FIFF tag-kind, block-kind and type-code numerical definitions, authoritative for FIFFLIB. More...
Go to the source code of this file.
Namespaces | |
| namespace | FIFFLIB |
| FIFF file I/O, in-memory data structures and high-level readers/writers. | |
FIFF tag-kind, block-kind and type-code numerical definitions, authoritative for FIFFLIB.
SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2012-2026 MNE-CPP Authors
Companion to fiff_constants.h that focuses on the value space of tag kinds (the FIFF_* numbers below 1000), of block kinds (FIFFB_*) and of the 32-bit FIFF type descriptors (FIFFT_*). The header doubles as the reference for the conventions used throughout the codebase: the upper byte of a type code encodes the fundamental structure (scalar vs. multidimensional matrix), the lower bytes encode the element type, and matrices additionally carry a dense / CCS / RCS sparse-coding indicator multiplexed into the same word (see fiff_tag.h for the bit masks).
These numbers are part of the on-disk FIFF format and are shared with mne.io.constants in MNE-Python; do not renumber them.
Definition in file fiff_file.h.
| #define FIFF_ARTEF_REMOVAL 221 |
Artifact removal.
Definition at line 467 of file fiff_file.h.
| #define FIFF_ASPECT_KIND 210 |
Aspect label.
Definition at line 456 of file fiff_file.h.
| #define FIFF_BAD_CHS 220 |
List of bad channels.
Definition at line 466 of file fiff_file.h.
| #define FIFF_BEM_APPROX 3111 |
int approximation method, see below.
Definition at line 735 of file fiff_file.h.
| #define FIFF_BEM_COORD_FRAME 3112 |
The coordinate frame of the model.
Definition at line 736 of file fiff_file.h.
| #define FIFF_BEM_POT_SOLUTION 3110 |
float ** The solution matrix.
Definition at line 734 of file fiff_file.h.
| #define FIFF_BEM_SIGMA 3113 |
Conductivity of a compartment.
Definition at line 737 of file fiff_file.h.
| #define FIFF_BEM_SURF_CURV_VALUES 3109 |
float the two curvature values (nnode,2).
Definition at line 732 of file fiff_file.h.
| #define FIFF_BEM_SURF_CURVS 3108 |
float surface node first principal curvature unit vectors (nnode,3).
Definition at line 731 of file fiff_file.h.
| #define FIFF_BEM_SURF_ID 3101 |
int surface number.
Definition at line 724 of file fiff_file.h.
| #define FIFF_BEM_SURF_NAME 3102 |
string surface name.
Definition at line 725 of file fiff_file.h.
| #define FIFF_BEM_SURF_NNODE 3103 |
int # of nodes on a surface.
Definition at line 726 of file fiff_file.h.
| #define FIFF_BEM_SURF_NODES 3105 |
float surface nodes (nnode,3).
Definition at line 728 of file fiff_file.h.
| #define FIFF_BEM_SURF_NORMALS 3107 |
float surface node normal unit vectors (nnode,3).
Definition at line 730 of file fiff_file.h.
| #define FIFF_BEM_SURF_NTRI 3104 |
int # number of triangles on a surface.
Definition at line 727 of file fiff_file.h.
| #define FIFF_BEM_SURF_TRIANGLES 3106 |
int surface triangles (ntri,3).
Definition at line 729 of file fiff_file.h.
| #define FIFF_BLOCK_END 105 |
Definition at line 321 of file fiff_file.h.
| #define FIFF_BLOCK_ID 103 |
Definition at line 319 of file fiff_file.h.
| #define FIFF_BLOCK_NAME 111 |
Definition at line 327 of file fiff_file.h.
| #define FIFF_BLOCK_START 104 |
Definition at line 320 of file fiff_file.h.
| #define FIFF_BLOCK_VERSION 112 |
Definition at line 328 of file fiff_file.h.
| #define FIFF_CH_CAL 254 |
float "Calibration coefficients from output voltage to some real units".
Definition at line 514 of file fiff_file.h.
| #define FIFF_CH_CALS_VEC 224 |
This will not occur in new files.
Definition at line 470 of file fiff_file.h.
| #define FIFF_CH_DACQ_NAME 258 |
string "Name of the channel in the data acquisition system. Same as fiffChInfoRec.name.".
Definition at line 518 of file fiff_file.h.
| #define FIFF_CH_INFO 203 |
Channel descriptor.
Definition at line 449 of file fiff_file.h.
| #define FIFF_CH_KIND 252 |
enum(ch_kind) "Channel type. Corresponds to fiffChInfoRec.kind field".
Definition at line 512 of file fiff_file.h.
| #define FIFF_CH_LOGICAL_NO 251 |
int32 "Channel logical number. Corresponds to fiffChInfoRec.logNo field".
Definition at line 511 of file fiff_file.h.
| #define FIFF_CH_NAME_LIST 3507 |
Alias of FIFF_MNE_CH_NAME_LIST.
Definition at line 836 of file fiff_file.h.
| #define FIFF_CH_POS 255 |
ch_pos_rec "Channel position".
Definition at line 515 of file fiff_file.h.
| #define FIFF_CH_POS_VEC 214 |
Channel positions.
Definition at line 460 of file fiff_file.h.
| #define FIFF_CH_RANGE 253 |
float "Conversion from recorded number to (possibly virtual) voltage at the output".
Definition at line 513 of file fiff_file.h.
| #define FIFF_CH_SCAN_NO 250 |
int32 "Channel scan number. Corresponds to fiffChInfoRec.scanNo field".
Definition at line 510 of file fiff_file.h.
| #define FIFF_CH_UNIT 256 |
enum(unit) "Unit of the data".
Definition at line 516 of file fiff_file.h.
| #define FIFF_CH_UNIT_MUL 257 |
int "Unit multiplier exponent.
Definition at line 517 of file fiff_file.h.
| #define FIFF_CLOSE_FILE 2 |
Definition at line 281 of file fiff_file.h.
| #define FIFF_COMMENT 206 |
This is used in a questionable way...
Definition at line 452 of file fiff_file.h.
| #define FIFF_CONDUCTOR_MODEL_KIND 3000 |
What kind of conductor model.
Definition at line 709 of file fiff_file.h.
| #define FIFF_CONNECTION_CHECK 7 |
Definition at line 286 of file fiff_file.h.
| #define FIFF_CONTINUE_FILE 17 |
Used to inform that data is saved into a continuation file.
Definition at line 296 of file fiff_file.h.
| #define FIFF_COORD_TRANS 222 |
Coordinate transformation.
Definition at line 468 of file fiff_file.h.
| #define FIFF_CREATOR 113 |
Program that created the file (string) .
