Qt RHI-based 3-D renderer managing scene objects, lighting, camera, and render pipeline for brain visualization. More...

#include <brainrenderer.h>

Classes
struct	SceneData
	Per-draw scene uniforms: camera matrices, light and overlay mode. More...
struct	Impl

Public Types
using	ShaderMode = DISP3DLIB::ShaderMode

Public Member Functions
	BrainRenderer ()
	~BrainRenderer ()
void	initialize (QRhi rhi, QRhiRenderPassDescriptor rp, int sampleCount)
void	ensureRenderTargets (QRhi rhi, QRhiTexture colorTex, const QSize &pixelSize)
QRhiRenderTarget *	rtClear () const
QRhiRenderTarget *	rtPreserve () const
void	newFrame ()
int	cachedMeshCount () const
void	beginFrame (QRhiCommandBuffer cb, QRhiResourceUpdateBatch updates=nullptr)
void	beginPreservingPass (QRhiCommandBuffer cb, QRhiResourceUpdateBatch updates=nullptr)
int	prepareSurfaceDraw (QRhiResourceUpdateBatch u, const SceneData &data, BrainSurface surface)
void	issueSurfaceDraw (QRhiCommandBuffer cb, BrainSurface surface, ShaderMode mode, int uniformOffset)
int	prepareDipoleDraw (QRhiResourceUpdateBatch u, const SceneData &data, DipoleObject dipoles)
void	issueDipoleDraw (QRhiCommandBuffer cb, DipoleObject dipoles, int uniformOffset)
int	prepareNetworkDraw (QRhiResourceUpdateBatch u, const SceneData &data, NetworkObject network)
void	issueNetworkDraw (QRhiCommandBuffer cb, NetworkObject network, int uniformOffset)
int	preparePolylineDraw (QRhiResourceUpdateBatch u, const SceneData &data, PolylineObject polyline)
void	issuePolylineDraw (QRhiCommandBuffer cb, PolylineObject polyline, int uniformOffset)
int	prepareElectrodeDraw (QRhiResourceUpdateBatch u, const SceneData &data, ElectrodeObject electrodes)
void	issueElectrodeDraw (QRhiCommandBuffer cb, ElectrodeObject electrodes, int uniformOffset)
void	prepareVideoOverlay (QRhi rhi, QRhiResourceUpdateBatch u, DISP3DLIB::VideoOverlay *overlay)
int	prepareVideoOverlayDraw (QRhiResourceUpdateBatch u, const SceneData &data, DISP3DLIB::VideoOverlay overlay, BrainSurface *surface)
void	issueVideoOverlayDraw (QRhiCommandBuffer cb, DISP3DLIB::VideoOverlay overlay, BrainSurface *surface, int uniformOffset)
void	prepareSlice (QRhi rhi, QRhiResourceUpdateBatch u, DISP3DLIB::SliceObject *slice, int slotIndex)
int	prepareSliceDraw (QRhiResourceUpdateBatch *u, const SceneData &data, int slotIndex)
void	issueSliceDraw (QRhiCommandBuffer *cb, int slotIndex, int uniformOffset)
void	endPass (QRhiCommandBuffer *cb)

Static Public Attributes
static constexpr ShaderMode	Standard = DISP3DLIB::Standard
static constexpr ShaderMode	Holographic = DISP3DLIB::Holographic
static constexpr ShaderMode	Anatomical = DISP3DLIB::Anatomical
static constexpr ShaderMode	Dipole = DISP3DLIB::Dipole
static constexpr ShaderMode	XRay = DISP3DLIB::XRay
static constexpr ShaderMode	ShowNormals = DISP3DLIB::ShowNormals

Detailed Description

Qt RHI-based 3-D renderer managing scene objects, lighting, camera, and render pipeline for brain visualization.

BrainRenderer handles the low-level RHI rendering logic, managing pipelines, shaders, and draw calls for brain surfaces.

Definition at line 76 of file brainrenderer.h.

