INVLIB::InvHpiFitData Class Reference

HPI Fit algorithm data structure. More...

#include <inv_hpi_fit_data.h>

Public Types
typedef QSharedPointer< InvHpiFitData >	SPtr
typedef QSharedPointer< const InvHpiFitData >	ConstSPtr

Public Member Functions
	InvHpiFitData ()
void	doDipfitConcurrent ()

Public Attributes
Eigen::MatrixXd	m_coilPos
Eigen::RowVectorXd	m_sensorData
DipFitError	m_errorInfo
InvSensorSet	m_sensors
Eigen::MatrixXd	m_matProjector
int	m_iMaxIterations
float	m_fAbortError

Protected Member Functions
Eigen::MatrixXd	magnetic_dipole (Eigen::MatrixXd matPos, Eigen::MatrixXd matPnt, Eigen::MatrixXd matOri)
Eigen::MatrixXd	compute_leadfield (const Eigen::MatrixXd &matPos, const InvSensorSet &sensors)
DipFitError	dipfitError (const Eigen::MatrixXd &matPos, const Eigen::MatrixXd &matData, const InvSensorSet &sensors, const Eigen::MatrixXd &matProjectors)
Eigen::MatrixXd	fminsearch (const Eigen::MatrixXd &matPos, int iMaxiter, int iMaxfun, int iDisplay, const Eigen::MatrixXd &matData, const Eigen::MatrixXd &matProjectors, const InvSensorSet &sensors, int &iSimplexNumitr)

Static Protected Member Functions
static bool	compare (HPISortStruct a, HPISortStruct b)

Detailed Description

HPI Fit algorithm data structure.

HPI Fit algorithm data structure.

Definition at line 112 of file inv_hpi_fit_data.h.

Member Typedef Documentation

ConstSPtr

typedef QSharedPointer<const InvHpiFitData> INVLIB::InvHpiFitData::ConstSPtr

Const shared pointer type for InvHpiFitData.

Definition at line 117 of file inv_hpi_fit_data.h.

SPtr

typedef QSharedPointer<InvHpiFitData> INVLIB::InvHpiFitData::SPtr

Shared pointer type for InvHpiFitData.

Definition at line 116 of file inv_hpi_fit_data.h.

Constructor & Destructor Documentation

InvHpiFitData()

InvHpiFitData::InvHpiFitData ( )

explicit

Default constructor.

Definition at line 74 of file inv_hpi_fit_data.cpp.

Member Function Documentation

compare()

bool InvHpiFitData::compare ( HPISortStruct a, HPISortStruct b )

staticprotected

Compare function for sorting

Definition at line 215 of file inv_hpi_fit_data.cpp.

compute_leadfield()

Eigen::MatrixXd InvHpiFitData::compute_leadfield ( const Eigen::MatrixXd & matPos, const InvSensorSet & sensors )

protected

compute_leadfield computes a forward solution for a dipole in a a volume conductor model. The forward solution is expressed as the leadfield matrix (Nchan*3), where each column corresponds with the potential or field distributions on all sensors for one of the x,y,z-orientations of the dipole. The function has been compared with matlab ft_compute_leadfield and it gives same output.

Definition at line 166 of file inv_hpi_fit_data.cpp.

dipfitError()

DipFitError InvHpiFitData::dipfitError ( const Eigen::MatrixXd & matPos, const Eigen::MatrixXd & matData, const InvSensorSet & sensors, const Eigen::MatrixXd & matProjectors )

protected

dipfitError computes the error between measured and model data and can be used for non-linear fitting of dipole position. The function has been compared with matlab dipfit_error and it gives same output

Definition at line 180 of file inv_hpi_fit_data.cpp.

doDipfitConcurrent()

void InvHpiFitData::doDipfitConcurrent

(

)

dipfit function is adapted from Fieldtrip Software.

Definition at line 81 of file inv_hpi_fit_data.cpp.

fminsearch()

Eigen::MatrixXd InvHpiFitData::fminsearch ( const Eigen::MatrixXd & matPos, int iMaxiter, int iMaxfun, int iDisplay, const Eigen::MatrixXd & matData, const Eigen::MatrixXd & matProjectors, const InvSensorSet & sensors, int & iSimplexNumitr )

protected

fminsearch Multidimensional unconstrained nonlinear minimization (Nelder-Mead). X = fminsearch(X0, iMaxiter, iMaxfun, iDisplay, matData, sensors) starts at X0 and attempts to find a local minimizer

Definition at line 222 of file inv_hpi_fit_data.cpp.

magnetic_dipole()

Eigen::MatrixXd InvHpiFitData::magnetic_dipole ( Eigen::MatrixXd matPos, Eigen::MatrixXd matPnt, Eigen::MatrixXd matOri )

protected

magnetic_dipole leadfield for a magnetic dipole in an infinite medium. The function has been compared with matlab magnetic_dipole and it gives same output.

Definition at line 111 of file inv_hpi_fit_data.cpp.

Member Data Documentation

m_coilPos

Eigen::MatrixXd INVLIB::InvHpiFitData::m_coilPos

Definition at line 131 of file inv_hpi_fit_data.h.

m_errorInfo

DipFitError INVLIB::InvHpiFitData::m_errorInfo

Definition at line 133 of file inv_hpi_fit_data.h.

m_fAbortError

float INVLIB::InvHpiFitData::m_fAbortError

Definition at line 138 of file inv_hpi_fit_data.h.

m_iMaxIterations

int INVLIB::InvHpiFitData::m_iMaxIterations

Definition at line 137 of file inv_hpi_fit_data.h.

m_matProjector

Eigen::MatrixXd INVLIB::InvHpiFitData::m_matProjector

Definition at line 135 of file inv_hpi_fit_data.h.

m_sensorData

Eigen::RowVectorXd INVLIB::InvHpiFitData::m_sensorData

Definition at line 132 of file inv_hpi_fit_data.h.

m_sensors

InvSensorSet INVLIB::InvHpiFitData::m_sensors

Definition at line 134 of file inv_hpi_fit_data.h.

---

The documentation for this class was generated from the following files:

• src/libraries/inv/hpi/inv_hpi_fit_data.h
• src/libraries/inv/hpi/inv_hpi_fit_data.cpp