Definition at line 329 of file fiff_file.h.
| #define FIFF_DACQ_PARS 150 |
Definition at line 343 of file fiff_file.h.
| #define FIFF_DACQ_STIM 151 |
Definition at line 344 of file fiff_file.h.
| #define FIFF_DACQ_SYSTEM_TYPE 14 |
Definition at line 293 of file fiff_file.h.
| #define FIFF_DATA_BUFFER 300 |
Buffer containing measurement data.
Definition at line 549 of file fiff_file.h.
| #define FIFF_DATA_BUFFER2 304 |
Int_32 data buffer in dacq outgen.
Definition at line 553 of file fiff_file.h.
| #define FIFF_DATA_PACK 202 |
How the raw data is packed.
Definition at line 448 of file fiff_file.h.
| #define FIFF_DATA_SKIP 301 |
Data skip in buffers.
Definition at line 550 of file fiff_file.h.
| #define FIFF_DATA_SKIP_SAMP 303 |
Data skip in samples.
Definition at line 552 of file fiff_file.h.
| #define FIFF_DECOUPLER_MATRIX 800 |
Definition at line 614 of file fiff_file.h.
| #define FIFF_DESCRIPTION FIFF_COMMENT |
(Textual) Description of an object.
Definition at line 479 of file fiff_file.h.
| #define FIFF_DIG_POINT 213 |
Digitization point.
Definition at line 459 of file fiff_file.h.
| #define FIFF_DIG_STRING 234 |
String of digitized points.
Definition at line 480 of file fiff_file.h.
| #define FIFF_DIR 102 |
Definition at line 318 of file fiff_file.h.
| #define FIFF_DIR_POINTER 101 |
Definition at line 317 of file fiff_file.h.
| #define FIFF_DISCARD_FILE 3 |
Definition at line 282 of file fiff_file.h.
| #define FIFF_ECHO 12 |
Definition at line 291 of file fiff_file.h.
| #define FIFF_EPOCH 302 |
Buffer containing one epoch and channel.
Definition at line 551 of file fiff_file.h.
| #define FIFF_ERROR_MESSAGE 4 |
Definition at line 283 of file fiff_file.h.
| #define FIFF_EVENT_BITS 603 |
Event bits array.
Definition at line 594 of file fiff_file.h.
| #define FIFF_EVENT_CHANNEL 602 |
Event channel name.
Definition at line 593 of file fiff_file.h.
| #define FIFF_EVENT_CHANNELS 600 |
Event channel numbers.
Definition at line 587 of file fiff_file.h.
| #define FIFF_EVENT_COMMENT 227 |
Comment about the events used in averaging.
Definition at line 473 of file fiff_file.h.
| #define FIFF_EVENT_LIST 601 |
List of events (integers: <sample before after>
Definition at line 588 of file fiff_file.h.
| #define FIFF_EXPERIMENTER 212 |
Experimenter name.
Definition at line 458 of file fiff_file.h.
| #define FIFF_FATAL_ERROR_MESSAGE 6 |
Definition at line 285 of file fiff_file.h.
| #define FIFF_FILE_ID 100 |
Definition at line 316 of file fiff_file.h.
| #define FIFF_FIRST_SAMPLE 208 |
The first sample of an epoch.
Definition at line 454 of file fiff_file.h.
| #define FIFF_FIRST_TIME 229 |
Time scale minimum.
Definition at line 475 of file fiff_file.h.
| #define FIFF_FREE_BLOCK 107 |
Definition at line 323 of file fiff_file.h.
| #define FIFF_FREE_LIST 106 |
Definition at line 322 of file fiff_file.h.
| #define FIFF_GANTRY_ANGLE 282 |
Tilt angle of the dewar in degrees.
Definition at line 548 of file fiff_file.h.
| #define FIFF_HIGHPASS 223 |
Analog highpass.
Definition at line 469 of file fiff_file.h.
| #define FIFF_HPI_BAD_CHS 225 |
List of channels considered to be bad in hpi.
Definition at line 471 of file fiff_file.h.
| #define FIFF_HPI_COIL_FREQ 236 |
HPI coil excitation frequency.
Definition at line 483 of file fiff_file.h.
| #define FIFF_HPI_COIL_MOMENTS 240 |
Estimated moment vectors for the HPI coil magnetic dipoles.
Definition at line 493 of file fiff_file.h.
| #define FIFF_HPI_COIL_NO 245 |
Coil number listed by HPI measurement.
Definition at line 498 of file fiff_file.h.
| #define FIFF_HPI_COILS_USED 246 |
List of coils finally used when the transformation was computed
Definition at line 499 of file fiff_file.h.
| #define FIFF_HPI_CORR_COEFF 226 |
Hpi curve fit correlations.
Definition at line 472 of file fiff_file.h.
| #define FIFF_HPI_DIGITIZATION_ORDER 247 |
Which Isotrak digitization point corresponds to each of the coils energized
Definition at line 501 of file fiff_file.h.
| #define FIFF_HPI_FIT_ACCEPT 242 |
Bitmask indicating acceptance (see below).
Definition at line 495 of file fiff_file.h.
| #define FIFF_HPI_FIT_DIST_LIMIT 244 |
Limit for the coil distance difference.
Definition at line 497 of file fiff_file.h.
| #define FIFF_HPI_FIT_GOOD_LIMIT 243 |
Limit for the goodness-of-fit.
Definition at line 496 of file fiff_file.h.
| #define FIFF_HPI_FIT_GOODNESS 241 |
Three floats indicating the goodness of fit.
Definition at line 494 of file fiff_file.h.
| #define FIFF_HPI_NCOIL 216 |
Number of HPI coils.
Definition at line 462 of file fiff_file.h.
| #define FIFF_HPI_SLOPES 215 |
HPI data.
Definition at line 461 of file fiff_file.h.
| #define FIFF_INDEX 5002 |
Definition at line 860 of file fiff_file.h.
| #define FIFF_INDEX_KIND 5001 |
Definition at line 859 of file fiff_file.h.
| #define FIFF_JITTER_MAX 18 |
Used to tell the jitter in the timing of data packets.
Definition at line 297 of file fiff_file.h.
| #define FIFF_LAST_SAMPLE 209 |
The last sample of an epoch.
Definition at line 455 of file fiff_file.h.
| #define FIFF_LINE_FREQ 235 |
Line interference frequency.
Definition at line 482 of file fiff_file.h.
| #define FIFF_LOWPASS 219 |
Analog lowpass.
Definition at line 465 of file fiff_file.h.
| #define FIFF_MEAS_DATE 204 |
Measurement date.
Definition at line 450 of file fiff_file.h.
| #define FIFF_MODIFIER 114 |
Program that modified the file (string).
