This page walks through the intracranial multimodal workflow added in mne-cpp v2.3.0: loading an MRI volume, a FreeSurfer cortical surface and an intracranial electrode set (sEEG depths + ECoG grids) into a single 3-D scene, then driving the Layers, Pick and Overlay docks to inspect contact-by-contact data on top of the anatomy.

For the architectural overview of mne_inspect, command-line flags, and the underlying renderables, see MNE Inspect. For the coregistration helper used to bring digitisation into MRI space, see MNE Align.

Overview

The multimodal workflow targets intracranial users (sEEG, ECoG, DBS) who need to look at electrode positions, the MRI they were planned from, and the cortical surface they sit on in the same scene, and to see recorded data and source estimates rendered in registration with that anatomy. The same MultimodalScene controller backs mne_align and the cortical workflow in mne_analyze, so layer / pick / overlay behaviour is consistent across the apps.

Multimodal scene overview

Prerequisites

Before you start, make sure you have:

  • A FreeSurfer subject directory ($SUBJECTS_DIR/<subject>/) with at least mri/T1.mgz (or aparc+aseg.mgz) and surf/lh.inflated + surf/rh.inflated.
  • An MRI volume in MGZ or NIfTI (*.mgz, *.nii, *.nii.gz) — usually the same T1.mgz the subject was reconstructed from.
  • Electrode coordinates as one of:
    • a FIFF digitisation file (*.fif) with intracranial points, or
    • a BIDS *_electrodes.tsv plus a matching *_coordsystem.json, or
    • a plain CSV (name,x,y,z,group) in the same coordinate frame as the MRI volume.
  • Optional: a source-estimate file (*-stc.{lh,rh}) and / or a pre-computed per-contact time-series (FIFF or NumPy .npy) to drive the Overlay dock.
tip

If your electrode coordinates are in subject-RAS (FreeSurfer) but the volume you loaded is in scanner-RAS, the converter mna_bids_converter can resample them into the MRI frame before you load them here.

Step-by-step walkthrough

1. Launch mne_inspect

# Linux / macOS
./bin/mne_inspect

# Windows
bin\mne_inspect.exe

The main window opens with an empty MultimodalScene in the centre, the Layers dock on the left, and the Pick / Overlay docks stacked on the right. The scene is empty until you load data through the File menu.

2. File → Load MRI…

File ▸ Load MRI… accepts *.mgz, *.nii and *.nii.gz. The volume is registered with the scene as three orthogonal slices (axial, coronal, sagittal) — one SceneLayer of kind MriSlice per slice, all sharing the same volume payload. The slice planes are placed at the volume centre on first load; you can drag them with the middle mouse button or scrub them from the Layers dock.

Load MRI dialog

3. File → Load Surface…

File ▸ Load Surface… opens the FreeSurfer subject browser. Pick a subject directory, then tick the surfaces you want (typically lh.inflated + rh.inflated, or lh.pial + rh.pial). Each surface is added as a SceneLayer of kind BrainSurface and rendered with the default cortical colormap.

note

The subject browser remembers the last $SUBJECTS_DIR per workspace. If you supplied --subjectPath on the command line it pre-selects that subject.

4. File → Load Electrodes…

File ▸ Load Electrodes… accepts three input shapes:

InputNotes
FIFFUses the intracranial points in ISOTRAK. Groups are inferred from contact name prefixes.
BIDS *_electrodes.tsvThe companion *_coordsystem.json selects the source coordinate frame.
CSV (name,x,y,z[,group])Coordinates are assumed to be in the frame of the currently loaded MRI.

The loader produces one ElectrodeArray per group, classified as Depth (sEEG), Strip, or Grid (ECoG) based on the contact layout. Each array becomes a SceneLayer of kind Electrode and the layout type drives the default geometry (cylindrical depths, planar grids).

Electrode loader

5. Toggle modalities in the Layers dock

The Layers dock lists every registered SceneLayer grouped by modality. For each row you can:

  • toggle visibility (eye icon),
  • change opacity (slider),
  • re-order within a modality (drag handle, sets drawOrder),
  • right-click ▸ Remove to evict the payload from the scene.

The renderer rebuilds its draw list on every layersChanged signal, so changes are reflected immediately without re-loading.

6. Inspect with the Pick dock

Click on any visible element in the scene. The ray picker returns a PickResult and the Pick dock displays the readout for whatever modality was hit. The contact / vertex / voxel is highlighted in the scene until the next pick.

Pick dock

7. Drive the Overlay dock

The Overlay dock binds a data source to a layer kind through a colormap and a shared time cursor:

Data sourceDrivesTypical use
Per-contact time series (FIFF / NPY)Electrode layersColour sEEG / ECoG contacts by iEEG amplitude, HFO rate, …
Source estimate (*-stc.{lh,rh})BrainSurface layersColour cortex by dSPM / sLORETA / MNE activation.
Static per-contact columnElectrode layersColour by a clinically annotated value (e.g. SOZ score).

