Visualizes ECD data. More...

#include <sourceestimateview.h>

Public Types
typedef QSharedPointer< SourceEstimateView >	SPtr

typedef QSharedPointer< const SourceEstimateView >	ConstSPtr

Public Types inherited from DISP3DLIB::AbstractView
typedef QSharedPointer< AbstractView >	SPtr

typedef QSharedPointer< const AbstractView >	ConstSPtr

Public Member Functions
	SourceEstimateView (QWidget *parent=0, Qt::WindowFlags f=Qt::Widget)

	~SourceEstimateView ()

MneDataTreeItem *	addData (const QString &sSubject, const QString &sMeasurementSetName, const MNELIB::MNESourceEstimate &tSourceEstimate, const MNELIB::MNEForwardSolution &tForwardSolution, const FSLIB::SurfaceSet &tSurfSet, const FSLIB::AnnotationSet &tAnnotSet)

Public Member Functions inherited from DISP3DLIB::AbstractView
	AbstractView (QWidget *parent=0, Qt::WindowFlags f=Qt::Widget)

	~AbstractView ()

QSharedPointer< DISP3DLIB::View3D >	getView ()

QSharedPointer< DISPLIB::Control3DView >	getControlView ()

QSharedPointer< DISP3DLIB::Data3DTreeModel >	getTreeModel ()

QPointer< DISPLIB::QuickControlView >	getQuickControl ()

void	setQuickControlWidgets (const QList< QWidget * > &lControlWidgets)

Additional Inherited Members
Protected Member Functions inherited from DISP3DLIB::AbstractView
void	createGUI ()

Protected Attributes inherited from DISP3DLIB::AbstractView
QSharedPointer< DISP3DLIB::View3D >	m_p3DView

QSharedPointer< DISP3DLIB::Data3DTreeModel >	m_pData3DModel

QSharedPointer< DISPLIB::Control3DView >	m_pControl3DView

QPointer< DISPLIB::QuickControlView >	m_pQuickControlView

Detailed Description

Visualizes ECD data.

Adapter which provides visualization for MNE source estimate data and a control widget.

Definition at line 85 of file sourceestimateview.h.

Inheritance diagram for DISP3DLIB::SourceEstimateView:

Member Typedef Documentation

◆ ConstSPtr

typedef QSharedPointer<const SourceEstimateView> DISP3DLIB::SourceEstimateView::ConstSPtr

Const shared pointer type for SourceEstimateView class.

Definition at line 91 of file sourceestimateview.h.

◆ SPtr

typedef QSharedPointer<SourceEstimateView> DISP3DLIB::SourceEstimateView::SPtr

Shared pointer type for SourceEstimateView class.

Definition at line 90 of file sourceestimateview.h.

Constructor & Destructor Documentation

◆ SourceEstimateView()

SourceEstimateView::SourceEstimateView	(	QWidget *	parent = `0`,
		Qt::WindowFlags	f = `Qt::Widget`
	)

explicit

Default constructor

Definition at line 66 of file sourceestimateview.cpp.

◆ ~SourceEstimateView()

SourceEstimateView::~SourceEstimateView ( )

Default destructor

Definition at line 74 of file sourceestimateview.cpp.

Member Function Documentation

◆ addData()

MneDataTreeItem * SourceEstimateView::addData	(	const QString &	sSubject,
		const QString &	sMeasurementSetName,
		const MNELIB::MNESourceEstimate &	tSourceEstimate,
		const MNELIB::MNEForwardSolution &	tForwardSolution,
		const FSLIB::SurfaceSet &	tSurfSet,
		const FSLIB::AnnotationSet &	tAnnotSet
	)

Add data to the view

Parameters

[in]	sSubject	The name of the subject.
[in]	sMeasurementSetName	The name of the measurement set to which the data is to be added. If it does not exist yet, it will be created.
[in]	tSourceEstimate	The MNESourceEstimate.
[in]	tForwardSolution	The MNEForwardSolution.
[in]	tSurfSet	The surface set holding the left and right hemisphere surfaces.
[in]	tAnnotSet	The annotation set holding the left and right hemisphere annotations.

Returns: Returns a pointer to the added tree item. Default is a NULL pointer if no item was added.

Definition at line 80 of file sourceestimateview.cpp.

The documentation for this class was generated from the following files:

src/libraries/disp3D/viewers/sourceestimateview.h
src/libraries/disp3D/viewers/sourceestimateview.cpp
