Minimum norm estimation. More...

#include <inv_minimum_norm.h>

Public Types
typedef QSharedPointer< InvMinimumNorm >	SPtr
typedef QSharedPointer< const InvMinimumNorm >	ConstSPtr

Public Member Functions
	InvMinimumNorm (const MNELIB::MNEInverseOperator &p_inverseOperator, float lambda, const QString method)
	InvMinimumNorm (const MNELIB::MNEInverseOperator &p_inverseOperator, float lambda, bool dSPM, bool sLORETA)
virtual	~InvMinimumNorm ()
virtual InvSourceEstimate	calculateInverse (const FIFFLIB::FiffEvoked &p_fiffEvoked, bool pick_normal=false)
virtual InvSourceEstimate	calculateInverse (const Eigen::MatrixXd &data, float tmin, float tstep, bool pick_normal=false) const
virtual void	doInverseSetup (qint32 nave, bool pick_normal=false)
virtual const char *	getName () const
virtual const MNELIB::MNESourceSpaces &	getSourceSpace () const
MNELIB::MNEInverseOperator &	getPreparedInverseOperator ()
void	setMethod (QString method)
void	setMethod (bool dSPM, bool sLORETA, bool eLoreta=false)
void	setRegularization (float lambda)
void	setELoretaOptions (int maxIter=20, double eps=1e-6, bool forceEqual=false)
Eigen::MatrixXd &	getKernel ()

Detailed Description

Minimum norm estimation.

Minimum norm estimation algorithm.

Computes L2 minimum-norm, dSPM, or sLORETA source estimates from MEG/EEG data using a pre-computed inverse operator.

References:

Hamalainen & Ilmoniemi, Med. & Biol. Eng. & Comput. 32, 35-42, 1994.
Dale et al., Neuron 26, 55-67, 2000 (dSPM).
Pascual-Marqui, Methods Find. Exp. Clin. Pharmacol. 24D, 5-12, 2002 (sLORETA).

Definition at line 77 of file inv_minimum_norm.h.

Member Typedef Documentation

◆ ConstSPtr

typedef QSharedPointer<const InvMinimumNorm> INVLIB::InvMinimumNorm::ConstSPtr

Const shared pointer type for InvMinimumNorm.

Definition at line 81 of file inv_minimum_norm.h.

◆ SPtr

typedef QSharedPointer<InvMinimumNorm> INVLIB::InvMinimumNorm::SPtr

Shared pointer type for InvMinimumNorm.

Definition at line 80 of file inv_minimum_norm.h.

Constructor & Destructor Documentation

◆ InvMinimumNorm() [1/2]

InvMinimumNorm::InvMinimumNorm	(	const MNELIB::MNEInverseOperator &	p_inverseOperator,
		float	lambda,
		const QString	method )

explicit

Constructs minimum norm inverse algorithm

Parameters

[in]	p_inverseOperator	The inverse operator.
[in]	lambda	The regularization factor.
[in]	method	Use mininum norm, dSPM or sLORETA. ("MNE" \| "dSPM" \| "sLORETA").

Returns: the prepared inverse operator.

Definition at line 74 of file inv_minimum_norm.cpp.

◆ InvMinimumNorm() [2/2]

InvMinimumNorm::InvMinimumNorm	(	const MNELIB::MNEInverseOperator &	p_inverseOperator,
		float	lambda,
		bool	dSPM,
		bool	sLORETA )

explicit

Constructs minimum norm inverse algorithm

Parameters

[in]	p_inverseOperator	The inverse operator.
[in]	lambda	The regularization factor.
[in]	dSPM	Compute the noise-normalization factors for dSPM?.
[in]	sLORETA	Compute the noise-normalization factors for sLORETA?.

Returns: the prepared inverse operator.

Definition at line 88 of file inv_minimum_norm.cpp.

◆ ~InvMinimumNorm()

virtual INVLIB::InvMinimumNorm::~InvMinimumNorm ( )

inlinevirtual

Definition at line 108 of file inv_minimum_norm.h.