Pick a colormap (viridis, RdBu_r, turbo, …), set min / max (or let the dock auto-fit), and scrub the time slider. The time index is the scene-wide timeSampleChanged signal, so contact colours, cortical overlay and slice annotations advance together.

8. Cross-modality jump

Clicking a cortical vertex while an MRI volume is loaded does two things:

  1. The Pick dock fills in the vertex readout (as in step 6).
  2. The three MRI slice planes reposition so that the hit point lies at their intersection — i.e. the orthogonal slices jump to the voxel under the cortical vertex you clicked.

The same dispatch works in the other direction: picking a voxel on a slice highlights the nearest cortical vertex (within a configurable search radius) and the nearest electrode contact.

Layer model

The scene draws layers in modality order; opaque geometry (cortex, BEM, MRI slices) is rendered before translucent overlays. The available SceneLayerKind values are:

SceneLayerKindWhat it shows
BrainSurfaceCortical / BEM surface (one layer per hemisphere or compartment).
MriSliceOne orthogonal MRI slice (axial / coronal / sagittal).
SensorMEG / EEG sensor positions.
HelmetMEG helmet shell.
ElectrodesEEG depth, ECoG strip or ECoG grid ElectrodeArray.
DipoleDipole renderable.
SourceOverlaySource-estimate activation overlay attached to a BrainSurface.
NetworkConnectivity network graph.
CustomHost-app-specific renderable (plugins, prototypes).

Each layer carries an opaque, type-erased payload owned by the producing plugin; the scene only needs the kind, the id, and the visibility / opacity flags to drive the draw list.

Pick model

A single PickResult describes every hit, regardless of modality. The Pick dock surfaces the fields relevant to the layer kind that was hit:

Pick targetReadout fields
Cortical vertexsurfaceKey, vertexIndex, hitPoint, regionName / regionId (from FsAnnotation), current overlay value.
MRI voxelhitPoint in MRI RAS, voxel index, voxel intensity.
sEEG / ECoG contactContact name, group label, layout kind (Depth / Strip / Grid), hitPoint, current time-series value.
SensorSensor name, channel index, hitPoint.
DipoledipoleIndex, hitPoint, current amplitude.

PickResult::displayLabel() is the same string the dock uses for its header line, so log dumps and dock headers always agree.

Overlay model

An overlay is the cross-product of three things:

overlay = data source × colormap × time cursor
  • Data source — anything that exposes a value (or a per-element vector of values) per scene element, sampled at the current time index. Examples: an STC for cortical vertices, a RowMatrixXf for electrode contacts, a static column for a clinical score.
  • Colormap — a named LUT (viridis, turbo, RdBu_r, …) plus a min / max pair (auto-fit or user-set).
  • Time cursor — the scene-wide sample index. Changing it emits timeSampleChanged; every bound overlay re-samples and the renderer refreshes once.

This means a single time cursor scrubs cortical activation, electrode colours and any slice annotations in lock-step.

Troubleshooting

Electrodes are not where you expect them. The most common cause is a coordinate-frame mismatch (BIDS subject-RAS vs MRI scanner-RAS vs head). Check the companion *_coordsystem.json for BIDS inputs, or verify the FIFF dig block is in head coordinates. The mna_bids_converter tool can resample contacts into the MRI frame.

Surface and slices do not line up. The cortical surface is in the FreeSurfer subject-RAS frame. If the loaded MRI is in scanner-RAS, either load T1.mgz from the same subject (which is in subject-RAS once FreeSurfer has run) or compute the surface-RAS-to-volume transform with tools-collect-transforms. The orthogonal slice planes honour the volume's own affine; they are not silently re-aligned.

Frame rate drops with many contacts and a dense surface. Use the Layers dock to drop opacity on the surface to ~0.6 so the GPU can early-out occluded contacts, hide the hemisphere you are not currently inspecting, or switch the surface from pial to inflated. As a reference, the v2.3.0 target is ≥ 30 FPS on a 2024-class laptop for a 327 k-triangle cortex + 120 sEEG contacts + 64-contact ECoG grid + 3 MRI slices.

WASM build is slow on first load. The browser file picker streams the MRI volume into memory before the slices are built; large NIfTIs can take several seconds. Subsequent layer toggles are GPU-only and should match the desktop frame rate.

Saving your work

The multimodal scene is a viewer — none of the loaded MRI, surface, electrode or overlay state is persisted automatically when you close the window. To capture the current set of layers, their visibility, the overlay bindings and the time cursor, save the session as an MNA project (File ▸ Save Project…). The MNA file records the paths of the underlying data plus the scene state, so re-opening it restores the layout without re-importing.

See MNA / MNX Project Format for the on-disk format and show_mna for a CLI inspector.

See also

  • MNE Inspect — application overview and command-line flags.
  • MNE Align — coregistration wizard that produces the -trans.fif consumed by this workflow.
  • MNE Analyze — the cortical / vertex workflow that shares the same MultimodalScene primitives.
  • MNA BIDS Converter — resample BIDS electrodes into the MRI frame before loading.
  • MNA / MNX Project Format — on-disk layout for saved sessions.
