INVLIB::InvGuessData Class Reference

Precomputed guess point grid with forward fields for initial dipole position candidates. More...

#include <inv_guess_data.h>

Public Types
typedef QSharedPointer< InvGuessData >	SPtr
typedef QSharedPointer< const InvGuessData >	ConstSPtr

Public Member Functions
	InvGuessData ()
	InvGuessData (const InvGuessData &)=delete
InvGuessData &	operator= (const InvGuessData &)=delete
	InvGuessData (const QString &guessname, const QString &guess_surfname, float mindist, float exclude, float grid, InvDipoleFitData *f)
	InvGuessData (const QString &guessname, const QString &guess_surfname, float mindist, float exclude, float grid, InvDipoleFitData *f, char *guess_save_name)
	~InvGuessData ()
bool	compute_guess_fields (InvDipoleFitData *f)

Public Attributes
Eigen::Matrix< float, Eigen::Dynamic, 3, Eigen::RowMajor >	rr
std::vector< InvDipoleForward::UPtr >	guess_fwd
int	nguess

Detailed Description

Precomputed guess point grid with forward fields for initial dipole position candidates.

Implements InvGuessData (Replaces *guessData,guessDataRec struct of MNE-C fit_types.h).

Definition at line 80 of file inv_guess_data.h.

Member Typedef Documentation

ConstSPtr

typedef QSharedPointer<const InvGuessData> INVLIB::InvGuessData::ConstSPtr

Const shared pointer type for InvGuessData.

Definition at line 84 of file inv_guess_data.h.

SPtr

typedef QSharedPointer<InvGuessData> INVLIB::InvGuessData::SPtr

Shared pointer type for InvGuessData.

Definition at line 83 of file inv_guess_data.h.

Constructor & Destructor Documentation

InvGuessData() [1/4]

InvGuessData::InvGuessData

(

)

Constructs the Guess Data Refactored: new_guess_data (dipole_fit_setup.c)

Definition at line 170 of file inv_guess_data.cpp.

InvGuessData() [2/4]

INVLIB::InvGuessData::InvGuessData ( const InvGuessData & )

delete

Deleted — non-copyable due to unique_ptr members.

InvGuessData() [3/4]

InvGuessData::InvGuessData	(	const QString &	guessname,
		const QString &	guess_surfname,
		float	mindist,
		float	exclude,
		float	grid,
		InvDipoleFitData *	f )

Constructs the Guess Data from given Data Refactored: make_guess_data (setup.c)

Parameters

[in]

guessname.

Definition at line 183 of file inv_guess_data.cpp.

InvGuessData() [4/4]

InvGuessData::InvGuessData	(	const QString &	guessname,
		const QString &	guess_surfname,
		float	mindist,
		float	exclude,
		float	grid,
		InvDipoleFitData *	f,
		char *	guess_save_name )

Constructs the Guess Data from given Data Refactored: make_guess_data (dipole_fit_setup.c)

Parameters

[in]

guessname.

Definition at line 282 of file inv_guess_data.cpp.

~InvGuessData()

InvGuessData::~InvGuessData ( )

default

Destroys the Guess Data description Refactored: free_guess_data (dipole_fit_setup.c)

Member Function Documentation

compute_guess_fields()

bool InvGuessData::compute_guess_fields

(

InvDipoleFitData *

f

)

Once the guess locations have been set up we can compute the fields Refactored: compute_guess_fields (dipole_fit_setup.c)

Parameters

[in]

f

Dipole Fit Data to the Compute Guess Fields.

Returns

true when successful.

Definition at line 380 of file inv_guess_data.cpp.

operator=()

InvGuessData & INVLIB::InvGuessData::operator= ( const InvGuessData & )

delete

Member Data Documentation

guess_fwd

std::vector<InvDipoleForward::UPtr> INVLIB::InvGuessData::guess_fwd

Forward solutions for the guesses.

Definition at line 137 of file inv_guess_data.h.

nguess

int INVLIB::InvGuessData::nguess

How many sources.

Definition at line 138 of file inv_guess_data.h.

rr

Eigen::Matrix<float, Eigen::Dynamic, 3, Eigen::RowMajor> INVLIB::InvGuessData::rr

Guess dipole locations (nguess x 3, row-major).

Definition at line 136 of file inv_guess_data.h.

---

The documentation for this class was generated from the following files:

• src/libraries/inv/dipole_fit/inv_guess_data.h
• src/libraries/inv/dipole_fit/inv_guess_data.cpp