Definition at line 330 of file fiff_file.h.
| #define FIFF_MRI_BOUNDING_BOX 2009 |
Definition at line 645 of file fiff_file.h.
| #define FIFF_MRI_DEPTH 2014 |
Definition at line 650 of file fiff_file.h.
| #define FIFF_MRI_DEPTH_M 2015 |
Definition at line 651 of file fiff_file.h.
| #define FIFF_MRI_HEIGHT 2012 |
Definition at line 648 of file fiff_file.h.
| #define FIFF_MRI_HEIGHT_M 2013 |
Definition at line 649 of file fiff_file.h.
| #define FIFF_MRI_MRILAB_SETUP 2100 |
Definition at line 663 of file fiff_file.h.
| #define FIFF_MRI_ORIG_PIXEL_DATA_OFFSET 2023 |
Definition at line 658 of file fiff_file.h.
| #define FIFF_MRI_ORIG_PIXEL_ENCODING 2022 |
Definition at line 657 of file fiff_file.h.
| #define FIFF_MRI_ORIG_SOURCE_FORMAT 2021 |
Definition at line 656 of file fiff_file.h.
| #define FIFF_MRI_ORIG_SOURCE_PATH 2020 |
Definition at line 655 of file fiff_file.h.
| #define FIFF_MRI_PIXEL_DATA 2006 |
Definition at line 641 of file fiff_file.h.
| #define FIFF_MRI_PIXEL_DATA_OFFSET 2004 |
Definition at line 639 of file fiff_file.h.
| #define FIFF_MRI_PIXEL_ENCODING 2003 |
Definition at line 638 of file fiff_file.h.
| #define FIFF_MRI_PIXEL_OVERLAY_DATA 2008 |
Definition at line 643 of file fiff_file.h.
| #define FIFF_MRI_PIXEL_OVERLAY_ENCODING 2007 |
Definition at line 642 of file fiff_file.h.
| #define FIFF_MRI_PIXEL_SCALE 2005 |
Definition at line 640 of file fiff_file.h.
| #define FIFF_MRI_SCENE_AIM 2017 |
Definition at line 653 of file fiff_file.h.
| #define FIFF_MRI_SEG_REGION_ID 2200 |
Definition at line 665 of file fiff_file.h.
| #define FIFF_MRI_SOURCE_FORMAT 2002 |
Definition at line 637 of file fiff_file.h.
| #define FIFF_MRI_SOURCE_PATH FIFF_REF_PATH |
Definition at line 636 of file fiff_file.h.
| #define FIFF_MRI_THICKNESS 2016 |
Definition at line 652 of file fiff_file.h.
| #define FIFF_MRI_VOXEL_DATA 2030 |
Definition at line 660 of file fiff_file.h.
| #define FIFF_MRI_VOXEL_ENCODING 2031 |
Definition at line 661 of file fiff_file.h.
| #define FIFF_MRI_WIDTH 2010 |
Definition at line 646 of file fiff_file.h.
| #define FIFF_MRI_WIDTH_M 2011 |
Definition at line 647 of file fiff_file.h.
| #define FIFF_NAME 233 |
Intended to be a short name.
Definition at line 478 of file fiff_file.h.
| #define FIFF_NAVE 207 |
Number of averages.
Definition at line 453 of file fiff_file.h.
| #define FIFF_NCHAN 200 |
Number of channels.
Definition at line 446 of file fiff_file.h.
| #define FIFF_NEW_FILE 1 |
Definition at line 280 of file fiff_file.h.
| #define FIFF_NO_SAMPLES 228 |
Number of samples in an epoch.
Definition at line 474 of file fiff_file.h.
| #define FIFF_NOP 108 |
Definition at line 324 of file fiff_file.h.
| #define FIFF_PARENT_BLOCK_ID 110 |
Definition at line 326 of file fiff_file.h.
| #define FIFF_PARENT_FILE_ID 109 |
Definition at line 325 of file fiff_file.h.
| #define FIFF_PLAYBACK_MODE 16 |
Tell that we are playing data back from the hard disks in the data acquisition front end.
Definition at line 295 of file fiff_file.h.
| #define FIFF_PROJ_AIM 502 |
Projct description.
Definition at line 570 of file fiff_file.h.
| #define FIFF_PROJ_COMMENT 504 |
Comment about the project. Special values used in the project tags.
Definition at line 572 of file fiff_file.h.
| #define FIFF_PROJ_ID 500 |
Project ID.
Definition at line 568 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_CH_NAME_LIST 3417 |
Definition at line 802 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_COMMENT FIFF_COMMENT |
Definition at line 799 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_DEFINITION 3416 |
Definition at line 801 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_DESCRIPTION FIFF_DESCRIPTION |
Definition at line 800 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_DIPOLE FIFF_SOURCE_DIPOLE |
Definition at line 795 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_IGN_CHS 3413 |
Definition at line 796 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_KIND 3411 |
Definition at line 793 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_NVEC 3414 |
Definition at line 797 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_TIME 3412 |
Definition at line 794 of file fiff_file.h.
| #define FIFF_PROJ_ITEM_VECTORS 3415 |
Definition at line 798 of file fiff_file.h.
| #define FIFF_PROJ_NAME 501 |
Project name.
Definition at line 569 of file fiff_file.h.
| #define FIFF_PROJ_PERSONS 503 |
Persons participating in the project.
Definition at line 571 of file fiff_file.h.
| #define FIFF_RAW_PICK_LIST 11 |
Definition at line 290 of file fiff_file.h.
| #define FIFF_RAW_PREBASE 10 |
Definition at line 289 of file fiff_file.h.
| #define FIFF_REF_BLOCK_ID 120 |
Definition at line 337 of file fiff_file.h.
| #define FIFF_REF_EVENT 211 |
Reference event.
Definition at line 457 of file fiff_file.h.
| #define FIFF_REF_FILE_ID 116 |
Definition at line 333 of file fiff_file.h.
| #define FIFF_REF_FILE_NAME 118 |
Definition at line 335 of file fiff_file.h.
| #define FIFF_REF_FILE_NUM 117 |
Definition at line 334 of file fiff_file.h.
| #define FIFF_REF_PATH 1101 |
Definition at line 632 of file fiff_file.h.
| #define FIFF_REF_ROLE 115 |
Definition at line 332 of file fiff_file.h.
| #define FIFF_REQ_EVENT 217 |
Required event.
Definition at line 463 of file fiff_file.h.
| #define FIFF_REQ_LIMIT 218 |
Window for required event.
