FWDLIB::FwdCompData Class Reference

This structure is used in the compensated field calculations. More...

#include <fwd_comp_data.h>

Public Member Functions
	FwdCompData ()
	~FwdCompData ()

Static Public Member Functions
static int	fwd_comp_field (const Eigen::Vector3f &rd, const Eigen::Vector3f &Q, FwdCoilSet &coils, Eigen::Ref< Eigen::VectorXf > res, void *client)
static int	fwd_make_ctf_comp_coils (MNELIB::MNECTFCompDataSet *set, FwdCoilSet *coils, FwdCoilSet *comp_coils)
static FwdCompData *	fwd_make_comp_data (MNELIB::MNECTFCompDataSet *set, FwdCoilSet *coils, FwdCoilSet *comp_coils, fwdFieldFunc field, fwdVecFieldFunc vec_field, fwdFieldGradFunc field_grad, void *client)
static int	fwd_comp_field_vec (const Eigen::Vector3f &rd, FwdCoilSet &coils, Eigen::Ref< Eigen::MatrixXf > res, void *client)
static int	fwd_comp_field_grad (const Eigen::Vector3f &rd, const Eigen::Vector3f &Q, FwdCoilSet &coils, Eigen::Ref< Eigen::VectorXf > res, Eigen::Ref< Eigen::VectorXf > xgrad, Eigen::Ref< Eigen::VectorXf > ygrad, Eigen::Ref< Eigen::VectorXf > zgrad, void *client)

Public Attributes
MNELIB::MNECTFCompDataSet *	set
FwdCoilSet *	comp_coils
fwdFieldFunc	field
fwdVecFieldFunc	vec_field
fwdFieldGradFunc	field_grad
void *	client
Eigen::VectorXf	work
Eigen::MatrixXf	vec_work

Detailed Description

This structure is used in the compensated field calculations.

Implements the Forward Compensation Data description (Replaces *fwdCompData,fwdCompDataRec; struct of MNE-C fwd_comp_data.h).

Definition at line 85 of file fwd_comp_data.h.

Constructor & Destructor Documentation

FwdCompData()

FwdCompData::FwdCompData

(

)

Constructs the Forward Compensation Data

Definition at line 64 of file fwd_comp_data.cpp.

~FwdCompData()

FwdCompData::~FwdCompData

(

)

Destroys the Forward Compensation Data

Definition at line 76 of file fwd_comp_data.cpp.

Member Function Documentation

fwd_comp_field()

int FwdCompData::fwd_comp_field ( const Eigen::Vector3f & rd, const Eigen::Vector3f & Q, FwdCoilSet & coils, Eigen::Ref< Eigen::VectorXf > res, void * client )

static

Calculate the compensated field for one dipole component.

Parameters

[in]	rd	Dipole position.
[in]	Q	Dipole moment direction.
[in]	coils	Coil definitions.
[out]	res	Result vector.
[in]	client	Pointer to FwdCompData.

Returns

OK on success, FAIL on error.

Definition at line 86 of file fwd_comp_data.cpp.

fwd_comp_field_grad()

int FwdCompData::fwd_comp_field_grad ( const Eigen::Vector3f & rd, const Eigen::Vector3f & Q, FwdCoilSet & coils, Eigen::Ref< Eigen::VectorXf > res, Eigen::Ref< Eigen::VectorXf > xgrad, Eigen::Ref< Eigen::VectorXf > ygrad, Eigen::Ref< Eigen::VectorXf > zgrad, void * client )

static

Calculate the compensated field and gradient for one dipole component.

Parameters

[in]	rd	Dipole position.
[in]	Q	Dipole moment direction.
[in]	coils	Coil definitions.
[out]	res	Result vector.
[out]	xgrad	X-gradient result.
[out]	ygrad	Y-gradient result.
[out]	zgrad	Z-gradient result.
[in]	client	Pointer to FwdCompData.

Returns

OK on success, FAIL on error.

Definition at line 247 of file fwd_comp_data.cpp.

fwd_comp_field_vec()

int FwdCompData::fwd_comp_field_vec ( const Eigen::Vector3f & rd, FwdCoilSet & coils, Eigen::Ref< Eigen::MatrixXf > res, void * client )

static

Calculate the compensated field for all three dipole components.

Parameters

[in]	rd	Dipole position.
[in]	coils	Coil definitions.
[out]	res	Result matrix (3 x ncoil).
[in]	client	Pointer to FwdCompData.

Returns

OK on success, FAIL on error.

Definition at line 204 of file fwd_comp_data.cpp.

fwd_make_comp_data()

FwdCompData * FwdCompData::fwd_make_comp_data ( MNELIB::MNECTFCompDataSet * set, FwdCoilSet * coils, FwdCoilSet * comp_coils, fwdFieldFunc field, fwdVecFieldFunc vec_field, fwdFieldGradFunc field_grad, void * client )

static

Compose a compensation data set.

Parameters

[in]	set	CTF compensation data read from file.
[in]	coils	Principal coil set.
[in]	comp_coils	Compensation coils.
[in]	field	Field computation function (single dipole component).
[in]	vec_field	Vector field computation function (all components).
[in]	field_grad	Field and gradient computation function.
[in]	client	Client data passed to the computation functions.

Returns

Pointer to the created FwdCompData, or nullptr on error. Caller owns the pointer.

Definition at line 164 of file fwd_comp_data.cpp.

fwd_make_ctf_comp_coils()

int FwdCompData::fwd_make_ctf_comp_coils ( MNELIB::MNECTFCompDataSet * set, FwdCoilSet * coils, FwdCoilSet * comp_coils )

static

Set up CTF compensation coils for field computations.

Parameters

[in]	set	Available compensation data.
[in]	coils	Main coil set.
[in]	comp_coils	Compensation coils.

Returns

OK on success, FAIL on error.

Definition at line 122 of file fwd_comp_data.cpp.

Member Data Documentation

client

void* FWDLIB::FwdCompData::client

Client data to pass to the above functions.

Definition at line 189 of file fwd_comp_data.h.

comp_coils

FwdCoilSet* FWDLIB::FwdCompData::comp_coils

The compensation coil definitions.

Definition at line 185 of file fwd_comp_data.h.

field

fwdFieldFunc FWDLIB::FwdCompData::field

Computes the field of given direction dipole.

Definition at line 186 of file fwd_comp_data.h.

field_grad

fwdFieldGradFunc FWDLIB::FwdCompData::field_grad

Computes the field and gradient of one dipole direction.

Definition at line 188 of file fwd_comp_data.h.

set

MNELIB::MNECTFCompDataSet* FWDLIB::FwdCompData::set

The compensation data set.

Definition at line 184 of file fwd_comp_data.h.

vec_field

fwdVecFieldFunc FWDLIB::FwdCompData::vec_field

Computes the fields of all three dipole components.

Definition at line 187 of file fwd_comp_data.h.

vec_work

Eigen::MatrixXf FWDLIB::FwdCompData::vec_work

The vector work area (3 x ncoil).

Definition at line 191 of file fwd_comp_data.h.

work

Eigen::VectorXf FWDLIB::FwdCompData::work

The work area.

Definition at line 190 of file fwd_comp_data.h.

---

The documentation for this class was generated from the following files:

• src/libraries/fwd/fwd_comp_data.h
• src/libraries/fwd/fwd_comp_data.cpp
