The ConnectivitySettingsView class provides a view to control settings for estiamting functional connectivity. More...

#include <connectivitysettingsview.h>

Public Types
typedef QSharedPointer< ConnectivitySettingsView >	SPtr

typedef QSharedPointer< const ConnectivitySettingsView >	ConstSPtr

Public Types inherited from DISPLIB::AbstractView
enum	StyleMode { Default , Dark }

enum	GuiMode { Clinical , Research }

enum	ProcessingMode { RealTime , Offline }

typedef QSharedPointer< AbstractView >	SPtr

typedef QSharedPointer< const AbstractView >	ConstSPtr

Signals
void	connectivityMetricChanged (const QString &sMetric)

void	windowTypeChanged (const QString &windowType)

void	numberTrialsChanged (int iNumberTrials)

void	triggerTypeChanged (const QString &sTriggerType)

void	freqBandChanged (float fFreqLow, float fFreqHigh)

Signals inherited from DISPLIB::AbstractView
void	guiStyleChanged (DISPLIB::AbstractView::StyleMode style)

Public Member Functions
	ConnectivitySettingsView (const QString &sSettingsPath="", QWidget *parent=0, Qt::WindowFlags f=Qt::Widget)

	~ConnectivitySettingsView ()

void	setTriggerTypes (const QStringList &lTriggerTypes)

void	setNumberTrials (int iNumberTrials)

void	setFrequencyBand (double dFreqLow, double dFreqHigh)

QString	getConnectivityMetric ()

QString	getWindowType ()

int	getNumberTrials ()

QString	getTriggerType ()

double	getLowerFreq ()

double	getUpperFreq ()

void	saveSettings ()

void	loadSettings ()

void	clearView ()

Public Member Functions inherited from DISPLIB::AbstractView
	AbstractView (QWidget *parent=0, Qt::WindowFlags f=Qt::Widget)

virtual void	setGuiMode (GuiMode mode)

virtual void	setProcessingMode (ProcessingMode mode)

Protected Member Functions
void	updateGuiMode (GuiMode mode)

void	updateProcessingMode (ProcessingMode mode)

void	onMetricChanged (const QString &sMetric)

void	onWindowTypeChanged (const QString &sWindowType)

void	onNumberTrialsChanged ()

void	onTriggerTypeChanged (const QString &sTriggerType)

void	onFrequencyBandChanged ()

Protected Attributes
Ui::ConnectivitySettingsViewWidget *	m_pUi

QString	m_sSettingsPath

int	m_iNumberTrials

Protected Attributes inherited from DISPLIB::AbstractView
bool	m_bResearchModeIsActive

bool	m_bOfflineModeIsActive

QString	m_sSettingsPath

Detailed Description

The ConnectivitySettingsView class provides a view to control settings for estiamting functional connectivity.

DECLARE CLASS ConnectivitySettingsView

Definition at line 78 of file connectivitysettingsview.h.

Inheritance diagram for DISPLIB::ConnectivitySettingsView:

Member Typedef Documentation

◆ ConstSPtr

typedef QSharedPointer<const ConnectivitySettingsView> DISPLIB::ConnectivitySettingsView::ConstSPtr

Const shared pointer type for ConnectivitySettingsView.

Definition at line 84 of file connectivitysettingsview.h.

◆ SPtr

typedef QSharedPointer<ConnectivitySettingsView> DISPLIB::ConnectivitySettingsView::SPtr

Shared pointer type for ConnectivitySettingsView.

Definition at line 83 of file connectivitysettingsview.h.

Constructor & Destructor Documentation

◆ ConnectivitySettingsView()

ConnectivitySettingsView::ConnectivitySettingsView	(	const QString &	sSettingsPath = `""`,
		QWidget *	parent = `0`,
		Qt::WindowFlags	f = `Qt::Widget`
	)

Constructs a ConnectivitySettingsView which is a child of parent.

Parameters

[in] parent parent of widget.

Definition at line 63 of file connectivitysettingsview.cpp.

◆ ~ConnectivitySettingsView()

ConnectivitySettingsView::~ConnectivitySettingsView ( )

Destroys the ConnectivitySettingsView.

Definition at line 108 of file connectivitysettingsview.cpp.

Member Function Documentation

◆ clearView()

void ConnectivitySettingsView::clearView ( )

virtual

Clears the view

Implements DISPLIB::AbstractView.

Definition at line 294 of file connectivitysettingsview.cpp.

◆ connectivityMetricChanged

void DISPLIB::ConnectivitySettingsView::connectivityMetricChanged ( const QString & sMetric )

signal

Emit signal whenever the connectivity metric changed.

Parameters

[in] sMetric The new metric.

◆ freqBandChanged

void DISPLIB::ConnectivitySettingsView::freqBandChanged	(	float	fFreqLow,
		float	fFreqHigh
	)

signal

Emit signal whenever the frequency band changed.

Parameters

[in]	fFreqLow	The new lower frequency band.
[in]	fFreqHigh	The new higher frequency band.

◆ getConnectivityMetric()

QString ConnectivitySettingsView::getConnectivityMetric ( )

Get the current connectivity metric.

Returns: The current connectivity metric.

Definition at line 143 of file connectivitysettingsview.cpp.

◆ getLowerFreq()

double ConnectivitySettingsView::getLowerFreq ( )

Get the current lower frequency range.

Returns: The current lower frequency range.

Definition at line 171 of file connectivitysettingsview.cpp.

◆ getNumberTrials()

int ConnectivitySettingsView::getNumberTrials ( )

Get the current number of trials.

Returns: The current number of trials.

Definition at line 157 of file connectivitysettingsview.cpp.

