

◆ FIFF_MNE_MORPH_MAP_FROM

◆ FIFF_MNE_MORPH_MAP_TO

◆ FIFF_MNE_NCOL

◆ FIFF_MNE_NROW

◆ FIFF_MNE_PRIORS_USED

◆ FIFF_MNE_PROJ_ITEM_ACTIVE

◆ FIFF_MNE_ROW_NAMES

◆ FIFF_MNE_RT_CLIENT_ID

◆ FIFF_MNE_RT_COMMAND

◆ FIFF_MNE_SOURCE_ORIENTATION

◆ FIFF_MNE_SOURCE_SPACE_DIST

◆ FIFF_MNE_SOURCE_SPACE_DIST_LIMIT

◆ FIFF_MNE_SOURCE_SPACE_ID

◆ FIFF_MNE_SOURCE_SPACE_INTERPOLATOR

◆ FIFF_MNE_SOURCE_SPACE_MRI_FILE

◆ FIFF_MNE_SOURCE_SPACE_NEAREST

◆ FIFF_MNE_SOURCE_SPACE_NEAREST_DIST

◆ FIFF_MNE_SOURCE_SPACE_NORMALS

◆ FIFF_MNE_SOURCE_SPACE_NPOINTS

◆ FIFF_MNE_SOURCE_SPACE_NTRI

◆ FIFF_MNE_SOURCE_SPACE_NUSE

◆ FIFF_MNE_SOURCE_SPACE_NUSE_TRI

◆ FIFF_MNE_SOURCE_SPACE_POINTS

◆ FIFF_MNE_SOURCE_SPACE_SELECTION

◆ FIFF_MNE_SOURCE_SPACE_TRIANGLES

◆ FIFF_MNE_SOURCE_SPACE_TYPE

◆ FIFF_MNE_SOURCE_SPACE_USE_TRIANGLES

◆ FIFF_MNE_SOURCE_SPACE_VOXEL_DIMS

◆ FIFF_OK

◆ FIFF_UNIT_A

◆ FIFF_UNIT_AM

◆ FIFF_UNIT_AM_M2

◆ FIFF_UNIT_AM_M3

◆ FIFF_UNIT_C

◆ FIFF_UNIT_CD

◆ FIFF_UNIT_CEL

◆ FIFF_UNIT_F

◆ FIFF_UNIT_H

◆ FIFF_UNIT_HZ

◆ FIFF_UNIT_J

◆ FIFF_UNIT_K

◆ FIFF_UNIT_KG

◆ FIFF_UNIT_LM

◆ FIFF_UNIT_LX

◆ FIFF_UNIT_M

◆ FIFF_UNIT_MHO

◆ FIFF_UNIT_MOL
