INVLIB::InvSourceCoupling Struct Reference

N-tuple of correlated grid sources with orientations and correlation matrix. More...

#include <inv_source_coupling.h>

Public Member Functions
	InvSourceCoupling ()

Public Attributes
std::vector< int >	gridIndices
std::vector< Eigen::Vector3d >	moments
Eigen::MatrixXd	correlations
float	tmin
float	tmax

Detailed Description

N-tuple of correlated grid sources with orientations and correlation matrix.

Describes a group of N coupled (correlated) source grid points found by algorithms such as RAP-MUSIC. The group can be a pair, triplet, or any N-tuple of grid indices together with their orientations and an N x N correlation matrix.

Definition at line 65 of file inv_source_coupling.h.

Constructor & Destructor Documentation

InvSourceCoupling()

InvSourceCoupling::InvSourceCoupling

(

)

Definition at line 51 of file inv_source_coupling.cpp.

Member Data Documentation

correlations

Eigen::MatrixXd INVLIB::InvSourceCoupling::correlations

N x N correlation matrix between the coupled sources.

Definition at line 69 of file inv_source_coupling.h.

gridIndices

std::vector<int> INVLIB::InvSourceCoupling::gridIndices

Grid indices of the coupled sources (size N).

Definition at line 67 of file inv_source_coupling.h.

moments

std::vector<Eigen::Vector3d> INVLIB::InvSourceCoupling::moments

Dipole moment / orientation for each coupled source (size N).

Definition at line 68 of file inv_source_coupling.h.

tmax

float INVLIB::InvSourceCoupling::tmax

End of the time window (s) this coupling represents.

Definition at line 71 of file inv_source_coupling.h.

tmin

float INVLIB::InvSourceCoupling::tmin

Start of the time window (s) this coupling represents.

Definition at line 70 of file inv_source_coupling.h.

---

The documentation for this struct was generated from the following files:

• src/libraries/inv/inv_source_coupling.h
• src/libraries/inv/inv_source_coupling.cpp
