FIFFLIB::FiffSparseMatrix Class Reference

Data associated with MNE computations for each mneMeasDataSet. More...

#include <fiff_sparse_matrix.h>

Public Types
typedef QSharedPointer< FiffSparseMatrix >	SPtr
typedef QSharedPointer< const FiffSparseMatrix >	ConstSPtr

Public Member Functions
	FiffSparseMatrix ()
	FiffSparseMatrix (const FiffSparseMatrix &mat)
	~FiffSparseMatrix ()
FIFFLIB::FiffSparseMatrix *	mne_add_upper_triangle_rcs ()

Static Public Member Functions
static FIFFLIB::fiff_int_t *	fiff_get_matrix_sparse_dims (FIFFLIB::FiffTag::SPtr &tag)
static FIFFLIB::FiffSparseMatrix *	fiff_get_float_sparse_matrix (FIFFLIB::FiffTag::SPtr &tag)
static FIFFLIB::FiffSparseMatrix *	create_sparse_rcs (int nrow, int ncol, int *nnz, int **colindex, float **vals)

Public Attributes
FIFFLIB::fiff_int_t	coding
FIFFLIB::fiff_int_t	m
FIFFLIB::fiff_int_t	n
FIFFLIB::fiff_int_t	nz
FIFFLIB::fiff_float_t *	data
FIFFLIB::fiff_int_t *	inds
FIFFLIB::fiff_int_t *	ptrs

Detailed Description

Data associated with MNE computations for each mneMeasDataSet.

Implements MNE Mne Data (Replaces *mneMneData,mneMneDataRec; struct of MNE-C mne_types.h).

Definition at line 74 of file fiff_sparse_matrix.h.

Member Typedef Documentation

ConstSPtr

typedef QSharedPointer<const FiffSparseMatrix> FIFFLIB::FiffSparseMatrix::ConstSPtr

Const shared pointer type for FiffSparseMatrix.

Definition at line 78 of file fiff_sparse_matrix.h.

SPtr

typedef QSharedPointer<FiffSparseMatrix> FIFFLIB::FiffSparseMatrix::SPtr

Shared pointer type for FiffSparseMatrix.

Definition at line 77 of file fiff_sparse_matrix.h.

Constructor & Destructor Documentation

FiffSparseMatrix() [1/2]

FiffSparseMatrix::FiffSparseMatrix

(

)

Constructs the FiffSparseMatrix

Definition at line 149 of file fiff_sparse_matrix.cpp.

FiffSparseMatrix() [2/2]

FiffSparseMatrix::FiffSparseMatrix

(

const FiffSparseMatrix &

mat

)

Copies a FiffSparseMatrix Refactored: mne_dup_sparse_matrix (mne_sparse_matop.c)

Parameters

[in]

mat

The Sparse Matrix which should be copied.

Definition at line 162 of file fiff_sparse_matrix.cpp.

~FiffSparseMatrix()

FiffSparseMatrix::~FiffSparseMatrix

(

)

Destroys the FiffSparseMatrix description Refactored: mne_free_sparse (mne_sparse_matop.c)

Definition at line 191 of file fiff_sparse_matrix.cpp.

Member Function Documentation

create_sparse_rcs()

FiffSparseMatrix * FiffSparseMatrix::create_sparse_rcs ( int nrow, int ncol, int * nnz, int ** colindex, float ** vals )

static

Definition at line 269 of file fiff_sparse_matrix.cpp.

fiff_get_float_sparse_matrix()

FiffSparseMatrix * FiffSparseMatrix::fiff_get_float_sparse_matrix ( FIFFLIB::FiffTag::SPtr & tag )

static

Definition at line 206 of file fiff_sparse_matrix.cpp.

fiff_get_matrix_sparse_dims()

fiff_int_t * FiffSparseMatrix::fiff_get_matrix_sparse_dims ( FIFFLIB::FiffTag::SPtr & tag )

static

Definition at line 199 of file fiff_sparse_matrix.cpp.

mne_add_upper_triangle_rcs()

FiffSparseMatrix * FiffSparseMatrix::mne_add_upper_triangle_rcs

(

)

Definition at line 333 of file fiff_sparse_matrix.cpp.

Member Data Documentation

coding

FIFFLIB::fiff_int_t FIFFLIB::FiffSparseMatrix::coding

coding (storage) type of the sparse matrix.

Definition at line 125 of file fiff_sparse_matrix.h.

data

FIFFLIB::fiff_float_t* FIFFLIB::FiffSparseMatrix::data

owns the data.

Definition at line 129 of file fiff_sparse_matrix.h.

inds

FIFFLIB::fiff_int_t* FIFFLIB::FiffSparseMatrix::inds

index list, points into data, no dealloc!.

Definition at line 130 of file fiff_sparse_matrix.h.

m

FIFFLIB::fiff_int_t FIFFLIB::FiffSparseMatrix::m

m rows.

Definition at line 126 of file fiff_sparse_matrix.h.

n

FIFFLIB::fiff_int_t FIFFLIB::FiffSparseMatrix::n

n columns.

Definition at line 127 of file fiff_sparse_matrix.h.

nz

FIFFLIB::fiff_int_t FIFFLIB::FiffSparseMatrix::nz

nz nonzeros.

Definition at line 128 of file fiff_sparse_matrix.h.

ptrs

FIFFLIB::fiff_int_t* FIFFLIB::FiffSparseMatrix::ptrs

pointer list, points into data, no dealloc!.

Definition at line 131 of file fiff_sparse_matrix.h.

---

The documentation for this class was generated from the following files:

• src/libraries/fiff/c/fiff_sparse_matrix.h
• src/libraries/fiff/c/fiff_sparse_matrix.cpp
