SSP parameters of compute_proj_ecg / compute_proj_eog; ecg() and eog() give the MNE-Python defaults. More...

#include <artifact_detect.h>

Static Public Member Functions
static ArtifactDetectProjParams	ecg ()
static ArtifactDetectProjParams	eog ()

Public Attributes
double	dTmin = -0.2
double	dTmax = 0.4
int	nGrad = 2
int	nMag = 2
int	nEeg = 2
double	dFilterLow = 1.0
double	dFilterHigh = 35.0
double	dGradReject = 2000e-13
double	dMagReject = 3000e-15
double	dEegReject = 50e-6
double	dEogReject = 250e-6

Detailed Description

SSP parameters of compute_proj_ecg / compute_proj_eog; ecg() and eog() give the MNE-Python defaults.

Definition at line 85 of file artifact_detect.h.

Member Function Documentation

◆ ecg()

ArtifactDetectProjParams UTILSLIB::ArtifactDetectProjParams::ecg ( )

inlinestatic

Returns: The compute_proj_ecg defaults.

Definition at line 100 of file artifact_detect.h.

◆ eog()

ArtifactDetectProjParams UTILSLIB::ArtifactDetectProjParams::eog ( )

inlinestatic

Returns: The compute_proj_eog defaults (tmax 0.2, eeg 500 µV, no EOG rejection).

Definition at line 106 of file artifact_detect.h.

Member Data Documentation

◆ dEegReject

double UTILSLIB::ArtifactDetectProjParams::dEegReject = 50e-6

Peak-to-peak rejection in V; 0 = off.

Definition at line 96 of file artifact_detect.h.

◆ dEogReject

double UTILSLIB::ArtifactDetectProjParams::dEogReject = 250e-6

Peak-to-peak rejection in V; 0 = off.

Definition at line 97 of file artifact_detect.h.

◆ dFilterHigh

double UTILSLIB::ArtifactDetectProjParams::dFilterHigh = 35.0

Band-pass upper edge of the data in Hz (h_freq).

Definition at line 93 of file artifact_detect.h.

◆ dFilterLow

double UTILSLIB::ArtifactDetectProjParams::dFilterLow = 1.0

Band-pass lower edge of the data in Hz (l_freq).

Definition at line 92 of file artifact_detect.h.

◆ dGradReject

double UTILSLIB::ArtifactDetectProjParams::dGradReject = 2000e-13

Peak-to-peak rejection in T/m; 0 = off.

Definition at line 94 of file artifact_detect.h.

◆ dMagReject

double UTILSLIB::ArtifactDetectProjParams::dMagReject = 3000e-15

Peak-to-peak rejection in T; 0 = off.

Definition at line 95 of file artifact_detect.h.

◆ dTmax

double UTILSLIB::ArtifactDetectProjParams::dTmax = 0.4

Epoch end relative to the event in seconds.

Definition at line 88 of file artifact_detect.h.

◆ dTmin

double UTILSLIB::ArtifactDetectProjParams::dTmin = -0.2

Epoch start relative to the event in seconds.

Definition at line 87 of file artifact_detect.h.

◆ nEeg

int UTILSLIB::ArtifactDetectProjParams::nEeg = 2

Number of EEG vectors.

Definition at line 91 of file artifact_detect.h.

◆ nGrad

int UTILSLIB::ArtifactDetectProjParams::nGrad = 2

Number of gradiometer vectors.

Definition at line 89 of file artifact_detect.h.

◆ nMag

int UTILSLIB::ArtifactDetectProjParams::nMag = 2

Number of magnetometer vectors.

Definition at line 90 of file artifact_detect.h.

The documentation for this struct was generated from the following file:

src/libraries/dsp/artifact_detect.h
