UTILSLIB::AnnotateAmplitudeParams Struct Reference

Parameters for amplitude-based annotation. More...

#include <annotate_artifact.h>

Public Attributes
std::optional< double >	peak
std::optional< double >	flat
double	dBadPercent = 5.0
double	dMinDuration = 0.005

Detailed Description

Parameters for amplitude-based annotation.

Definition at line 98 of file annotate_artifact.h.

Member Data Documentation

dBadPercent

double UTILSLIB::AnnotateAmplitudeParams::dBadPercent = 5.0

A channel above or below a threshold for at least this percentage of the recording is returned as bad.

Definition at line 102 of file annotate_artifact.h.

dMinDuration

double UTILSLIB::AnnotateAmplitudeParams::dMinDuration = 0.005

Runs of supra- or sub-threshold differences shorter than this (seconds) are ignored.

Definition at line 103 of file annotate_artifact.h.

flat

std::optional<double> UTILSLIB::AnnotateAmplitudeParams::flat

Annotate where consecutive samples differ by at most this much (mne's flat); unset = off.

Definition at line 101 of file annotate_artifact.h.

peak

std::optional<double> UTILSLIB::AnnotateAmplitudeParams::peak

Annotate where consecutive samples differ by at least this much (mne's peak); unset = off.

Definition at line 100 of file annotate_artifact.h.

---

The documentation for this struct was generated from the following file:

• src/libraries/dsp/annotate_artifact.h
