Measurement channel position and coil type. More...

#include <fiff_ch_pos.h>

Public Types
using	SPtr = QSharedPointer<FiffChPos>
using	ConstSPtr = QSharedPointer<const FiffChPos>
using	UPtr = std::unique_ptr<FiffChPos>
using	ConstUPtr = std::unique_ptr<const FiffChPos>

Public Member Functions
	FiffChPos ()
	FiffChPos (const FiffChPos &p_FiffChPos)
	~FiffChPos ()

Static Public Member Functions
static qint32	storageSize ()

Public Attributes
fiff_int_t	coil_type
Eigen::Vector3f	r0
Eigen::Vector3f	ex
Eigen::Vector3f	ey
Eigen::Vector3f	ez

Friends
bool	operator== (const FiffChPos &a, const FiffChPos &b)

Detailed Description

Measurement channel position and coil type.

Coil position description.

Definition at line 67 of file fiff_ch_pos.h.

Member Typedef Documentation

◆ ConstSPtr

using FIFFLIB::FiffChPos::ConstSPtr = QSharedPointer<const FiffChPos>

Const shared pointer type for FiffChPos.

Definition at line 71 of file fiff_ch_pos.h.

◆ ConstUPtr

using FIFFLIB::FiffChPos::ConstUPtr = std::unique_ptr<const FiffChPos>

Const unique pointer type for FiffChPos.

Definition at line 73 of file fiff_ch_pos.h.

◆ SPtr

using FIFFLIB::FiffChPos::SPtr = QSharedPointer<FiffChPos>

Shared pointer type for FiffChPos.

Definition at line 70 of file fiff_ch_pos.h.

◆ UPtr

using FIFFLIB::FiffChPos::UPtr = std::unique_ptr<FiffChPos>

Unique pointer type for FiffChPos.

Definition at line 72 of file fiff_ch_pos.h.

Constructor & Destructor Documentation

◆ FiffChPos() [1/2]

FiffChPos::FiffChPos ( )

Constructs the coil position descriptor.

Definition at line 53 of file fiff_ch_pos.cpp.

◆ FiffChPos() [2/2]

FiffChPos::FiffChPos ( const FiffChPos & p_FiffChPos )

Copy constructor.

Parameters

[in] p_FiffChPos Coil position descriptor which should be copied.

Definition at line 67 of file fiff_ch_pos.cpp.

◆ ~FiffChPos()

FiffChPos::~FiffChPos ( )

Destroys the coil position descriptor.

Definition at line 81 of file fiff_ch_pos.cpp.

Member Function Documentation

◆ storageSize()

qint32 FIFFLIB::FiffChPos::storageSize ( )

inlinestatic

Size of the old struct (fiffChPosRec) 13*int = 13*4 = 52

Returns: the size of the old struct fiffChPosRec.

Definition at line 126 of file fiff_ch_pos.h.

◆ operator==

bool operator==	(	const FiffChPos &	a,
		const FiffChPos &	b )

friend

Overloaded == operator to compare an object to this instance.

Parameters

[in] object The object which should be compared to.

Returns: true if equal, false otherwise.

Definition at line 135 of file fiff_ch_pos.h.

Member Data Documentation

◆ coil_type

fiff_int_t FIFFLIB::FiffChPos::coil_type

What kind of coil.

Definition at line 114 of file fiff_ch_pos.h.

◆ ex

Eigen::Vector3f FIFFLIB::FiffChPos::ex

Coil coordinate system x-axis unit vector.

Definition at line 116 of file fiff_ch_pos.h.

◆ ey

Eigen::Vector3f FIFFLIB::FiffChPos::ey

Coil coordinate system y-axis unit vector.

Definition at line 117 of file fiff_ch_pos.h.

◆ ez

Eigen::Vector3f FIFFLIB::FiffChPos::ez

Coil coordinate system z-axis unit vector.

Definition at line 118 of file fiff_ch_pos.h.

◆ r0

Eigen::Vector3f FIFFLIB::FiffChPos::r0

Coil coordinate system origin.

Definition at line 115 of file fiff_ch_pos.h.

The documentation for this class was generated from the following files:

src/libraries/fiff/fiff_ch_pos.h
src/libraries/fiff/fiff_ch_pos.cpp
