INVLIB::InvLCMV Class Reference

LCMV beamformer (time-domain). More...

#include <inv_lcmv.h>

Static Public Member Functions
static InvBeamformer	makeLCMV (const FIFFLIB::FiffInfo &info, const MNELIB::MNEForwardSolution &forward, const FIFFLIB::FiffCov &dataCov, double reg=0.05, const FIFFLIB::FiffCov &noiseCov=FIFFLIB::FiffCov(), BeamformerPickOri pickOri=BeamformerPickOri::None, BeamformerWeightNorm weightNorm=BeamformerWeightNorm::UnitNoiseGain, bool reduceRank=false, BeamformerInversion invMethod=BeamformerInversion::Matrix)
static InvSourceEstimate	applyLCMV (const FIFFLIB::FiffEvoked &evoked, const InvBeamformer &filters)
static InvSourceEstimate	applyLCMVRaw (const Eigen::MatrixXd &data, float tmin, float tstep, const InvBeamformer &filters)
static InvSourceEstimate	applyLCMVCov (const FIFFLIB::FiffCov &dataCov, const InvBeamformer &filters)

Detailed Description

LCMV beamformer (time-domain).

Linearly Constrained Minimum Variance (LCMV) beamformer for MEG/EEG source localization.

Typical workflow:

// 1. Compute the spatial filter from forward model + data covariance
InvBeamformer filters = InvLCMV::makeLCMV(info, forward, dataCov, noiseCov, reg,
                                           pickOri, weightNorm, reduceRank, inversion);

// 2. Apply to evoked data -> source time courses
InvSourceEstimate stc = InvLCMV::applyLCMV(evoked, filters);

// 3. Or apply to covariance -> source power map
InvSourceEstimate power = InvLCMV::applyLCMVCov(dataCov, filters);

Definition at line 85 of file inv_lcmv.h.

Member Function Documentation

applyLCMV()

InvSourceEstimate InvLCMV::applyLCMV ( const FIFFLIB::FiffEvoked & evoked, const InvBeamformer & filters )

static

Apply LCMV beamformer to evoked data to produce source time courses.

stc = W @ (whitener @ proj @ evoked.data)

Parameters

[in]	evoked	Evoked data (averaged, channel x time).
[in]	filters	Pre-computed LCMV beamformer from makeLCMV().

Returns

Source estimate with time courses at each source point.

Definition at line 227 of file inv_lcmv.cpp.

applyLCMVCov()

InvSourceEstimate InvLCMV::applyLCMVCov ( const FIFFLIB::FiffCov & dataCov, const InvBeamformer & filters )

static

Apply LCMV beamformer to a data covariance to produce a source power map.

power_i = trace(W_i @ Cm @ W_i^T)

Parameters

[in]	dataCov	Data covariance matrix.
[in]	filters	Pre-computed LCMV beamformer from makeLCMV().

Returns

Source estimate where data column 0 contains power at each source.

Definition at line 295 of file inv_lcmv.cpp.

applyLCMVRaw()

InvSourceEstimate InvLCMV::applyLCMVRaw ( const Eigen::MatrixXd & data, float tmin, float tstep, const InvBeamformer & filters )

static

Apply LCMV beamformer to raw data matrix.

Parameters

[in]	data	Data matrix (n_channels, n_times).
[in]	tmin	Start time in seconds.
[in]	tstep	Time step in seconds.
[in]	filters	Pre-computed LCMV beamformer from makeLCMV().

Returns

Source estimate with time courses.

Definition at line 262 of file inv_lcmv.cpp.

makeLCMV()

InvBeamformer InvLCMV::makeLCMV ( const FIFFLIB::FiffInfo & info, const MNELIB::MNEForwardSolution & forward, const FIFFLIB::FiffCov & dataCov, double reg = 0.05, const FIFFLIB::FiffCov & noiseCov = FIFFLIB::FiffCov(), BeamformerPickOri pickOri = BeamformerPickOri::None, BeamformerWeightNorm weightNorm = BeamformerWeightNorm::UnitNoiseGain, bool reduceRank = false, BeamformerInversion invMethod = BeamformerInversion::Matrix )

static

Compute LCMV beamformer spatial filters.

Parameters

[in]	info	Measurement info (for channel matching).
[in]	forward	Forward solution containing the leadfield.
[in]	dataCov	Data covariance matrix (from recording epoch).
[in]	reg	Regularization parameter (default 0.05 = 5% of trace).
[in]	noiseCov	Noise covariance for whitening. If empty, identity whitening.
[in]	pickOri	Orientation selection mode (default: None = keep all).
[in]	weightNorm	Weight normalization (default: UnitNoiseGain).
[in]	reduceRank	Reduce leadfield rank by 1 (default: false).
[in]	invMethod	Inversion method for denominator (default: Matrix).

Returns

The computed beamformer containing spatial filter weights.

Definition at line 70 of file inv_lcmv.cpp.

---

The documentation for this class was generated from the following files:

• src/libraries/inv/beamformer/inv_lcmv.h
• src/libraries/inv/beamformer/inv_lcmv.cpp
