FWDLIB::FwdEegSphereLayer Class Reference

Single concentric sphere layer with conductivity ratio for the EEG forward model. More...

#include <fwd_eeg_sphere_layer.h>

Public Member Functions
	FwdEegSphereLayer ()
	~FwdEegSphereLayer ()

Static Public Member Functions
static bool	comp_layers (const FwdEegSphereLayer &v1, const FwdEegSphereLayer &v2)

Public Attributes
float	rad
float	rel_rad
float	sigma

Detailed Description

Single concentric sphere layer with conductivity ratio for the EEG forward model.

Implements FwdEegSphereLayer (Replaces *fwdEegSphereLayer,fwdEegSphereLayerRec struct of MNE-C fwd_types.h).

Definition at line 71 of file fwd_eeg_sphere_layer.h.

Constructor & Destructor Documentation

FwdEegSphereLayer()

FwdEegSphereLayer::FwdEegSphereLayer

(

)

Constructs the Electric Current Dipole

Definition at line 55 of file fwd_eeg_sphere_layer.cpp.

~FwdEegSphereLayer()

FwdEegSphereLayer::~FwdEegSphereLayer

(

)

Destroys the Forward EEG Sphere Layer description

Definition at line 73 of file fwd_eeg_sphere_layer.cpp.

Member Function Documentation

comp_layers()

bool FWDLIB::FwdEegSphereLayer::comp_layers ( const FwdEegSphereLayer & v1, const FwdEegSphereLayer & v2 )

inlinestatic

Compare two sphere layers by radius for sorting.

Parameters

[in]	v1	First layer.
[in]	v2	Second layer.

Returns

True if v1.rad < v2.rad.

Definition at line 96 of file fwd_eeg_sphere_layer.h.

Member Data Documentation

rad

float FWDLIB::FwdEegSphereLayer::rad

The actual rads.

Definition at line 102 of file fwd_eeg_sphere_layer.h.

rel_rad

float FWDLIB::FwdEegSphereLayer::rel_rad

Relative rads.

Definition at line 103 of file fwd_eeg_sphere_layer.h.

sigma

float FWDLIB::FwdEegSphereLayer::sigma

Conductivity.

Definition at line 104 of file fwd_eeg_sphere_layer.h.

---

The documentation for this class was generated from the following files:

• src/libraries/fwd/fwd_eeg_sphere_layer.h
• src/libraries/fwd/fwd_eeg_sphere_layer.cpp
