INVLIB::InvHpiFit Class Reference

HPI Fit algorithms. More...

#include <inv_hpi_fit.h>

Public Types
typedef QSharedPointer< InvHpiFit >	SPtr
typedef QSharedPointer< const InvHpiFit >	ConstSPtr

Public Member Functions
	InvHpiFit ()
	InvHpiFit (const InvSensorSet &sensorSet)
void	checkForUpdate (const InvSensorSet &sensorSet)
void	fit (const Eigen::MatrixXd &matProjectedData, const Eigen::MatrixXd &matProjectors, const InvHpiModelParameters &hpiModelParameters, const Eigen::MatrixXd &matCoilsHead, HpiFitResult &hpiFitResult)
void	fit (const Eigen::MatrixXd &matProjectedData, const Eigen::MatrixXd &matProjectors, const InvHpiModelParameters &hpiModelParameters, const Eigen::MatrixXd &matCoilsHead, const bool bOrderFrequencies, HpiFitResult &hpiFitResult)

Static Public Member Functions
static void	storeHeadPosition (float fTime, const Eigen::MatrixXf &matTransDevHead, Eigen::MatrixXd &matPosition, const Eigen::VectorXd &vecGoF, const QVector< double > &vecError)
static bool	compareTransformation (const Eigen::MatrixX4f &mDevHeadT, const Eigen::MatrixX4f &mDevHeadDest, const float &fThreshRot, const float &fThreshTrans)

Detailed Description

HPI Fit algorithms.

HPI Fit algorithms.

Definition at line 140 of file inv_hpi_fit.h.

Member Typedef Documentation

ConstSPtr

typedef QSharedPointer<const InvHpiFit> INVLIB::InvHpiFit::ConstSPtr

Const shared pointer type for InvHpiFit.

Definition at line 145 of file inv_hpi_fit.h.

SPtr

typedef QSharedPointer<InvHpiFit> INVLIB::InvHpiFit::SPtr

Shared pointer type for InvHpiFit.

Definition at line 144 of file inv_hpi_fit.h.

Constructor & Destructor Documentation

InvHpiFit() [1/2]

INVLIB::InvHpiFit::InvHpiFit ( )

explicit

Default constructor.

InvHpiFit() [2/2]

InvHpiFit::InvHpiFit ( const InvSensorSet & sensorSet )

explicit

Constructs the HPI from a InvSensorSet.

Parameters

[in]

InvSensorSet

The MEG sensorSet used for the hpi fitting.

Definition at line 95 of file inv_hpi_fit.cpp.

Member Function Documentation

checkForUpdate()

void InvHpiFit::checkForUpdate

(

const InvSensorSet &

sensorSet

)

Checks if InvSensorSet has changed and updates member InvSensorSet.

Parameters

[in]

InvSensorSet

The MEG sensorSet used for the hpi fitting.

Definition at line 104 of file inv_hpi_fit.cpp.

compareTransformation()

bool InvHpiFit::compareTransformation ( const Eigen::MatrixX4f & mDevHeadT, const Eigen::MatrixX4f & mDevHeadDest, const float & fThreshRot, const float & fThreshTrans )

static

Compares two 4x4 transformation matrices by evaluating their rotation and translation differences against given thresholds.

Parameters

[in]	mDevHeadT	The first transformation matrix.
[in]	mDevHeadDest	The second (destination) transformation matrix.
[in]	fThreshRot	The rotation threshold in degrees.
[in]	fThreshTrans	The translation threshold in meters.

Returns

True if the movement exceeds either threshold.

Definition at line 556 of file inv_hpi_fit.cpp.

fit() [1/2]

void INVLIB::InvHpiFit::fit	(	const Eigen::MatrixXd &	matProjectedData,
		const Eigen::MatrixXd &	matProjectors,
		const InvHpiModelParameters &	hpiModelParameters,
		const Eigen::MatrixXd &	matCoilsHead,
		const bool	bOrderFrequencies,
		HpiFitResult &	hpiFitResult )

fit() [2/2]

void INVLIB::InvHpiFit::fit	(	const Eigen::MatrixXd &	matProjectedData,
		const Eigen::MatrixXd &	matProjectors,
		const InvHpiModelParameters &	hpiModelParameters,
		const Eigen::MatrixXd &	matCoilsHead,
		HpiFitResult &	hpiFitResult )

Perform one single HPI fit.

Parameters

[in]	matProjectedData	Data to estimate the HPI positions from. Projectars should be already applied.
[in]	matProjectors	The projectors to apply.
[in]	hpiModelParameters	The model parameters to use for the Hpi Fitting, especially to compute the coil amplitudes.
[in]	matCoilsHead	The hpi coil locations in head space.
[in]	bOrderFrequencies	Order Hpi coils yes/no.
[out]	hpiFitResult	The fitting results.

storeHeadPosition()

void InvHpiFit::storeHeadPosition ( float fTime, const Eigen::MatrixXf & matTransDevHead, Eigen::MatrixXd & matPosition, const Eigen::VectorXd & vecGoF, const QVector< double > & vecError )

static

Store results from dev_Head_t as quaternions in position matrix. The format is the same as you get from Neuromag's MaxFilter.

Parameters

[in]	fTime	The corresponding time in the measurement for the fit.
[in]	matTransDevHead	The device->head transformation matrix.
[out]	matPosition	The matrix to store the results.
[in]	vecGoF	The goodness of fit per coil.
[in]	vecError	The Hpi estimation Error per coil.

Definition at line 529 of file inv_hpi_fit.cpp.

---

The documentation for this class was generated from the following files:

• src/libraries/inv/hpi/inv_hpi_fit.h
• src/libraries/inv/hpi/inv_hpi_fit.cpp
