Single focal dipole with free 3D position, moment, and fit-quality metrics. More...

#include <inv_focal_dipole.h>

Public Member Functions
	InvFocalDipole ()

Public Attributes
Eigen::Vector3f	position
Eigen::Vector3f	moment
int	gridIndex
float	goodness
float	khi2
int	nfree
bool	valid
float	tmin
float	tmax

Detailed Description

Single focal dipole with free 3D position, moment, and fit-quality metrics.

Represents a single focal (off-grid) current dipole, typically the result of an equivalent current dipole (ECD) fit. The dipole has a free 3D position (not constrained to a source-space grid), a current moment, and associated fit quality metrics.

Definition at line 59 of file inv_focal_dipole.h.

Constructor & Destructor Documentation

◆ InvFocalDipole()

INVLIB::InvFocalDipole::InvFocalDipole ( )

inline

Definition at line 71 of file inv_focal_dipole.h.

Member Data Documentation

◆ goodness

float INVLIB::InvFocalDipole::goodness

Goodness-of-fit (0..1).

Definition at line 64 of file inv_focal_dipole.h.

◆ gridIndex

int INVLIB::InvFocalDipole::gridIndex

Nearest grid index (-1 if truly off-grid).

Definition at line 63 of file inv_focal_dipole.h.

◆ khi2

float INVLIB::InvFocalDipole::khi2

Chi-squared value of the fit.

Definition at line 65 of file inv_focal_dipole.h.

◆ moment

Eigen::Vector3f INVLIB::InvFocalDipole::moment

Current dipole moment (Am).

Definition at line 62 of file inv_focal_dipole.h.

◆ nfree

int INVLIB::InvFocalDipole::nfree

Degrees of freedom.

Definition at line 66 of file inv_focal_dipole.h.

◆ position

Eigen::Vector3f INVLIB::InvFocalDipole::position

Dipole position (m) in head coordinates.

Definition at line 61 of file inv_focal_dipole.h.

◆ tmax

float INVLIB::InvFocalDipole::tmax

End of the time window (s) this dipole represents.

Definition at line 69 of file inv_focal_dipole.h.

◆ tmin

float INVLIB::InvFocalDipole::tmin

Start of the time window (s) this dipole represents.

Definition at line 68 of file inv_focal_dipole.h.

◆ valid

bool INVLIB::InvFocalDipole::valid

Whether this dipole passed validity checks.

Definition at line 67 of file inv_focal_dipole.h.

The documentation for this struct was generated from the following file:

src/libraries/inv/inv_focal_dipole.h
