This class holds information about a network, can compute a distance table and provide network metrics. More...

#include <network.h>

Public Types
typedef QSharedPointer< Network >	SPtr

typedef QSharedPointer< const Network >	ConstSPtr

Public Member Functions
	Network (const QString &sConnectivityMethod="Unknown", double dThreshold=0.0)

Eigen::MatrixXd	getFullConnectivityMatrix (bool bGetMirroredVersion=true) const

Eigen::MatrixXd	getThresholdedConnectivityMatrix (bool bGetMirroredVersion=true) const

const QList< QSharedPointer< NetworkEdge > > &	getFullEdges () const

const QList< QSharedPointer< NetworkEdge > > &	getThresholdedEdges () const

const QList< QSharedPointer< NetworkNode > > &	getNodes () const

QSharedPointer< NetworkEdge >	getEdgeAt (int i)

QSharedPointer< NetworkNode >	getNodeAt (int i)

qint16	getFullDistribution () const

qint16	getThresholdedDistribution () const

void	setConnectivityMethod (const QString &sConnectivityMethod)

QString	getConnectivityMethod () const

QPair< double, double >	getMinMaxFullWeights () const

QPair< double, double >	getMinMaxThresholdedWeights () const

QPair< int, int >	getMinMaxFullDegrees () const

QPair< int, int >	getMinMaxThresholdedDegrees () const

QPair< int, int >	getMinMaxFullIndegrees () const

QPair< int, int >	getMinMaxThresholdedIndegrees () const

QPair< int, int >	getMinMaxFullOutdegrees () const

QPair< int, int >	getMinMaxThresholdedOutdegrees () const

void	setThreshold (double dThreshold=0.0)

double	getThreshold ()

void	setFrequencyRange (float fLowerFreq, float fUpperFreq)

const QPair< float, float > &	getFrequencyRange () const

void	append (QSharedPointer< NetworkEdge > newEdge)

void	append (QSharedPointer< NetworkNode > newNode)

bool	isEmpty () const

void	normalize ()

VisualizationInfo	getVisualizationInfo () const

void	setVisualizationInfo (const VisualizationInfo &visualizationInfo)

float	getSamplingFrequency () const

void	setSamplingFrequency (float fSFreq)

int	getUsedFreqBins () const

void	setUsedFreqBins (int iNumberFreqBins)

void	setFFTSize (int iFFTSize)

int	getFFTSize ()

Protected Attributes
QList< QSharedPointer< NetworkEdge > >	m_lFullEdges

QList< QSharedPointer< NetworkEdge > >	m_lThresholdedEdges

QList< QSharedPointer< NetworkNode > >	m_lNodes

Eigen::MatrixXd	m_matDistMatrix

QString	m_sConnectivityMethod

QPair< double, double >	m_minMaxFullWeights

QPair< double, double >	m_minMaxThresholdedWeights

QPair< float, float >	m_minMaxFrequency

double	m_dThreshold

float	m_fSFreq

int	m_iNumberFreqBins

int	m_iFFTSize

VisualizationInfo	m_visualizationInfo

Detailed Description

This class holds information about a network, can compute a distance table and provide network metrics.

This class holds information (nodes and connecting edges) about a network, can compute a distance table and provide network metrics.

Definition at line 88 of file network.h.

Member Typedef Documentation

◆ ConstSPtr

typedef QSharedPointer<const Network> CONNECTIVITYLIB::Network::ConstSPtr

Const shared pointer type for Network.

Definition at line 93 of file network.h.

◆ SPtr

typedef QSharedPointer<Network> CONNECTIVITYLIB::Network::SPtr

Shared pointer type for Network.

Definition at line 92 of file network.h.

Constructor & Destructor Documentation

◆ Network()

Network::Network	(	const QString &	sConnectivityMethod = `"Unknown"`,
		double	dThreshold = `0.0`
	)

explicit

Constructs a Network object.

Parameters

[in]	sConnectivityMethod	The connectivity measure method used to create the data of this network structure.
[in]	dThreshold	The threshold of the network. Default is 0.0.

Definition at line 76 of file network.cpp.

Member Function Documentation

◆ append() [1/2]

void CONNECTIVITYLIB::Network::append ( QSharedPointer< NetworkEdge > newEdge )

Appends a network edge to this network node.

Parameters

[in] newEdge The new edge item.

◆ append() [2/2]

void CONNECTIVITYLIB::Network::append ( QSharedPointer< NetworkNode > newNode )

Appends a network edge to this network node.

Parameters

[in] newNode The new node item as a reference.

