Directory node structure. More...

#include <fiff_dir_node.h>

Public Types
using	SPtr = QSharedPointer<FiffDirNode>
using	ConstSPtr = QSharedPointer<const FiffDirNode>
using	UPtr = std::unique_ptr<FiffDirNode>
using	ConstUPtr = std::unique_ptr<const FiffDirNode>

Public Member Functions
	FiffDirNode ()
	FiffDirNode (const FiffDirNode *p_FiffDirTree)
	~FiffDirNode ()
bool	isEmpty () const
QList< FiffDirNode::SPtr >	dir_tree_find (fiff_int_t p_kind) const
bool	find_tag (QSharedPointer< FiffStream > &p_pStream, fiff_int_t findkind, std::unique_ptr< FiffTag > &p_pTag) const
bool	find_tag (FiffStream *p_pStream, fiff_int_t findkind, std::unique_ptr< FiffTag > &p_pTag) const
bool	has_tag (fiff_int_t findkind)
bool	has_kind (fiff_int_t p_kind) const
void	print (int indent) const
fiff_int_t	nent () const
fiff_int_t	nchild () const

Static Public Member Functions
static bool	copy_tree (QSharedPointer< FiffStream > &p_pStreamIn, const FiffId &in_id, const QList< QSharedPointer< FiffDirNode > > &p_Nodes, QSharedPointer< FiffStream > &p_pStreamOut)
static void	explain_block (int kind)
static void	explain (int kind)
static const char *	get_tag_explanation (int kind)

Public Attributes
fiff_int_t	type
FiffId	id
QList< FiffDirEntry::SPtr >	dir
QList< FiffDirEntry::SPtr >	dir_tree
fiff_int_t	nent_tree
FiffDirNode::SPtr	parent
FiffId	parent_id
QList< FiffDirNode::SPtr >	children

Detailed Description

Directory node structure.

FIFF directory tree node.

Definition at line 75 of file fiff_dir_node.h.

Member Typedef Documentation

◆ ConstSPtr

using FIFFLIB::FiffDirNode::ConstSPtr = QSharedPointer<const FiffDirNode>

Const shared pointer type for FiffDirNode.

Definition at line 78 of file fiff_dir_node.h.

◆ ConstUPtr

using FIFFLIB::FiffDirNode::ConstUPtr = std::unique_ptr<const FiffDirNode>

Const unique pointer type for FiffDirNode.

Definition at line 80 of file fiff_dir_node.h.

◆ SPtr

using FIFFLIB::FiffDirNode::SPtr = QSharedPointer<FiffDirNode>

Shared pointer type for FiffDirNode.

Definition at line 77 of file fiff_dir_node.h.

◆ UPtr

using FIFFLIB::FiffDirNode::UPtr = std::unique_ptr<FiffDirNode>

Unique pointer type for FiffDirNode.

Definition at line 79 of file fiff_dir_node.h.

Constructor & Destructor Documentation

◆ FiffDirNode() [1/2]

FiffDirNode::FiffDirNode ( )

Constructors the directory tree structure.

Definition at line 60 of file fiff_dir_node.cpp.

◆ FiffDirNode() [2/2]

FiffDirNode::FiffDirNode ( const FiffDirNode * p_FiffDirTree )

Copy constructor.

Parameters

[in] p_FiffDirTree Directory tree structure which should be copied.

Definition at line 69 of file fiff_dir_node.cpp.

◆ ~FiffDirNode()

FiffDirNode::~FiffDirNode ( )

Destroys the fiffDirTree.

Definition at line 82 of file fiff_dir_node.cpp.

Member Function Documentation

◆ copy_tree()

bool FiffDirNode::copy_tree	(	QSharedPointer< FiffStream > &	p_pStreamIn,
		const FiffId &	in_id,
		const QList< QSharedPointer< FiffDirNode > > &	p_Nodes,
		QSharedPointer< FiffStream > &	p_pStreamOut )

static

Copies directory subtrees from fidin to fidout

Parameters

[in]	p_pStreamIn	fiff file to copy from.
[in]	in_id	file id description.
[in]	p_Nodes	subtree directories to be copied.
[out]	p_pStreamOut	fiff file to write to.

Returns: true if succeeded, false otherwise.

Definition at line 92 of file fiff_dir_node.cpp.

◆ dir_tree_find()

QList< FiffDirNode::SPtr > FiffDirNode::dir_tree_find ( fiff_int_t p_kind ) const

Find nodes of the given kind from a directory tree structure

Parameters

[in] p_kind the given kind.

Returns: list of the found nodes.

Definition at line 178 of file fiff_dir_node.cpp.

◆ explain()

void FiffDirNode::explain ( int kind )

static

Try to explain...

Parameters

[in] kind directory kind.

Definition at line 291 of file fiff_dir_node.cpp.

◆ explain_block()

void FiffDirNode::explain_block ( int kind )

static

Try to explain a block...

Parameters

[in] kind Block kind.