Definition at line 464 of file fiff_file.h.
| #define FIFF_RESUME_FILING 9 |
Definition at line 288 of file fiff_file.h.
| #define FIFF_RESUME_READING 13 |
Definition at line 292 of file fiff_file.h.
| #define FIFF_SELECT_RAW_CH 15 |
Instruct rawdisp to select this channel.
Definition at line 294 of file fiff_file.h.
| #define FIFF_SFREQ 201 |
Sampling frequency (Hz).
Definition at line 447 of file fiff_file.h.
| #define FIFF_SIGNAL_CHANNEL 237 |
Signal channel name.
Definition at line 484 of file fiff_file.h.
| #define FIFF_SOURCE_DIPOLE 3201 |
Definition at line 777 of file fiff_file.h.
| #define FIFF_SPARSE_CH_NAME_LIST FIFF_PROJ_ITEM_CH_NAME_LIST |
Definition at line 615 of file fiff_file.h.
| #define FIFF_SPHERE_COORD_FRAME 3002 |
Which coordinate frame are we using?.
Definition at line 719 of file fiff_file.h.
| #define FIFF_SPHERE_LAYERS 3003 |
Array of layer structures.
Definition at line 720 of file fiff_file.h.
| #define FIFF_SPHERE_ORIGIN 3001 |
Definition at line 718 of file fiff_file.h.
| #define FIFF_SQUID_BIAS 701 |
Definition at line 607 of file fiff_file.h.
| #define FIFF_SQUID_GATE 703 |
Definition at line 609 of file fiff_file.h.
| #define FIFF_SQUID_OFFSET 702 |
Definition at line 608 of file fiff_file.h.
| #define FIFF_SSS_BASE_IN 273 |
DOUBLE matrix for SSS inside basis.
Definition at line 543 of file fiff_file.h.
| #define FIFF_SSS_BASE_OUT 274 |
DOUBLE matrix for SSS outside basis.
Definition at line 544 of file fiff_file.h.
| #define FIFF_SSS_BASE_VIRT 275 |
DOUBLE matrix for SSS virtual basis.
Definition at line 545 of file fiff_file.h.
| #define FIFF_SSS_CAL_CHANS 270 |
INT matrix (nmag x 2) for fine-calibrated channel numbers and types.
Definition at line 527 of file fiff_file.h.
| #define FIFF_SSS_CAL_CORRS 271 |
FLOAT matrix (nmag x 14) for fine-calibration coefficients.
Definition at line 528 of file fiff_file.h.
| #define FIFF_SSS_COMPONENTS 269 |
Number of SSS moments.
Definition at line 526 of file fiff_file.h.
| #define FIFF_SSS_FRAME 263 |
SSS coordinate frame.
Definition at line 520 of file fiff_file.h.
| #define FIFF_SSS_ITERATE 277 |
Nr of iterations in iterative SSS pseudo-inverse.
Definition at line 547 of file fiff_file.h.
| #define FIFF_SSS_JOB 264 |
SSS job.
Definition at line 521 of file fiff_file.h.
| #define FIFF_SSS_NMAG 268 |
Number of MEG channels.
Definition at line 525 of file fiff_file.h.
| #define FIFF_SSS_NORM 276 |
Froebius norm of the inside basis.
Definition at line 546 of file fiff_file.h.
| #define FIFF_SSS_ORD_IN 266 |
Order of the SSS inside expansion.
Definition at line 523 of file fiff_file.h.
| #define FIFF_SSS_ORD_OUT 267 |
Order of the SSS outside expansion.
Definition at line 524 of file fiff_file.h.
| #define FIFF_SSS_ORIGIN 265 |
Origin of the SSS inside expansion.
Definition at line 522 of file fiff_file.h.
| #define FIFF_SSS_ST_CORR 272 |
TSSS subspace correlation.
Definition at line 529 of file fiff_file.h.
| #define FIFF_STREAM_SEGMENT 19 |
A segment of data stream.
Definition at line 298 of file fiff_file.h.
| #define FIFF_SUBAVE_FIRST 231 |
The first epoch # contained in the subaverage.
Definition at line 477 of file fiff_file.h.
| #define FIFF_SUBAVE_SIZE 230 |
Size of a subaverage.
Definition at line 476 of file fiff_file.h.
| #define FIFF_SUBJ_BIRTH_DAY 404 |
Birthday of the subject.
Definition at line 560 of file fiff_file.h.
| #define FIFF_SUBJ_COMMENT 409 |
Comment about the subject.
Definition at line 565 of file fiff_file.h.
| #define FIFF_SUBJ_FIRST_NAME 401 |
First name of the subject.
Definition at line 557 of file fiff_file.h.
| #define FIFF_SUBJ_HAND 406 |
Handedness of the subject.
Definition at line 562 of file fiff_file.h.
| #define FIFF_SUBJ_HEIGHT 408 |
Height of the subject.
Definition at line 564 of file fiff_file.h.
| #define FIFF_SUBJ_HIS_ID 410 |
ID used in the Hospital Information System.
Definition at line 566 of file fiff_file.h.
| #define FIFF_SUBJ_ID 400 |
Subject ID.
Definition at line 556 of file fiff_file.h.
| #define FIFF_SUBJ_LAST_NAME 403 |
Last name of the subject.
Definition at line 559 of file fiff_file.h.
| #define FIFF_SUBJ_MIDDLE_NAME 402 |
Middle name of the subject.
Definition at line 558 of file fiff_file.h.
| #define FIFF_SUBJ_SEX 405 |
Sex of the subject.
Definition at line 561 of file fiff_file.h.
| #define FIFF_SUBJ_WEIGHT 407 |
Weight of the subject.
Definition at line 563 of file fiff_file.h.
| #define FIFF_SUBJECT 205 |
This might be deleted later.
Definition at line 451 of file fiff_file.h.
| #define FIFF_SUSPEND_FILING 8 |
Definition at line 287 of file fiff_file.h.
| #define FIFF_SUSPEND_READING 5 |
Definition at line 284 of file fiff_file.h.
| #define FIFF_TIME_STAMP 305 |
Int_32[3] meas time stamp (sec,usec,sampleno).
Definition at line 554 of file fiff_file.h.
| #define FIFF_UTC_OFFSET 159 |
UTC offset of related meas_date (sHH:MM).
Definition at line 444 of file fiff_file.h.
| #define FIFF_VOL_AVAIL_BLOCKS 4013 |
Definition at line 853 of file fiff_file.h.
| #define FIFF_VOL_BLOCK_SIZE 4014 |
Block size in bytes.
Definition at line 854 of file fiff_file.h.
| #define FIFF_VOL_BLOCKS 4011 |
Total # of blocks.
Definition at line 851 of file fiff_file.h.
| #define FIFF_VOL_DIRECTORY 4015 |
Contents of the volume in a special format the data type will be FIFF_VOID.