◆ getConnectivityMethod()

QString Network::getConnectivityMethod ( ) const

Returns the connectivity measure method used to create the data of this network structure.

Returns: The connectivity measure method used to create the data of this network structure.

Definition at line 203 of file network.cpp.

◆ getEdgeAt()

QSharedPointer<NetworkEdge> CONNECTIVITYLIB::Network::getEdgeAt ( int i )

Returns the edge at a specific position.

Parameters

[in] i The index to look up the edge. i must be a valid index position in the network list (i.e., 0 <= i < size()).

Returns: Returns the network edge.

◆ getFFTSize()

int Network::getFFTSize ( )

Returns the current FFT size.

Returns: The used FFT size (number of total frequency bins for a half spectrum - only positive frequencies).

Definition at line 520 of file network.cpp.

◆ getFrequencyRange()

const QPair< float, float > & Network::getFrequencyRange ( ) const

Returns the current frequency edge to average from/to.

Returns: The current upper/lower frequency edge to average from/to.

Definition at line 405 of file network.cpp.

◆ getFullConnectivityMatrix()

MatrixXd Network::getFullConnectivityMatrix ( bool bGetMirroredVersion = true ) const

Returns the full connectivity matrix for this network structure.

Parameters

[in] bGetMirroredVersion Flag whether to return the mirrored version of the connectivity matrix, if the network. is a non-directional one. Otherwise returns zeros for the lower part of the matrix. Default is set to true.

Returns: The full connectivity matrix generated from the current network information.

Definition at line 94 of file network.cpp.

◆ getFullDistribution()

qint16 Network::getFullDistribution ( ) const

Returns network distribution, also known as network degree, corresponding to the full network.

Returns: The network distribution calculated as degrees of all nodes together.

Definition at line 170 of file network.cpp.

◆ getFullEdges()

const QList< NetworkEdge::SPtr > & Network::getFullEdges ( ) const

Returns the full and non thresholded edges.

Returns: Returns the network edges.

Definition at line 142 of file network.cpp.

◆ getMinMaxFullDegrees()

QPair< int, int > Network::getMinMaxFullDegrees ( ) const

Returns the minimum and maximum degree (in and out) corresponding to the full network.

Returns: The minimum and maximum degree of the entire network.

Definition at line 224 of file network.cpp.

◆ getMinMaxFullIndegrees()

QPair< int, int > Network::getMinMaxFullIndegrees ( ) const

Returns the minimum and maximum indegree corresponding to the full network.

Returns: The minimum and maximum indegree of the entire network.

Definition at line 260 of file network.cpp.

◆ getMinMaxFullOutdegrees()

QPair< int, int > Network::getMinMaxFullOutdegrees ( ) const

Returns the minimum and maximum outdegree corresponding to the full network.

Returns: The minimum and maximum outdegree of the entire network.

Definition at line 296 of file network.cpp.

◆ getMinMaxFullWeights()

QPair< double, double > Network::getMinMaxFullWeights ( ) const

Returns the minimum and maximum weight strength of the entire network.

Returns: The minimum and maximum weight strength of the entire network.

Definition at line 210 of file network.cpp.

◆ getMinMaxThresholdedDegrees()

QPair< int, int > Network::getMinMaxThresholdedDegrees ( ) const

Returns the minimum and maximum degree (in and out) corresponding to the thresholded network.

Returns: The minimum and maximum degree of the entire network.

Definition at line 242 of file network.cpp.

◆ getMinMaxThresholdedIndegrees()

QPair< int, int > Network::getMinMaxThresholdedIndegrees ( ) const

Returns the minimum and maximum indegree corresponding to the thresholded network.

Returns: The minimum and maximum indegree of the entire network.

Definition at line 278 of file network.cpp.

◆ getMinMaxThresholdedOutdegrees()

QPair< int, int > Network::getMinMaxThresholdedOutdegrees ( ) const

Returns the minimum and maximum outdegree corresponding to the thresholded network.

Returns: The minimum and maximum outdegree of the entire network.

Definition at line 314 of file network.cpp.

◆ getMinMaxThresholdedWeights()

QPair< double, double > Network::getMinMaxThresholdedWeights ( ) const

Returns the minimum and maximum weight strength of the thresholded network.

Returns: The minimum and maximum weight strength of the entire network.

Definition at line 217 of file network.cpp.

◆ getNodeAt()

NetworkNode::SPtr Network::getNodeAt ( int i )

Returns the node at a specific position.

Parameters

[in] i The index to look up the node. i must be a valid index position in the network list (i.e., 0 <= i < size()).

