LSLLIB::stream_info Class Reference

Describes a particular stream on the network. More...

#include <lsl_stream_info.h>

Public Member Functions
	stream_info ()
	stream_info (const std::string &name, const std::string &type, int channel_count=0, double nominal_srate=0.0, ChannelFormat channel_format=ChannelFormat::Float32, const std::string &source_id="")
	stream_info (const stream_info &other)=default
stream_info &	operator= (const stream_info &other)=default
Core Stream Properties
std::string	name () const noexcept
	Name of the stream.
std::string	type () const noexcept
	Content type of the stream.
int	channel_count () const noexcept
	Number of channels.
double	nominal_srate () const noexcept
	Nominal sampling rate in Hz. 0.0 means irregular.
ChannelFormat	channel_format () const noexcept
	Data format of a channel.
std::string	source_id () const noexcept
	Unique source identifier.
Network / Identity Properties
std::string	uid () const noexcept
	A unique identifier for this particular stream instance (auto-generated).
std::string	hostname () const noexcept
	Hostname of the machine from which the stream originates.
Network Endpoint (internal, set during discovery)
int	data_port () const noexcept
	TCP data port of the outlet.
std::string	data_host () const noexcept
	Host address of the outlet (IP, set from UDP sender address during discovery).
void	set_data_port (int port)
	Set the TCP data port (used internally during discovery / outlet creation).
void	set_data_host (const std::string &host)
	Set the data host (used internally during discovery).

Serialization (used for network discovery)
std::string	to_string () const
	Serialize stream_info into a string for network transport.
static stream_info	from_string (const std::string &data)
	Deserialize a stream_info from a network transport string.

Detailed Description

Describes a particular stream on the network.

The stream_info class holds the declaration of a data stream. It describes the core properties of a stream such as its name, content type, channel count and sampling rate, as well as optional meta-data and network endpoint information.

This class is API-compatible with the liblsl stream_info to serve as a drop-in replacement.

Definition at line 82 of file lsl_stream_info.h.

Constructor & Destructor Documentation

stream_info() [1/3]

stream_info::stream_info

(

)

Default constructor. Creates an empty / invalid stream_info.

Definition at line 64 of file lsl_stream_info.cpp.

stream_info() [2/3]

stream_info::stream_info	(	const std::string &	name,
		const std::string &	type,
		int	channel_count = 0,
		double	nominal_srate = 0.0,
		ChannelFormat	channel_format = ChannelFormat::Float32,
		const std::string &	source_id = "" )

Construct a new stream_info object.

Parameters

[in]	name	Name of the stream (e.g. "EEG" or "MoCap").
[in]	type	Content type of the stream (e.g. "EEG", "Markers").
[in]	channel_count	Number of channels in the stream.
[in]	nominal_srate	The nominal sampling rate (Hz). Use 0.0 for irregular streams.
[in]	channel_format	Data format of a channel (default: cf_float32).
[in]	source_id	A unique identifier for the device or source that generates the stream.

Definition at line 80 of file lsl_stream_info.cpp.

stream_info() [3/3]

LSLLIB::stream_info::stream_info ( const stream_info & other )

default

Copy constructor.

Member Function Documentation

channel_count()

int stream_info::channel_count ( ) const

nodiscardnoexcept

Number of channels.

Definition at line 115 of file lsl_stream_info.cpp.

channel_format()

ChannelFormat stream_info::channel_format ( ) const

nodiscardnoexcept

Data format of a channel.

Definition at line 129 of file lsl_stream_info.cpp.

data_host()

std::string stream_info::data_host ( ) const

nodiscardnoexcept

Host address of the outlet (IP, set from UDP sender address during discovery).

Definition at line 164 of file lsl_stream_info.cpp.

data_port()

int stream_info::data_port ( ) const

nodiscardnoexcept

TCP data port of the outlet.

Definition at line 157 of file lsl_stream_info.cpp.

from_string()

stream_info stream_info::from_string ( const std::string & data )

staticnodiscard

Deserialize a stream_info from a network transport string.

Definition at line 205 of file lsl_stream_info.cpp.

hostname()

std::string stream_info::hostname ( ) const

nodiscardnoexcept

Hostname of the machine from which the stream originates.

Definition at line 150 of file lsl_stream_info.cpp.

name()

std::string stream_info::name ( ) const

nodiscardnoexcept

Name of the stream.

Definition at line 101 of file lsl_stream_info.cpp.

nominal_srate()

double stream_info::nominal_srate ( ) const

nodiscardnoexcept

Nominal sampling rate in Hz. 0.0 means irregular.

Definition at line 122 of file lsl_stream_info.cpp.

operator=()

stream_info & LSLLIB::stream_info::operator= ( const stream_info & other )

default

Copy assignment operator.

set_data_host()

void stream_info::set_data_host

(

const std::string &

host

)

Set the data host (used internally during discovery).

Definition at line 178 of file lsl_stream_info.cpp.

set_data_port()

void stream_info::set_data_port

(

int

port

)

Set the TCP data port (used internally during discovery / outlet creation).

Definition at line 171 of file lsl_stream_info.cpp.

source_id()

std::string stream_info::source_id ( ) const

nodiscardnoexcept

Unique source identifier.

Definition at line 136 of file lsl_stream_info.cpp.

to_string()

std::string stream_info::to_string ( ) const

nodiscard

Serialize stream_info into a string for network transport.

Definition at line 185 of file lsl_stream_info.cpp.

type()

std::string stream_info::type ( ) const

nodiscardnoexcept

Content type of the stream.

Definition at line 108 of file lsl_stream_info.cpp.

uid()

std::string stream_info::uid ( ) const

nodiscardnoexcept

A unique identifier for this particular stream instance (auto-generated).

Definition at line 143 of file lsl_stream_info.cpp.

---

The documentation for this class was generated from the following files:

• src/libraries/lsl/lsl_stream_info.h
• src/libraries/lsl/lsl_stream_info.cpp