Definition at line 855 of file fiff_file.h.
| #define FIFF_VOL_FREE_BLOCKS 4012 |
Definition at line 852 of file fiff_file.h.
| #define FIFF_VOL_HOST 4007 |
Where does the volume reside.
Definition at line 847 of file fiff_file.h.
| #define FIFF_VOL_ID 4001 |
Definition at line 841 of file fiff_file.h.
| #define FIFF_VOL_MOUNT_POINT 4010 |
Last mount point of the volume.
Definition at line 850 of file fiff_file.h.
| #define FIFF_VOL_NAME 4002 |
Definition at line 842 of file fiff_file.h.
| #define FIFF_VOL_OWNER_ID 4003 |
User id of the owner.
Definition at line 843 of file fiff_file.h.
| #define FIFF_VOL_OWNER_NAME 4004 |
User name of the owner.
Definition at line 844 of file fiff_file.h.
| #define FIFF_VOL_OWNER_REAL_NAME 4005 |
User name of the owner.
Definition at line 845 of file fiff_file.h.
| #define FIFF_VOL_REAL_ROOT 4008 |
The root of the volume in in the machine where the file system is mounted.
Definition at line 848 of file fiff_file.h.
| #define FIFF_VOL_SYMBOLIC_ROOT 4009 |
Symbolic link to the root of the volume (if any) system is mounted.
Definition at line 849 of file fiff_file.h.
| #define FIFF_VOL_TYPE 4006 |
See below...
Definition at line 846 of file fiff_file.h.
| #define FIFF_XFIT_CONDUCTOR_MODEL_NAME 3406 |
Definition at line 786 of file fiff_file.h.
| #define FIFF_XFIT_CONDUCTOR_MODEL_TRANS_NAME 3407 |
Definition at line 787 of file fiff_file.h.
| #define FIFF_XFIT_CONT_SURF_TYPE 3408 |
Xfit contour surface type.
Definition at line 788 of file fiff_file.h.
| #define FIFF_XFIT_GRAD_MAP_PRODUCTS 3403 |
Definition at line 783 of file fiff_file.h.
| #define FIFF_XFIT_INTEGRATION_RADIUS 3405 |
Definition at line 785 of file fiff_file.h.
| #define FIFF_XFIT_LEAD_PRODUCTS 3401 |
Definition at line 781 of file fiff_file.h.
| #define FIFF_XFIT_MAP_PRODUCTS 3402 |
Definition at line 782 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_COMMENT FIFF_PROJ_ITEM_COMMENT |
Definition at line 810 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_DIPOLE FIFF_PROJ_ITEM_DIPOLE |
Definition at line 806 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_IGN_CHS FIFF_PROJ_ITEM_IGN_CHS |
Definition at line 807 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_KIND FIFF_PROJ_ITEM_KIND |
Definition at line 804 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_NVEC FIFF_PROJ_ITEM_NVEC |
Definition at line 808 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_TIME FIFF_PROJ_ITEM_TIME |
Definition at line 805 of file fiff_file.h.
| #define FIFF_XFIT_PROJ_ITEM_VECTORS FIFF_PROJ_ITEM_VECTORS |
Definition at line 809 of file fiff_file.h.
| #define FIFF_XFIT_VOL_INTEGRATION 3404 |
Definition at line 784 of file fiff_file.h.
| #define FIFF_XPLOTTER_LAYOUT 3501 |
xplotter layout tag.
Definition at line 830 of file fiff_file.h.
| #define FIFFB_ASPECT 105 |
Definition at line 361 of file fiff_file.h.
| #define FIFFB_BAD_CHANNELS 359 |
Alias of FIFFB_MNE_BAD_CHANNELS.
Definition at line 408 of file fiff_file.h.
| #define FIFFB_BEM 310 |
Boundary-element method.
Definition at line 396 of file fiff_file.h.
| #define FIFFB_BEM_SURF 311 |
Boundary-element method surfaces.
Definition at line 397 of file fiff_file.h.
| #define FIFFB_CHANNEL_DECOUPLER 501 |
Cross-talk correction .
Definition at line 419 of file fiff_file.h.
| #define FIFFB_CONDUCTOR_MODEL 312 |
One conductor model definition.
Definition at line 398 of file fiff_file.h.
| #define FIFFB_CONTINUOUS_DATA 112 |
Definition at line 368 of file fiff_file.h.
| #define FIFFB_DACQ_PARS 117 |
Definition at line 372 of file fiff_file.h.
| #define FIFFB_DATA_CORRECTION 500 |
Correction to data.
Definition at line 418 of file fiff_file.h.
| #define FIFFB_EVENTS 115 |
Definition at line 370 of file fiff_file.h.
| #define FIFFB_EVOKED 104 |
Definition at line 359 of file fiff_file.h.
| #define FIFFB_HPI_COIL 110 |
Definition at line 366 of file fiff_file.h.
| #define FIFFB_HPI_MEAS 108 |
Definition at line 364 of file fiff_file.h.
| #define FIFFB_HPI_RESULT 109 |
Definition at line 365 of file fiff_file.h.
| #define FIFFB_HPI_SUBSYSTEM 121 |
HPI subsystem.
Definition at line 377 of file fiff_file.h.
| #define FIFFB_INDEX 116 |
Definition at line 371 of file fiff_file.h.
| #define FIFFB_ISOTRAK 107 |
Definition at line 363 of file fiff_file.h.
| #define FIFFB_MCG_AVE FIFFB_EVOKED |
Definition at line 360 of file fiff_file.h.
| #define FIFFB_MEAS 100 |
Definition at line 355 of file fiff_file.h.
| #define FIFFB_MEAS_INFO 101 |
Definition at line 356 of file fiff_file.h.
| #define FIFFB_MRI 200 |
MRI/CT data.
Definition at line 383 of file fiff_file.h.
| #define FIFFB_MRI_SCENE 204 |
Which are actually 3D scenes...
Definition at line 387 of file fiff_file.h.
| #define FIFFB_MRI_SCENERY 203 |
These are for writing unrelated 'slices'.
Definition at line 386 of file fiff_file.h.
| #define FIFFB_MRI_SEG 205 |
MRI segmentation data.
Definition at line 388 of file fiff_file.h.
| #define FIFFB_MRI_SEG_REGION 206 |
One MRI segmentation region.
Definition at line 389 of file fiff_file.h.
| #define FIFFB_MRI_SET 201 |
MRI/CT volume.
Definition at line 384 of file fiff_file.h.
| #define FIFFB_MRI_SLICE 202 |
MRI/CT slice (image).