Returns: Returns the network node.

Definition at line 163 of file network.cpp.

◆ getNodes()

const QList< NetworkNode::SPtr > & Network::getNodes ( ) const

Returns the nodes.

Returns: Returns the network nodes.

Definition at line 156 of file network.cpp.

◆ getSamplingFrequency()

float Network::getSamplingFrequency ( ) const

Get the currently set sampling frequency.

Returns: The currently set sampling frequency.

Definition at line 485 of file network.cpp.

◆ getThreshold()

double Network::getThreshold ( )

Returns the current threshold of the network.

Returns: The current threshold.

Definition at line 352 of file network.cpp.

◆ getThresholdedConnectivityMatrix()

MatrixXd Network::getThresholdedConnectivityMatrix ( bool bGetMirroredVersion = true ) const

Returns the thresholded connectivity matrix for this network structure.

Parameters

[in] bGetMirroredVersion Flag whether to return the mirrored version of the connectivity matrix, if the network. is a non-directional one. Otherwise returns zeros for the lower part of the matrix. Default is set to true.

Returns: The thresholded connectivity matrix generated from the current network information.

Definition at line 118 of file network.cpp.

◆ getThresholdedDistribution()

qint16 Network::getThresholdedDistribution ( ) const

Returns network distribution, also known as network degree, corresponding to the thresholded network.

Returns: The network distribution calculated as degrees of all nodes together.

Definition at line 183 of file network.cpp.

◆ getThresholdedEdges()

const QList< NetworkEdge::SPtr > & Network::getThresholdedEdges ( ) const

Returns the thresholded edges.

Returns: Returns the network edges.

Definition at line 149 of file network.cpp.

◆ getUsedFreqBins()

int Network::getUsedFreqBins ( ) const

Get the currently set number of frequency bins.

Returns: The currently set number of samples.

Definition at line 499 of file network.cpp.

◆ getVisualizationInfo()

VisualizationInfo Network::getVisualizationInfo ( ) const

Get the current visualization info.

Returns: The current visualization info.

Definition at line 471 of file network.cpp.

◆ isEmpty()

bool Network::isEmpty ( ) const

Returns whether the Network is empty by checking the number of nodes and edges.

Returns: The flag identifying whether the Network is empty.

Definition at line 439 of file network.cpp.

◆ normalize()

void Network::normalize ( )

Normalize the network.

Definition at line 450 of file network.cpp.

◆ setConnectivityMethod()

void Network::setConnectivityMethod ( const QString & sConnectivityMethod )

Sets the connectivity measure method used to create the data of this network structure.

Parameters

[in] sConnectivityMethod The connectivity measure method used to create the data of this network structure.

Definition at line 196 of file network.cpp.

◆ setFFTSize()

void Network::setFFTSize ( int iFFTSize )

Set the new FFT size.

Parameters

[in] iFFTSize The used FFT size (number of total frequency bins for a half spectrum - only positive frequencies).

Definition at line 513 of file network.cpp.

◆ setFrequencyRange()

void Network::setFrequencyRange	(	float	fLowerFreq,
		float	fUpperFreq
	)

Sets the frequency range to average from/to.

Parameters

[in]	fLowerFreq	The new lower frequency edge to average from.
[in]	fUpperFreq	The new upper frequency edge to average to.

Definition at line 359 of file network.cpp.

◆ setSamplingFrequency()

void Network::setSamplingFrequency ( float fSFreq )

Set the new sampling frequency.

Parameters

[in] sFreq The new sampling frequency.

Definition at line 492 of file network.cpp.

◆ setThreshold()

void Network::setThreshold ( double dThreshold = 0.0 )

Sets the threshold of the network and updates the resulting active edges.

Parameters

[in] dThreshold The new threshold.

Definition at line 332 of file network.cpp.

◆ setUsedFreqBins()

void Network::setUsedFreqBins ( int iNumberFreqBins )

Set the new number of used frequency bins.

Parameters

[in] iNumberFreqBins The new number of used frequency bins.

Definition at line 506 of file network.cpp.

◆ setVisualizationInfo()

void Network::setVisualizationInfo ( const VisualizationInfo & visualizationInfo )

Set the current visualization info.

Parameters

[in] visualizationInfo The new visualization info.

Definition at line 478 of file network.cpp.

Member Data Documentation

◆ m_dThreshold

double CONNECTIVITYLIB::Network::m_dThreshold

protected

The current value which was used to threshold the edge weigths.

Definition at line 410 of file network.h.

