fwd_comp_data.h File Reference

Software-gradiometer compensation wrapper that subtracts the reference-channel contribution from the primary forward field. More...

#include "fwd_global.h"
#include "fwd_types.h"
#include <Eigen/Core>

Include dependency graph for fwd_comp_data.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	FWDLIB::FwdCompData
	CTF / 4D software-gradiometer wrapper that re-evaluates the primary field callback on a separate reference-coil set and subtracts the linear combination k·B_ref from the primary field to mirror the compensation already applied to the recorded data. More...

Namespaces
namespace	MNELIB
	Core MNE data structures (source spaces, source estimates, hemispheres).
namespace	FWDLIB
	Forward modelling — BEM solver, spherical models, sensor/coil definitions and the lead-field assembly that links current dipoles to MEG/EEG sensor readings.

Detailed Description

Software-gradiometer compensation wrapper that subtracts the reference-channel contribution from the primary forward field.

SPDX-License-Identifier: BSD-3-Clause Copyright (c) 2017-2026 MNE-CPP Authors

Author

Christoph Dinh chris.nosp@m.toph.nosp@m..dinh.nosp@m.@mne.nosp@m.-cpp..nosp@m.org; Lorenz Esch loren.nosp@m.z.es.nosp@m.ch@tu.nosp@m.-ilm.nosp@m.enau..nosp@m.de; Gabriel Motta gabri.nosp@m.elbe.nosp@m.nmott.nosp@m.a@gm.nosp@m.ail.c.nosp@m.om

Since

0.1.0

Date

March 2017

CTF whole-head and 4D/BTi MEG systems acquire a bank of reference channels located far from the head and form synthetic higher-order gradiometers by subtracting linear combinations of those references from each primary channel. The compensation coefficients k are stored in the FIFF file as a MNECTFCompDataSet. To keep the forward model consistent with the data, the same linear combination must be applied to the predicted field: B_comp = B_primary − k·B_reference.

FwdCompData wraps an underlying field/grad function pair (BEM or sphere), evaluates it once for the primary coils and once for the reference coils, and returns the compensated result. The class mirrors fwdCompDataRec from MNE-C fwd_comp_data.h and preserves the same callback signatures so it can be dropped into the source-space loop without changes upstream.

Definition in file fwd_comp_data.h.