Definition at line 385 of file fiff_file.h.
| #define FIFFB_PROCESSED_DATA 103 |
Definition at line 358 of file fiff_file.h.
| #define FIFFB_PROCESSING_HISTORY 900 |
Processing history block.
Definition at line 620 of file fiff_file.h.
| #define FIFFB_PROCESSING_RECORD 901 |
.. can contain several processing records. Aspect values used to save characteristic curves of SQUIDs.
Definition at line 621 of file fiff_file.h.
| #define FIFFB_PROJ FIFFB_XFIT_PROJ |
Definition at line 402 of file fiff_file.h.
| #define FIFFB_PROJ_ITEM FIFFB_XFIT_PROJ_ITEM |
Definition at line 403 of file fiff_file.h.
| #define FIFFB_PROJECT 111 |
Definition at line 367 of file fiff_file.h.
| #define FIFFB_RAW_DATA 102 |
Definition at line 357 of file fiff_file.h.
| #define FIFFB_REF 118 |
Fiff referencing mechanism.
Definition at line 373 of file fiff_file.h.
| #define FIFFB_ROOT 999 |
Definition at line 354 of file fiff_file.h.
| #define FIFFB_SMARTSHIELD 510 |
SmartShield data.
Definition at line 425 of file fiff_file.h.
| #define FIFFB_SMSH_ASPECT 120 |
SmartShield averaged data.
Definition at line 376 of file fiff_file.h.
| #define FIFFB_SMSH_RAW_DATA 119 |
SmartShield raw data.
Definition at line 375 of file fiff_file.h.
| #define FIFFB_SPHERE 300 |
Concentric sphere model related.
Definition at line 395 of file fiff_file.h.
| #define FIFFB_SSS_BASES 505 |
SSS bases.
Definition at line 423 of file fiff_file.h.
| #define FIFFB_SSS_CAL_ADJUST 503 |
Fine-calibration adjustment data.
Definition at line 421 of file fiff_file.h.
| #define FIFFB_SSS_INFO 502 |
SSS processing info.
Definition at line 420 of file fiff_file.h.
| #define FIFFB_SSS_ST_INFO 504 |
TSSS info.
Definition at line 422 of file fiff_file.h.
| #define FIFFB_SUBJECT 106 |
Definition at line 362 of file fiff_file.h.
| #define FIFFB_VOID 114 |
Definition at line 369 of file fiff_file.h.
| #define FIFFB_VOL_INFO 400 |
Definition at line 413 of file fiff_file.h.
| #define FIFFB_XFIT_AUX 315 |
xfit saves its auxliary data into this block.
Definition at line 401 of file fiff_file.h.
| #define FIFFB_XFIT_PROJ 313 |
xfit saves the linear projection information here.
Definition at line 399 of file fiff_file.h.
| #define FIFFB_XFIT_PROJ_ITEM 314 |
Each projection item goes here.
Definition at line 400 of file fiff_file.h.
| #define FIFFC_EVENT_FROMBITS 1 |
Definition at line 600 of file fiff_file.h.
| #define FIFFC_EVENT_FROMMASK 0 |
Definition at line 599 of file fiff_file.h.
| #define FIFFC_EVENT_TOBITS 3 |
Definition at line 602 of file fiff_file.h.
| #define FIFFC_EVENT_TOMASK 2 |
Definition at line 601 of file fiff_file.h.
| #define FIFFC_HPI_MAX_NCOIL 1000 |
Max value for FIFF_HPI_NCOIL.
Definition at line 486 of file fiff_file.h.
| #define FIFFC_MAJOR_VERSION 1L |
Definition at line 212 of file fiff_file.h.
| #define FIFFC_MATRIX_MAX_DIM 9 |
Definition at line 252 of file fiff_file.h.
| #define FIFFC_MINOR_VERSION 3L |
Definition at line 213 of file fiff_file.h.
| #define FIFFC_VERSION (FIFFC_MAJOR_VERSION<<16 | FIFFC_MINOR_VERSION) |
Definition at line 215 of file fiff_file.h.
| #define FIFFM_MESSAGE_GROUP | ( | x | ) |
Definition at line 275 of file fiff_file.h.
| #define FIFFT_ASCII 10 |
Definition at line 232 of file fiff_file.h.
| #define FIFFT_BYTE 1 |
Definition at line 222 of file fiff_file.h.
| #define FIFFT_CCS_MATRIX (FIFFTS_FS_MATRIX | FIFFTS_MC_CCS) |
Definition at line 266 of file fiff_file.h.
| #define FIFFT_CCS_MATRIX_FLOAT (FIFFT_CCS_MATRIX | FIFFT_FLOAT) |
Definition at line 272 of file fiff_file.h.
| #define FIFFT_CH_INFO_STRUCT 30 |
Definition at line 240 of file fiff_file.h.
| #define FIFFT_CH_POS_STRUCT 34 |
Definition at line 244 of file fiff_file.h.
| #define FIFFT_COMPLEX_DOUBLE 21 |
Definition at line 238 of file fiff_file.h.
| #define FIFFT_COMPLEX_FLOAT 20 |
Definition at line 237 of file fiff_file.h.
| #define FIFFT_COORD_TRANS_STRUCT 35 |
Definition at line 245 of file fiff_file.h.
| #define FIFFT_DATA_REF_STRUCT 38 |
Definition at line 248 of file fiff_file.h.
| #define FIFFT_DAU_PACK13 13 |
Definition at line 234 of file fiff_file.h.
| #define FIFFT_DAU_PACK14 14 |
Definition at line 235 of file fiff_file.h.
| #define FIFFT_DAU_PACK16 16 |
Definition at line 236 of file fiff_file.h.
| #define FIFFT_DIG_POINT_STRUCT 33 |
Definition at line 243 of file fiff_file.h.
| #define FIFFT_DIG_STRING_STRUCT 36 |
Definition at line 246 of file fiff_file.h.
| #define FIFFT_DIR_ENTRY_STRUCT 32 |
Definition at line 242 of file fiff_file.h.
| #define FIFFT_DOUBLE 5 |
Definition at line 226 of file fiff_file.h.
| #define FIFFT_FLOAT 4 |
Definition at line 225 of file fiff_file.h.
| #define FIFFT_ID_STRUCT 31 |
Definition at line 241 of file fiff_file.h.
| #define FIFFT_INT 3 |
Definition at line 224 of file fiff_file.h.
| #define FIFFT_JULIAN 6 |
Julian day.
