FIFFLIB::FiffInfo Class Reference

FIFF measurement file information. More...

#include <fiff_info.h>

Public Types
typedef QSharedPointer< FiffInfo >	SPtr
typedef QSharedPointer< const FiffInfo >	ConstSPtr
Public Types inherited from FIFFLIB::FiffInfoBase
typedef QSharedPointer< FiffInfoBase >	SPtr
typedef QSharedPointer< const FiffInfoBase >	ConstSPtr

Public Member Functions
	FiffInfo ()
	FiffInfo (const FiffInfo &p_FiffInfo)
	~FiffInfo ()
void	clear ()
bool	make_compensator (fiff_int_t from, fiff_int_t to, FiffCtfComp &ctf_comp, bool exclude_comp_chs=false) const
qint32	get_current_comp ()
qint32	make_projector (Eigen::MatrixXd &proj) const
qint32	make_projector (Eigen::MatrixXd &proj, const QStringList &p_chNames) const
FiffInfo	pick_info (const Eigen::RowVectorXi &sel=defaultVectorXi) const
void	set_current_comp (fiff_int_t value)
void	writeToStream (FiffStream *p_pStream) const
void	print () const
Public Member Functions inherited from FIFFLIB::FiffInfoBase
	FiffInfoBase ()
	FiffInfoBase (const FiffInfoBase &p_FiffInfoBase)
virtual	~FiffInfoBase ()
void	clear ()
QString	channel_type (qint32 idx) const
bool	isEmpty () const
FiffInfoBase	pick_info (const Eigen::RowVectorXi *sel=Q_NULLPTR) const
Eigen::RowVectorXi	pick_types (const QString meg, bool eeg=false, bool stim=false, const QStringList &include=defaultQStringList, const QStringList &exclude=defaultQStringList) const
Eigen::RowVectorXi	pick_types (bool meg, bool eeg=false, bool stim=false, const QStringList &include=defaultQStringList, const QStringList &exclude=defaultQStringList) const
QStringList	get_channel_types ()

Static Public Member Functions
static QList< FiffChInfo >	set_current_comp (QList< FiffChInfo > &listFiffChInfo, fiff_int_t value)
Static Public Member Functions inherited from FIFFLIB::FiffInfoBase
static Eigen::RowVectorXi	pick_channels (const QStringList &ch_names, const QStringList &include=defaultQStringList, const QStringList &exclude=defaultQStringList)

Public Attributes
FiffId	file_id
fiff_int_t	meas_date [2]
float	sfreq
float	linefreq
float	highpass
float	lowpass
int	proj_id
QString	proj_name
QString	xplotter_layout
QString	experimenter
QString	description
QString	utc_offset
fiff_int_t	gantry_angle
FiffCoordTrans	dev_ctf_t
QList< FiffDigPoint >	dig
FiffCoordTrans	dig_trans
QList< FiffProj >	projs
QList< FiffCtfComp >	comps
QString	acq_pars
QString	acq_stim
Public Attributes inherited from FIFFLIB::FiffInfoBase
QString	filename
QStringList	bads
FiffId	meas_id
fiff_int_t	nchan
QList< FiffChInfo >	chs
QStringList	ch_names
FiffCoordTrans	dev_head_t
FiffCoordTrans	ctf_head_t

Detailed Description

FIFF measurement file information.

Provides fiff measurement file information

Definition at line 84 of file fiff_info.h.

Inheritance diagram for FIFFLIB::FiffInfo:

Member Typedef Documentation

ConstSPtr

typedef QSharedPointer<const FiffInfo> FIFFLIB::FiffInfo::ConstSPtr

Const shared pointer type for FiffInfo.

Definition at line 88 of file fiff_info.h.

SPtr

typedef QSharedPointer<FiffInfo> FIFFLIB::FiffInfo::SPtr

Shared pointer type for FiffInfo.

Definition at line 87 of file fiff_info.h.

Constructor & Destructor Documentation

FiffInfo() [1/2]

FiffInfo::FiffInfo

(

)

Constructors the fiff measurement file information.

Definition at line 61 of file fiff_info.cpp.

FiffInfo() [2/2]

FiffInfo::FiffInfo

(

const FiffInfo &

p_FiffInfo

)

Copy constructor.

Parameters

[in]

p_FiffInfo

FIFF measurement information which should be copied.

Definition at line 76 of file fiff_info.cpp.

~FiffInfo()

FiffInfo::~FiffInfo

(

)

Destroys the fiff measurement file information.

Definition at line 104 of file fiff_info.cpp.

Member Function Documentation

clear()

void FiffInfo::clear

(

)

Initializes FIFF measurement information.

< UTC offset of related meas_date (sHH:MM).

Definition at line 110 of file fiff_info.cpp.

get_current_comp()

qint32 FiffInfo::get_current_comp

(

)

mne_get_current_comp

MNE toolbox root function ### Definition of the mne_get_current_comp function

Get the current compensation in effect in the data

Returns

the current compensation.

Definition at line 137 of file fiff_info.cpp.

make_compensator()

bool FiffInfo::make_compensator	(	fiff_int_t	from,
		fiff_int_t	to,
		FiffCtfComp &	ctf_comp,
		bool	exclude_comp_chs = false
	)		const

mne_make_compensator

MNE toolbox root function ### Definition of the mne_make_compensator function

Create a compensation matrix to bring the data from one compensation state to another

Parameters

[in]	from	compensation in the input data.
[in]	to	desired compensation in the output.
[out]	ctf_comp	Compensation Matrix.
[in]	exclude_comp_chs	exclude compensation channels from the output (optional).

Returns

true if succeeded, false otherwise.