Definition at line 278 of file fiff_dir_node.cpp.

◆ find_tag() [1/2]

bool FIFFLIB::FiffDirNode::find_tag	(	FiffStream *	p_pStream,
		fiff_int_t	findkind,
		std::unique_ptr< FiffTag > &	p_pTag ) const

Definition of the find_tag function in various files e.g. fiff_read_named_matrix.m,

Founds a tag of a given kind within a tree, and reeds it from file. Note: In difference to mne-matlab this is not a static function. This is a method of the FiffDirNode class, that's why a tree object doesn't need to be handed to the function.

Parameters

[in]	p_pStream	the opened fif file.
[in]	findkind	the kind which should be found.
[out]	p_pTag	the found tag.

Returns: true if found, false otherwise.

◆ find_tag() [2/2]

bool FIFFLIB::FiffDirNode::find_tag	(	QSharedPointer< FiffStream > &	p_pStream,
		fiff_int_t	findkind,
		std::unique_ptr< FiffTag > &	p_pTag ) const

inline

Definition of the find_tag function in various files e.g. fiff_read_named_matrix.m,

Founds a tag of a given kind within a tree, and reeds it from file. Note: In difference to mne-matlab this is not a static function. This is a method of the FiffDirNode class, that's why a tree object doesn't need to be handed to the function.

Parameters

[in]	p_pStream	the opened fif file.
[in]	findkind	the kind which should be found.
[out]	p_pTag	the found tag.

Returns: true if found, false otherwise.

Definition at line 257 of file fiff_dir_node.h.

◆ get_tag_explanation()

const char * FiffDirNode::get_tag_explanation ( int kind )

static

Get textual explanation of a tag

Parameters

[in] kind directory kind.

Returns: Pointer to the static string explaining the tag, or nullptr if not found.

Definition at line 305 of file fiff_dir_node.cpp.

◆ has_kind()

bool FiffDirNode::has_kind ( fiff_int_t p_kind ) const

Checks whether a FiffDirNode has a specific kind

Parameters

[in] findkind kind to find.

Returns: true when fiff_dir_node contains kind.

Definition at line 221 of file fiff_dir_node.cpp.

◆ has_tag()

bool FiffDirNode::has_tag ( fiff_int_t findkind )

Definition of the has_tag function in fiff_read_named_matrix.m

Parameters

[in] findkind kind to find.

Returns: true when fiff_dir_node contains kind.

Definition at line 211 of file fiff_dir_node.cpp.

◆ isEmpty()

bool FIFFLIB::FiffDirNode::isEmpty ( ) const

inline

Returns true if directory tree structure contains no data.

Returns: true if directory tree structure is empty.

Definition at line 121 of file fiff_dir_node.h.

◆ nchild()

fiff_int_t FiffDirNode::nchild ( ) const

Returns the number of child nodes

Returns: Number of child nodes.

Definition at line 324 of file fiff_dir_node.cpp.

◆ nent()

fiff_int_t FiffDirNode::nent ( ) const

Returns the number of entries in this node

Returns: Number of entries in this node.

Definition at line 317 of file fiff_dir_node.cpp.

◆ print()

void FiffDirNode::print ( int indent ) const

Prints elements of a tree.

Parameters

[in] indent number of intendations.

Definition at line 236 of file fiff_dir_node.cpp.

Member Data Documentation

◆ children

QList<FiffDirNode::SPtr> FIFFLIB::FiffDirNode::children

Child nodes.

Definition at line 248 of file fiff_dir_node.h.

◆ dir

QList<FiffDirEntry::SPtr> FIFFLIB::FiffDirNode::dir

Directory of tags in this node.

Definition at line 241 of file fiff_dir_node.h.

◆ dir_tree

QList<FiffDirEntry::SPtr> FIFFLIB::FiffDirNode::dir_tree

Directory of tags within this node subtrees as well as FIFF_BLOCK_START and FIFF_BLOCK_END

Definition at line 243 of file fiff_dir_node.h.

◆ id

FiffId FIFFLIB::FiffDirNode::id

Id of this block if any.

Definition at line 240 of file fiff_dir_node.h.

◆ nent_tree

fiff_int_t FIFFLIB::FiffDirNode::nent_tree

Number of entries in the directory tree node.

Definition at line 245 of file fiff_dir_node.h.

◆ parent

FiffDirNode::SPtr FIFFLIB::FiffDirNode::parent

Parent node.

Definition at line 246 of file fiff_dir_node.h.

◆ parent_id

FiffId FIFFLIB::FiffDirNode::parent_id

Newly added to stay consistent with MATLAB implementation.

Definition at line 247 of file fiff_dir_node.h.

◆ type

fiff_int_t FIFFLIB::FiffDirNode::type

Block type for this directory.

Definition at line 239 of file fiff_dir_node.h.

The documentation for this class was generated from the following files:

src/libraries/fiff/fiff_dir_node.h
src/libraries/fiff/fiff_dir_node.cpp