Definition at line 227 of file fiff_file.h.
| #define FIFFT_LONG 11 |
Definition at line 233 of file fiff_file.h.
| #define FIFFT_MATRIX (FIFFTS_FS_MATRIX | FIFFTS_MC_DENSE) |
Definition at line 265 of file fiff_file.h.
| #define FIFFT_MATRIX_DOUBLE (FIFFT_MATRIX | FIFFT_DOUBLE) |
Definition at line 271 of file fiff_file.h.
| #define FIFFT_MATRIX_FLOAT (FIFFT_MATRIX | FIFFT_FLOAT) |
Definition at line 270 of file fiff_file.h.
| #define FIFFT_MATRIX_INT (FIFFT_MATRIX | FIFFT_INT) |
Definition at line 269 of file fiff_file.h.
| #define FIFFT_OLD_PACK 23 |
Definition at line 239 of file fiff_file.h.
| #define FIFFT_RCS_MATRIX (FIFFTS_FS_MATRIX | FIFFTS_MC_RCS) |
Definition at line 267 of file fiff_file.h.
| #define FIFFT_RCS_MATRIX_FLOAT (FIFFT_RCS_MATRIX | FIFFT_FLOAT) |
Definition at line 273 of file fiff_file.h.
| #define FIFFT_SHORT 2 |
Definition at line 223 of file fiff_file.h.
| #define FIFFT_STREAM_SEGMENT_STRUCT 37 |
Definition at line 247 of file fiff_file.h.
| #define FIFFT_STRING 10 |
Definition at line 231 of file fiff_file.h.
| #define FIFFT_UINT 8 |
Definition at line 229 of file fiff_file.h.
| #define FIFFT_ULONG 9 |
Definition at line 230 of file fiff_file.h.
| #define FIFFT_USHORT 7 |
Definition at line 228 of file fiff_file.h.
| #define FIFFT_VOID 0 |
Definition at line 221 of file fiff_file.h.
| #define FIFFTS_BASE_MASK 0x00000FFF |
Definition at line 255 of file fiff_file.h.
| #define FIFFTS_FS_MASK 0xFF000000 |
Definition at line 254 of file fiff_file.h.
| #define FIFFTS_FS_MATRIX 0x40000000 |
Definition at line 259 of file fiff_file.h.
| #define FIFFTS_FS_SCALAR 0x00000000 |
Definition at line 258 of file fiff_file.h.
| #define FIFFTS_MC_CCS 0x00100000 |
Definition at line 262 of file fiff_file.h.
| #define FIFFTS_MC_DENSE 0x00000000 |
Definition at line 261 of file fiff_file.h.
| #define FIFFTS_MC_MASK 0x00FF0000 |
Definition at line 256 of file fiff_file.h.
| #define FIFFTS_MC_RCS 0x00200000 |
Definition at line 263 of file fiff_file.h.
| #define FIFFV_ASPECT_ALTAVERAGE 104 |
Alternating subaverage.
Definition at line 435 of file fiff_file.h.
| #define FIFFV_ASPECT_AVERAGE 100 |
Normal average of epochs.
Definition at line 431 of file fiff_file.h.
| #define FIFFV_ASPECT_DIPOLE_WAVE 200 |
Dipole amplitude curve.
Definition at line 438 of file fiff_file.h.
| #define FIFFV_ASPECT_GATE 1102 |
Definition at line 628 of file fiff_file.h.
| #define FIFFV_ASPECT_IFII_HIGH 1101 |
Definition at line 627 of file fiff_file.h.
| #define FIFFV_ASPECT_IFII_LOW 1100 |
Definition at line 626 of file fiff_file.h.
| #define FIFFV_ASPECT_POWER_DENSITY 106 |
Power density spectrum.
Definition at line 437 of file fiff_file.h.
| #define FIFFV_ASPECT_SAMPLE 105 |
A sample cut out by graph.
Definition at line 436 of file fiff_file.h.
| #define FIFFV_ASPECT_SINGLE 102 |
Single epoch cut out from the continuous data.
Definition at line 433 of file fiff_file.h.
| #define FIFFV_ASPECT_STD_ERR 101 |
Std. error of mean.
Definition at line 432 of file fiff_file.h.
| #define FIFFV_ASPECT_SUBAVERAGE 103 |
Definition at line 434 of file fiff_file.h.
| #define FIFFV_BEM_APPROX_CONST 1 |
The constant potential approach.
Definition at line 771 of file fiff_file.h.
| #define FIFFV_BEM_APPROX_LINEAR 2 |
The linear potential approach.
Definition at line 772 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_BLOOD 11 |
Definition at line 747 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_BRAIN 1 |
Definition at line 742 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_CSF 2 |
Definition at line 743 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_HEAD 4 |
Definition at line 745 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_HEART 12 |
Definition at line 748 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_LUNGS 13 |
Definition at line 749 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_NM122 21 |
Definition at line 752 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_SKULL 3 |
Definition at line 744 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_TORSO 14 |
Definition at line 750 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_UNKNOWN -1 |
Definition at line 741 of file fiff_file.h.
| #define FIFFV_BEM_SURF_ID_VV 23 |
Definition at line 754 of file fiff_file.h.
| #define FIFFV_BEM_SURF_UNIT_SPHERE 22 |
Definition at line 753 of file fiff_file.h.
| #define FIFFV_BIG_ENDIAN 2 |
The big-endian (Motorola) byte order.
Definition at line 892 of file fiff_file.h.
| #define FIFFV_COND_MODEL_BEM 3 |
Multilayer BEM model.
Definition at line 716 of file fiff_file.h.
| #define FIFFV_COND_MODEL_BEM_HOMOG 2 |
Homogeneous BEM model.
Definition at line 715 of file fiff_file.h.
| #define FIFFV_COND_MODEL_SPHERE 1 |
Spherically symmetric.
Definition at line 714 of file fiff_file.h.
| #define FIFFV_COND_MODEL_UNKNOWN 0 |
Not known.
Definition at line 713 of file fiff_file.h.
| #define FIFFV_DACQ_SYSTEM_DAU 0 |
Definition at line 303 of file fiff_file.h.
| #define FIFFV_DACQ_SYSTEM_ORION 3 |
Definition at line 306 of file fiff_file.h.
| #define FIFFV_DACQ_SYSTEM_RPU 2 |
Definition at line 305 of file fiff_file.h.
| #define FIFFV_DACQ_SYSTEM_VXI 1 |
Definition at line 304 of file fiff_file.h.
| #define FIFFV_HAND_AMBIDEXTROUS 3 |
Definition at line 582 of file fiff_file.h.
| #define FIFFV_HAND_LEFT 2 |
Definition at line 581 of file fiff_file.h.
| #define FIFFV_HAND_RIGHT 1 |
Definition at line 580 of file fiff_file.h.
| #define FIFFV_HPI_ACCEPT_NONE 0 |
Following corresponsds to fields in channel info record.
Definition at line 506 of file fiff_file.h.
| #define FIFFV_HPI_ACCEPT_PROGRAM (1<<0) |
The fit was accepted by the software.
