DISPLIB::AverageSelectionView Class Reference

The AverageSelectionView class provides a view to activate and choose colors for different averages. More...

#include <averageselectionview.h>

Public Types
typedef QSharedPointer< AverageSelectionView >	SPtr
typedef QSharedPointer< const AverageSelectionView >	ConstSPtr
Public Types inherited from DISPLIB::AbstractView
enum	StyleMode { Default, Dark }
enum	GuiMode { Clinical, Research }
enum	ProcessingMode { RealTime, Offline }
typedef QSharedPointer< AbstractView >	SPtr
typedef QSharedPointer< const AbstractView >	ConstSPtr

Signals
void	newAverageColorMap (const QSharedPointer< QMap< QString, QColor > > qMapAverageColor)
void	newAverageActivationMap (const QSharedPointer< QMap< QString, bool > > qMapAverageActivation)
Signals inherited from DISPLIB::AbstractView
void	guiStyleChanged (DISPLIB::AbstractView::StyleMode style)

Public Member Functions
	AverageSelectionView (const QString &sSettingsPath="", QWidget *parent=0, Qt::WindowFlags f=Qt::Widget)
	~AverageSelectionView ()
QSharedPointer< QMap< QString, QColor > >	getAverageColor () const
QSharedPointer< QMap< QString, bool > >	getAverageActivation () const
void	setAverageColor (const QSharedPointer< QMap< QString, QColor > > qMapAverageColor)
void	setAverageActivation (const QSharedPointer< QMap< QString, bool > > qMapAverageActivation)
void	saveSettings ()
void	loadSettings ()
void	clearView ()
Public Member Functions inherited from DISPLIB::AbstractView
	AbstractView (QWidget *parent=0, Qt::WindowFlags f=Qt::Widget)
virtual void	setGuiMode (GuiMode mode)
virtual void	setProcessingMode (ProcessingMode mode)

Protected Member Functions
void	updateGuiMode (GuiMode mode)
void	updateProcessingMode (ProcessingMode mode)
void	redrawGUI ()
void	onAverageSelectionColorChanged ()

Protected Attributes
int	m_iMaxNumAverages
QSharedPointer< QMap< QString, QColor > >	m_qMapAverageColor
QSharedPointer< QMap< QString, bool > >	m_qMapAverageActivation
Protected Attributes inherited from DISPLIB::AbstractView
bool	m_bResearchModeIsActive
bool	m_bOfflineModeIsActive
QString	m_sSettingsPath

Detailed Description

The AverageSelectionView class provides a view to activate and choose colors for different averages.

DECLARE CLASS AverageSelectionView

Definition at line 76 of file averageselectionview.h.

Inheritance diagram for DISPLIB::AverageSelectionView:

Member Typedef Documentation

ConstSPtr

typedef QSharedPointer<const AverageSelectionView> DISPLIB::AverageSelectionView::ConstSPtr

Const shared pointer type for AverageSelectionView.

Definition at line 82 of file averageselectionview.h.

SPtr

typedef QSharedPointer<AverageSelectionView> DISPLIB::AverageSelectionView::SPtr

Shared pointer type for AverageSelectionView.

Definition at line 81 of file averageselectionview.h.

Constructor & Destructor Documentation

AverageSelectionView()

AverageSelectionView::AverageSelectionView	(	const QString &	sSettingsPath = "",
		QWidget *	parent = 0,
		Qt::WindowFlags	f = Qt::Widget
	)

Constructs a AverageSelectionView which is a child of parent.

Parameters

[in]

parent

parent of widget.

Definition at line 74 of file averageselectionview.cpp.

~AverageSelectionView()

AverageSelectionView::~AverageSelectionView

(

)

Destroys the AverageSelectionView.

Definition at line 93 of file averageselectionview.cpp.

Member Function Documentation

clearView()

void AverageSelectionView::clearView ( )

virtual

Clears the view

Implements DISPLIB::AbstractView.