Definition at line 159 of file fiff_info.cpp.

make_projector() [1/2]

qint32 FIFFLIB::FiffInfo::make_projector ( Eigen::MatrixXd &  proj ) const

inline

mne_make_projector_info

MNE toolbox root function ### Definition of the mne_make_projector_info function

Make a SSP operator using the meas info

Parameters

[out]

proj

The projection operator to apply to the data.

Returns

nproj - How many items in the projector.

Definition at line 278 of file fiff_info.h.

make_projector() [2/2]

qint32 FIFFLIB::FiffInfo::make_projector ( Eigen::MatrixXd &  proj, const QStringList &  p_chNames  ) const

inline

mne_make_projector_info

MNE toolbox root function ### Definition of the mne_make_projector_info function

Make a SSP operator using the meas info

Parameters

[out]	proj	The projection operator to apply to the data.
[in]	p_chNames	List of channels to include in the projection matrix.

Returns

nproj - How many items in the projector.

Definition at line 285 of file fiff_info.h.

pick_info()

FiffInfo FiffInfo::pick_info

(

const Eigen::RowVectorXi &

sel = defaultVectorXi

)

const

fiff_pick_info

MNE toolbox root function

Pick desired channels from measurement info

Parameters

[in]

sel

List of channels to select.

Returns

Info modified according to sel.

Definition at line 310 of file fiff_info.cpp.

print()

void FiffInfo::print

(

)

const

Prints class contents.

Definition at line 484 of file fiff_info.cpp.

set_current_comp() [1/2]

void FIFFLIB::FiffInfo::set_current_comp ( fiff_int_t  value )

inline

Set the current compensation value in the channel info structures

Parameters

[in]

value

compensation value.

Definition at line 292 of file fiff_info.h.

set_current_comp() [2/2]

QList< FiffChInfo > FiffInfo::set_current_comp ( QList< FiffChInfo > &  listFiffChInfo, fiff_int_t  value  )

static

mne_set_current_comp

MNE toolbox root function ### Definition of the mne_set_current_comp function

Consider taking the member function of set_current_comp(fiff_int_t value), when compensation should be applied to the channels of FiffInfo

Set the current compensation value in the channel info structures

Parameters

[in]	chs	fiff channel info list.
[in]	value	compensation value.

Returns

the current compensation.

Definition at line 334 of file fiff_info.cpp.

writeToStream()

void FiffInfo::writeToStream

(

FiffStream *

p_pStream

)

const

Writes the fiff information to a FIF stream.

Parameters

[in]

p_pStream

The stream to write to.

Definition at line 357 of file fiff_info.cpp.

Member Data Documentation

acq_pars

QString FIFFLIB::FiffInfo::acq_pars

Acquisition information ToDo...

Definition at line 270 of file fiff_info.h.

acq_stim

QString FIFFLIB::FiffInfo::acq_stim

Acquisition information ToDo...

Definition at line 271 of file fiff_info.h.

comps

QList<FiffCtfComp> FIFFLIB::FiffInfo::comps

List of available CTF software compensators.

Definition at line 269 of file fiff_info.h.

description

QString FIFFLIB::FiffInfo::description

(Textual) Description of an object.

Definition at line 262 of file fiff_info.h.

dev_ctf_t

FiffCoordTrans FIFFLIB::FiffInfo::dev_ctf_t

Coordinate transformation ToDo...

Definition at line 265 of file fiff_info.h.

dig

QList<FiffDigPoint> FIFFLIB::FiffInfo::dig

List of all digitization point descriptors.

Definition at line 266 of file fiff_info.h.

dig_trans

FiffCoordTrans FIFFLIB::FiffInfo::dig_trans

Coordinate transformation ToDo...

Definition at line 267 of file fiff_info.h.

experimenter

QString FIFFLIB::FiffInfo::experimenter

Experimenter name.

Definition at line 261 of file fiff_info.h.

file_id

FiffId FIFFLIB::FiffInfo::file_id

File ID.

Definition at line 252 of file fiff_info.h.

gantry_angle

fiff_int_t FIFFLIB::FiffInfo::gantry_angle

Tilt angle of the dewar in degrees.

Definition at line 264 of file fiff_info.h.

highpass

float FIFFLIB::FiffInfo::highpass

Highpass frequency.

Definition at line 256 of file fiff_info.h.

linefreq

float FIFFLIB::FiffInfo::linefreq

Power line frequency.

Definition at line 255 of file fiff_info.h.

lowpass

float FIFFLIB::FiffInfo::lowpass

Lowpass frequency.

Definition at line 257 of file fiff_info.h.

meas_date

fiff_int_t FIFFLIB::FiffInfo::meas_date[2]

Measurement date. TODO: use fiffTime instead to be MNE-C consistent

Definition at line 253 of file fiff_info.h.

proj_id

int FIFFLIB::FiffInfo::proj_id

Project ID.

Definition at line 258 of file fiff_info.h.

proj_name

QString FIFFLIB::FiffInfo::proj_name

Project name.

Definition at line 259 of file fiff_info.h.

projs

QList<FiffProj> FIFFLIB::FiffInfo::projs

List of available SSP projectors.

Definition at line 268 of file fiff_info.h.

sfreq

float FIFFLIB::FiffInfo::sfreq

Sample frequency.

Definition at line 254 of file fiff_info.h.

utc_offset

QString FIFFLIB::FiffInfo::utc_offset

UTC offset of related meas_date (sHH:MM).

Definition at line 263 of file fiff_info.h.

xplotter_layout

QString FIFFLIB::FiffInfo::xplotter_layout

xplotter layout tag.

Definition at line 260 of file fiff_info.h.

---

The documentation for this class was generated from the following files:

• src/libraries/fiff/fiff_info.h
• src/libraries/fiff/fiff_info.cpp