Definition at line 504 of file fiff_file.h.
| #define FIFFV_HPI_ACCEPT_USER (1<<1) |
The fit was accepted by user action.
Definition at line 505 of file fiff_file.h.
| #define FIFFV_LITTLE_ENDIAN 1 |
The little-endian (Intel) byte order.
Definition at line 891 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_ACR_NEMA 9 |
Definition at line 688 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_DICOM_3 10 |
Definition at line 689 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_FIFF 8 |
Definition at line 687 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_MAGNETOM_LONG 2 |
Definition at line 681 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_MAGNETOM_NEW 7 |
Definition at line 686 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_MAGNETOM_SHORT 1 |
Definition at line 680 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_MERIT 3 |
Definition at line 682 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_PIXEL_RAW 5 |
Definition at line 684 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_PIXEL_RAW_PACKED 6 |
Definition at line 685 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_SIGNA 4 |
Definition at line 683 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_UNKNOWN 0 |
Definition at line 679 of file fiff_file.h.
| #define FIFFV_MRI_FORMAT_VISTA 11 |
Definition at line 690 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_BIT_RLE 8 |
Definition at line 702 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_BYTE 1 |
Definition at line 695 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_BYTE_INDEXED_COLOR 5 |
Definition at line 699 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_BYTE_RGB_COLOR 6 |
Definition at line 700 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_BYTE_RLE_RGB_COLOR 7 |
Definition at line 701 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_FLOAT 4 |
Definition at line 698 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_SWAP_WORD 3 |
Definition at line 697 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_UNKNOWN 0 |
Definition at line 694 of file fiff_file.h.
| #define FIFFV_MRI_PIXEL_WORD 2 |
Definition at line 696 of file fiff_file.h.
| #define FIFFV_NATIVE_ENDIAN 0 |
This refers to the byte order in the current system.
Definition at line 890 of file fiff_file.h.
| #define FIFFV_PROJ_BY_COMPLEMENT 0 |
Definition at line 877 of file fiff_file.h.
| #define FIFFV_PROJ_BY_SPACE 1 |
Definition at line 878 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_DIP_FIX 2 |
Definition at line 817 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_DIP_ROT 3 |
Definition at line 818 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_EEG_AVREF 10 |
Definition at line 821 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_FIELD 1 |
Definition at line 816 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_HOMOG_FIELD 5 |
Definition at line 820 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_HOMOG_GRAD 4 |
Definition at line 819 of file fiff_file.h.
| #define FIFFV_PROJ_ITEM_NONE 0 |
Definition at line 815 of file fiff_file.h.
| #define FIFFV_ROLE_NEXT_FILE 2 |
Definition at line 871 of file fiff_file.h.
| #define FIFFV_ROLE_PREV_FILE 1 |
Definition at line 870 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_BLOOD FIFF_BEM_SURF_ID_BLOOD |
Definition at line 764 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_BRAIN FIFF_BEM_SURF_ID_BRAIN |
Definition at line 759 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_CSF FIFF_BEM_SURF_ID_CSF |
Definition at line 760 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_HEAD FIFF_BEM_SURF_ID_HEAD |
Definition at line 762 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_HEART FIFF_BEM_SURF_ID_HEART |
Definition at line 765 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_LUNGS FIFF_BEM_SURF_ID_LUNGS |
Definition at line 766 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_SKULL FIFF_BEM_SURF_ID_SKULL |
Definition at line 761 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_TORSO FIFF_BEM_SURF_ID_TORSO |
Definition at line 767 of file fiff_file.h.
| #define FIFFV_SEG_REGION_ID_UNKNOWN FIFF_BEM_SURF_ID_UNKNOWN |
Definition at line 758 of file fiff_file.h.
| #define FIFFV_SEX_FEMALE 2 |
Definition at line 578 of file fiff_file.h.
| #define FIFFV_SEX_MALE 1 |
Definition at line 577 of file fiff_file.h.
| #define FIFFV_SEX_UNKNOWN 0 |
Definition at line 576 of file fiff_file.h.
| #define FIFFV_SSS_JOB_CTC 1 |
Only cross-talk correction.
Definition at line 532 of file fiff_file.h.
| #define FIFFV_SSS_JOB_FILTER 2 |
Spatial filtering (default).
Definition at line 533 of file fiff_file.h.
| #define FIFFV_SSS_JOB_HEAD_POS 4 |
Estimate head positions, no movecomp.
Definition at line 535 of file fiff_file.h.
| #define FIFFV_SSS_JOB_MOVEC_FIT 5 |
Estimate head positions, do movecomp.
Definition at line 536 of file fiff_file.h.
| #define FIFFV_SSS_JOB_MOVEC_QUA 6 |
Do movecomp from prev estimated positions.
Definition at line 537 of file fiff_file.h.
| #define FIFFV_SSS_JOB_NOTHING 0 |
Just copy input to output.
Definition at line 531 of file fiff_file.h.
| #define FIFFV_SSS_JOB_REC_ALL 7 |
Reconstruct fields from inside and outside moments.
Definition at line 538 of file fiff_file.h.
| #define FIFFV_SSS_JOB_REC_IN 8 |
Reconstruct fields from inside moments.
Definition at line 539 of file fiff_file.h.
| #define FIFFV_SSS_JOB_REC_OUT 9 |
Reconstruct fields from outside moments.
Definition at line 540 of file fiff_file.h.
| #define FIFFV_SSS_JOB_ST 10 |
TSSS.
Definition at line 541 of file fiff_file.h.
| #define FIFFV_SSS_JOB_VIRT 3 |
Reconstruct virtual data.
Definition at line 534 of file fiff_file.h.
| #define FIFFV_VOL_TYPE_HD 1 |
Hard disk.
Definition at line 884 of file fiff_file.h.
| #define FIFFV_VOL_TYPE_MOD 2 |
Magneto-optical disk.
Definition at line 885 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_DIP_FIX FIFFV_PROJ_ITEM_DIP_FIX |
Definition at line 825 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_DIP_ROT FIFFV_PROJ_ITEM_DIP_ROT |
Definition at line 826 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_FIELD FIFFV_PROJ_ITEM_FIELD |
Definition at line 824 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_HOMOG_FIELD FIFFV_PROJ_ITEM_HOMOG_FIELD |
Definition at line 828 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_HOMOG_GRAD FIFFV_PROJ_ITEM_HOMOG_GRAD |
Definition at line 827 of file fiff_file.h.
| #define FIFFV_XFIT_PROJ_ITEM_NONE FIFFV_PROJ_ITEM_NONE |
Definition at line 823 of file fiff_file.h.
1.16.1