◆ m_fSFreq

float CONNECTIVITYLIB::Network::m_fSFreq

protected

The sampling frequency used to collect the data which this network is based on.

Definition at line 411 of file network.h.

◆ m_iFFTSize

int CONNECTIVITYLIB::Network::m_iFFTSize

protected

The used FFT size (number of total frequency bins for a half spectrum - only positive frequencies).

Definition at line 413 of file network.h.

◆ m_iNumberFreqBins

int CONNECTIVITYLIB::Network::m_iNumberFreqBins

protected

The number of used frequency bins.

Definition at line 412 of file network.h.

◆ m_lFullEdges

QList<QSharedPointer<NetworkEdge> > CONNECTIVITYLIB::Network::m_lFullEdges

protected

List with all edges of the network.

Definition at line 397 of file network.h.

◆ m_lNodes

QList<QSharedPointer<NetworkNode> > CONNECTIVITYLIB::Network::m_lNodes

protected

List with all nodes of the network.

Definition at line 400 of file network.h.

◆ m_lThresholdedEdges

QList<QSharedPointer<NetworkEdge> > CONNECTIVITYLIB::Network::m_lThresholdedEdges

protected

List with all the active (thresholded) edges of the network.

Definition at line 398 of file network.h.

◆ m_matDistMatrix

Eigen::MatrixXd CONNECTIVITYLIB::Network::m_matDistMatrix

protected

The distance matrix.

Definition at line 402 of file network.h.

◆ m_minMaxFrequency

QPair<float,float> CONNECTIVITYLIB::Network::m_minMaxFrequency

protected

The minimum and maximum frequency bins to average from/to.

Definition at line 408 of file network.h.

◆ m_minMaxFullWeights

QPair<double,double> CONNECTIVITYLIB::Network::m_minMaxFullWeights

protected

The minimum and maximum weight strength of the entire network.

Definition at line 406 of file network.h.

◆ m_minMaxThresholdedWeights

QPair<double,double> CONNECTIVITYLIB::Network::m_minMaxThresholdedWeights

protected

The minimum and maximum weight strength of the active edges.

Definition at line 407 of file network.h.

◆ m_sConnectivityMethod

QString CONNECTIVITYLIB::Network::m_sConnectivityMethod

protected

The connectivity measure method used to create the data of this network structure.

Definition at line 404 of file network.h.

◆ m_visualizationInfo

VisualizationInfo CONNECTIVITYLIB::Network::m_visualizationInfo

protected

The current visualization info used to plot the network later on.

Definition at line 415 of file network.h.

The documentation for this class was generated from the following files:

src/libraries/connectivity/network/network.h
src/libraries/connectivity/network/network.cpp

Public Types

Public Member Functions

Protected Attributes

Detailed Description

Member Typedef Documentation

◆ ConstSPtr

◆ SPtr

Constructor & Destructor Documentation

◆ Network()

Member Function Documentation

◆ append() [1/2]

◆ append() [2/2]

◆ getConnectivityMethod()

◆ getEdgeAt()

◆ getFFTSize()

◆ getFrequencyRange()

◆ getFullConnectivityMatrix()

◆ getFullDistribution()

◆ getFullEdges()

◆ getMinMaxFullDegrees()

◆ getMinMaxFullIndegrees()

◆ getMinMaxFullOutdegrees()

◆ getMinMaxFullWeights()

◆ getMinMaxThresholdedDegrees()

◆ getMinMaxThresholdedIndegrees()

◆ getMinMaxThresholdedOutdegrees()

◆ getMinMaxThresholdedWeights()

◆ getNodeAt()

◆ getNodes()

◆ getSamplingFrequency()

◆ getThreshold()

◆ getThresholdedConnectivityMatrix()

◆ getThresholdedDistribution()

◆ getThresholdedEdges()

◆ getUsedFreqBins()

◆ getVisualizationInfo()

◆ isEmpty()

◆ normalize()

◆ setConnectivityMethod()

◆ setFFTSize()

◆ setFrequencyRange()

◆ setSamplingFrequency()

◆ setThreshold()

◆ setUsedFreqBins()

◆ setVisualizationInfo()

Member Data Documentation

◆ m_dThreshold

◆ m_fSFreq

◆ m_iFFTSize

◆ m_iNumberFreqBins

◆ m_lFullEdges

◆ m_lNodes

◆ m_lThresholdedEdges

◆ m_matDistMatrix

◆ m_minMaxFrequency

◆ m_minMaxFullWeights

◆ m_minMaxThresholdedWeights

◆ m_sConnectivityMethod

◆ m_visualizationInfo