Definition at line 296 of file averageselectionview.cpp.

getAverageActivation()

QSharedPointer< QMap< QString, bool > > AverageSelectionView::getAverageActivation

(

)

const

Get the current average activations

Returns

Pointer to the current average activations.

Definition at line 107 of file averageselectionview.cpp.

getAverageColor()

QSharedPointer< QMap< QString, QColor > > AverageSelectionView::getAverageColor

(

)

const

Get the current average colors

Returns

Pointer to the current average colors.

Definition at line 100 of file averageselectionview.cpp.

loadSettings()

void AverageSelectionView::loadSettings ( )

virtual

Loads and inits all important settings of this view via QSettings.

Implements DISPLIB::AbstractView.

Definition at line 157 of file averageselectionview.cpp.

newAverageActivationMap

void DISPLIB::AverageSelectionView::newAverageActivationMap ( const QSharedPointer< QMap< QString, bool > >  qMapAverageActivation )

signal

Emmited when new average activation is available

Parameters

[in]

qMapAverageActivation

the average activation map.

newAverageColorMap

void DISPLIB::AverageSelectionView::newAverageColorMap ( const QSharedPointer< QMap< QString, QColor > >  qMapAverageColor )

signal

Emmited when new average color is available

Parameters

[in]

qMapAverageColor

the average color map.

onAverageSelectionColorChanged()

void AverageSelectionView::onAverageSelectionColorChanged ( )

protected

Call this slot whenever the average selection or color changed.

Definition at line 260 of file averageselectionview.cpp.

redrawGUI()

void AverageSelectionView::redrawGUI ( )

protected

Redraw the GUI.

Definition at line 206 of file averageselectionview.cpp.

saveSettings()

void AverageSelectionView::saveSettings ( )

virtual

Saves all important settings of this view via QSettings.

Implements DISPLIB::AbstractView.

Definition at line 130 of file averageselectionview.cpp.

setAverageActivation()

void AverageSelectionView::setAverageActivation

(

const QSharedPointer< QMap< QString, bool > >

qMapAverageActivation

)

Set the average activations

Parameters

[in]

qMapAverageActivation

Pointer to the new average activations.

Definition at line 122 of file averageselectionview.cpp.

setAverageColor()

void AverageSelectionView::setAverageColor

(

const QSharedPointer< QMap< QString, QColor > >

qMapAverageColor

)

Set the average colors

Parameters

[in]

qMapAverageColor

Pointer to the new average colors.

Definition at line 114 of file averageselectionview.cpp.

updateGuiMode()

void AverageSelectionView::updateGuiMode ( GuiMode  mode )

protectedvirtual

Update the views GUI based on the set GuiMode (Clinical=0, Research=1).

Parameters

mode	The new mode (Clinical=0, Research=1).

Implements DISPLIB::AbstractView.

Definition at line 182 of file averageselectionview.cpp.

updateProcessingMode()

void AverageSelectionView::updateProcessingMode ( ProcessingMode  mode )

protectedvirtual

Update the views GUI based on the set ProcessingMode (RealTime=0, Offline=1).

Parameters

mode	The new mode (RealTime=0, Offline=1).

Implements DISPLIB::AbstractView.

Definition at line 194 of file averageselectionview.cpp.

Member Data Documentation

m_qMapAverageActivation

QSharedPointer<QMap<QString, bool> > DISPLIB::AverageSelectionView::m_qMapAverageActivation

protected

Average activation status.

Definition at line 182 of file averageselectionview.h.

m_qMapAverageColor

QSharedPointer<QMap<QString, QColor> > DISPLIB::AverageSelectionView::m_qMapAverageColor

protected

Average colors.

Definition at line 181 of file averageselectionview.h.

---

The documentation for this class was generated from the following files:

• src/libraries/disp/viewers/averageselectionview.h
• src/libraries/disp/viewers/averageselectionview.cpp