Member Function Documentation

◆ calculateInverse() [1/2]

virtual InvSourceEstimate INVLIB::InvMinimumNorm::calculateInverse	(	const Eigen::MatrixXd &	data,
		float	tmin,
		float	tstep,
		bool	pick_normal = false ) const

virtual

◆ calculateInverse() [2/2]

InvSourceEstimate InvMinimumNorm::calculateInverse	(	const FIFFLIB::FiffEvoked &	p_fiffEvoked,
		bool	pick_normal = false )

virtual

Computes a L2-norm inverse solution Actual code using these principles might be different because the inverse operator is often reused across data sets.

Parameters

[in]	p_fiffEvoked	Evoked data.
[in]	pick_normal	If True, rather than pooling the orientations by taking the norm, only the. radial component is kept. This is only applied when working with loose orientations.

Returns: the calculated source estimation.

Definition at line 102 of file inv_minimum_norm.cpp.

◆ doInverseSetup()

void InvMinimumNorm::doInverseSetup	(	qint32	nave,
		bool	pick_normal = false )

virtual

Perform the inverse setup: Prepares this inverse operator and assembles the kernel.

Parameters

[in]	nave	Number of averages to use.
[in]	pick_normal	If True, rather than pooling the orientations by taking the norm, only the. radial component is kept. This is only applied when working with loose orientations.

Definition at line 256 of file inv_minimum_norm.cpp.

◆ getKernel()

Eigen::MatrixXd & INVLIB::InvMinimumNorm::getKernel ( )

inline

Get the assembled kernel

Returns: the assembled kernel.

Definition at line 240 of file inv_minimum_norm.h.

◆ getName()

const char * InvMinimumNorm::getName ( ) const

virtual

Get the name of the inverse operator.

Returns: the name of the inverse operator.

Definition at line 278 of file inv_minimum_norm.cpp.

◆ getPreparedInverseOperator()

MNELIB::MNEInverseOperator & INVLIB::InvMinimumNorm::getPreparedInverseOperator ( )

inline

Get the prepared inverse operator.

Returns: the prepared inverse operator.

Definition at line 247 of file inv_minimum_norm.h.

◆ getSourceSpace()

const MNESourceSpaces & InvMinimumNorm::getSourceSpace ( ) const

virtual

Get the source space corresponding to this inverse operator.

Returns: the source space corresponding to this inverse operator.

Definition at line 285 of file inv_minimum_norm.cpp.

◆ setELoretaOptions()

void InvMinimumNorm::setELoretaOptions	(	int	maxIter = 20,
		double	eps = 1e-6,
		bool	forceEqual = false )

Set eLORETA options.

Parameters

[in]	maxIter	Maximum number of eLORETA weight iterations (default: 20).
[in]	eps	Convergence threshold for weight fitting (default: 1e-6).
[in]	forceEqual	If true, use uniform orientation weights (default: false).

Definition at line 348 of file inv_minimum_norm.cpp.

◆ setMethod() [1/2]

void InvMinimumNorm::setMethod	(	bool	dSPM,
		bool	sLORETA,
		bool	eLoreta = false )

Set minimum norm algorithm method ("MNE" | "dSPM" | "sLORETA" | "eLORETA")

Parameters

[in]	dSPM	Compute the noise-normalization factors for dSPM?.
[in]	sLORETA	Compute the noise-normalization factors for sLORETA?.
[in]	eLoreta	Compute the eLORETA source weights?.

Definition at line 314 of file inv_minimum_norm.cpp.

◆ setMethod() [2/2]

void InvMinimumNorm::setMethod ( QString method )

Set minimum norm algorithm method ("MNE" | "dSPM" | "sLORETA" | "eLORETA")

Parameters

[in] method Use minimum norm, dSPM, sLORETA, or eLORETA.

Definition at line 292 of file inv_minimum_norm.cpp.

◆ setRegularization()

void InvMinimumNorm::setRegularization ( float lambda )

Set regularization factor

Parameters

[in] lambda The regularization factor.

Definition at line 341 of file inv_minimum_norm.cpp.

The documentation for this class was generated from the following files:

src/libraries/inv/minimum_norm/inv_minimum_norm.h
src/libraries/inv/minimum_norm/inv_minimum_norm.cpp