◆ getTriggerType()

QString ConnectivitySettingsView::getTriggerType ( )

Get the current trigger type.

Returns: The current trigger type.

Definition at line 164 of file connectivitysettingsview.cpp.

◆ getUpperFreq()

double ConnectivitySettingsView::getUpperFreq ( )

Get the current upper frequency range.

Returns: The current upper frequency range.

Definition at line 178 of file connectivitysettingsview.cpp.

◆ getWindowType()

QString ConnectivitySettingsView::getWindowType ( )

Get the current window type.

Returns: The current window type.

Definition at line 150 of file connectivitysettingsview.cpp.

◆ loadSettings()

void ConnectivitySettingsView::loadSettings ( )

virtual

Loads and inits all important settings of this view via QSettings.

Implements DISPLIB::AbstractView.

Definition at line 203 of file connectivitysettingsview.cpp.

◆ numberTrialsChanged

void DISPLIB::ConnectivitySettingsView::numberTrialsChanged ( int iNumberTrials )

signal

Emit signal whenever the number of trials changed.

Parameters

[in] iNumberTrials The new number of trials.

◆ onFrequencyBandChanged()

void ConnectivitySettingsView::onFrequencyBandChanged ( )

protected

Slot called when the frequency band changed.

Definition at line 284 of file connectivitysettingsview.cpp.

◆ onMetricChanged()

void ConnectivitySettingsView::onMetricChanged ( const QString & sMetric )

protected

Slot called when the metric changed.

Parameters

[in] sMetric The new metric.

Definition at line 246 of file connectivitysettingsview.cpp.

◆ onNumberTrialsChanged()

void ConnectivitySettingsView::onNumberTrialsChanged ( )

protected

Slot called when the number of trials changed.

Definition at line 262 of file connectivitysettingsview.cpp.

◆ onTriggerTypeChanged()

void ConnectivitySettingsView::onTriggerTypeChanged ( const QString & sTriggerType )

protected

Slot called when the trigger type changed.

Parameters

[in] sTriggerType The new trigger type.

Definition at line 276 of file connectivitysettingsview.cpp.

◆ onWindowTypeChanged()

void ConnectivitySettingsView::onWindowTypeChanged ( const QString & sWindowType )

protected

Slot called when the window type changed.

Parameters

[in] sWindowType The new window type.

Definition at line 254 of file connectivitysettingsview.cpp.

◆ saveSettings()

void ConnectivitySettingsView::saveSettings ( )

virtual

Saves all important settings of this view via QSettings.

Implements DISPLIB::AbstractView.

Definition at line 185 of file connectivitysettingsview.cpp.

◆ setFrequencyBand()

void ConnectivitySettingsView::setFrequencyBand	(	double	dFreqLow,
		double	dFreqHigh
	)

Sets the frequency band.

Parameters

[in]	dFreqLow	The lower frequency.
[in]	dFreqHigh	The upper frequency.

Definition at line 135 of file connectivitysettingsview.cpp.

◆ setNumberTrials()

void ConnectivitySettingsView::setNumberTrials ( int iNumberTrials )

Sets the new number of trials.

Parameters

[in] iNumberTrials The new number of trials.

Definition at line 128 of file connectivitysettingsview.cpp.

◆ setTriggerTypes()

void ConnectivitySettingsView::setTriggerTypes ( const QStringList & lTriggerTypes )

Destroys the ConnectivitySettingsView.

Parameters

[in] lTriggerTypes The new trigger types.

Definition at line 117 of file connectivitysettingsview.cpp.

◆ triggerTypeChanged

void DISPLIB::ConnectivitySettingsView::triggerTypeChanged ( const QString & sTriggerType )

signal

Emit signal whenever the trigger type changed.

Parameters

[in] sTriggerType The new trigger type.

◆ updateGuiMode()

void ConnectivitySettingsView::updateGuiMode ( GuiMode mode )

protectedvirtual

Update the views GUI based on the set GuiMode (Clinical=0, Research=1).

Parameters

[in] mode The new mode (Clinical=0, Research=1).

Implements DISPLIB::AbstractView.

Definition at line 222 of file connectivitysettingsview.cpp.

◆ updateProcessingMode()

void ConnectivitySettingsView::updateProcessingMode ( ProcessingMode mode )

protectedvirtual

Update the views GUI based on the set ProcessingMode (RealTime=0, Offline=1).

Parameters

[in] mode The new mode (RealTime=0, Offline=1).

Implements DISPLIB::AbstractView.

Definition at line 234 of file connectivitysettingsview.cpp.

◆ windowTypeChanged

void DISPLIB::ConnectivitySettingsView::windowTypeChanged ( const QString & windowType )

signal

Emit signal whenever the window type changed.

Parameters

[in] windowType The new window type.

Member Data Documentation

◆ m_iNumberTrials

int DISPLIB::ConnectivitySettingsView::m_iNumberTrials

protected

The number of trials are stored to check whether the number of trials actually changed.

Definition at line 250 of file connectivitysettingsview.h.

◆ m_pUi

Ui::ConnectivitySettingsViewWidget* DISPLIB::ConnectivitySettingsView::m_pUi

protected

Definition at line 247 of file connectivitysettingsview.h.

◆ m_sSettingsPath

QString DISPLIB::ConnectivitySettingsView::m_sSettingsPath

protected

The settings path to store the GUI settings to.

Definition at line 249 of file connectivitysettingsview.h.

The documentation for this class was generated from the following files:

src/libraries/disp/viewers/connectivitysettingsview.h
src/libraries/disp/viewers/connectivitysettingsview.cpp