Member Typedef Documentation

◆ ShaderMode

using DISP3DLIB::BrainRenderer::ShaderMode = DISP3DLIB::ShaderMode

Definition at line 93 of file brainrenderer.h.

Constructor & Destructor Documentation

◆ BrainRenderer()

DISP3DLIB::BrainRenderer::BrainRenderer ( )

Default Constructor

Definition at line 267 of file brainrenderer.cpp.

◆ ~BrainRenderer()

DISP3DLIB::BrainRenderer::~BrainRenderer ( )

default

Destructor

Member Function Documentation

◆ beginFrame()

void DISP3DLIB::BrainRenderer::beginFrame	(	QRhiCommandBuffer *	cb,
		QRhiResourceUpdateBatch *	updates = nullptr )

Begin the first render pass of a frame. Clears color and depth.

Parameters

[in]	cb	Command buffer to record to.
[in]	updates	Resource updates to commit before the pass, or nullptr.

Definition at line 635 of file brainrenderer.cpp.

◆ beginPreservingPass()

void DISP3DLIB::BrainRenderer::beginPreservingPass	(	QRhiCommandBuffer *	cb,
		QRhiResourceUpdateBatch *	updates = nullptr )

Begin an additional render pass that preserves previous output. Uses the internal preserving render target (m_rtPreserve).

Parameters

[in]	cb	Command buffer.
[in]	updates	Resource updates to commit before the pass, or nullptr.

Definition at line 642 of file brainrenderer.cpp.

◆ cachedMeshCount()

int DISP3DLIB::BrainRenderer::cachedMeshCount ( ) const

Returns: Number of renderables whose GPU copies the renderer currently holds.

Definition at line 601 of file brainrenderer.cpp.

◆ endPass()

void DISP3DLIB::BrainRenderer::endPass ( QRhiCommandBuffer * cb )

End any render pass (clearing or preserving).

Parameters

[in] cb Command buffer.

Definition at line 649 of file brainrenderer.cpp.

◆ ensureRenderTargets()

void DISP3DLIB::BrainRenderer::ensureRenderTargets	(	QRhi *	rhi,
		QRhiTexture *	colorTex,
		const QSize &	pixelSize )

Create the dual render-target pair for multi-pass rendering.

Both render targets share the same color texture and depth-stencil buffer but differ in their load/store flags:

m_rtClear: clears color+depth on beginPass (first pass)
m_rtPreserve: preserves previous output (passes 2+)

Qt bakes these flags into native resources at create() time, so calling setFlags() dynamically does NOT work (especially on WebGL). This is the validated pattern from test_wasm_multi_pass.

Parameters

[in]	rhi	QRhi instance.
[in]	colorTex	Color texture (owned by QRhiWidget or caller).
[in]	pixelSize	Render target dimensions.

Definition at line 535 of file brainrenderer.cpp.

◆ initialize()

void DISP3DLIB::BrainRenderer::initialize	(	QRhi *	rhi,
		QRhiRenderPassDescriptor *	rp,
		int	sampleCount )

Initialize resources (shaders, pipelines) for the given RHI and render pass. Ensures pipelines for all supported modes are created.

Parameters

[in]	rhi	Pointer to QRhi instance.
[in]	rp	Render pass descriptor.
[in]	sampleCount	MSAA sample count.

Definition at line 278 of file brainrenderer.cpp.

◆ issueDipoleDraw()

void DISP3DLIB::BrainRenderer::issueDipoleDraw	(	QRhiCommandBuffer *	cb,
		DipoleObject *	dipoles,
		int	uniformOffset )

Draw dipoles as instanced cones. Call inside a pass.

Parameters

[in]	cb	Command buffer.
[in]	dipoles	Pointer to DipoleObject.
[in]	uniformOffset	Offset returned by prepareDipoleDraw().

Definition at line 1569 of file brainrenderer.cpp.

◆ issueElectrodeDraw()

void DISP3DLIB::BrainRenderer::issueElectrodeDraw	(	QRhiCommandBuffer *	cb,
		ElectrodeObject *	electrodes,
		int	uniformOffset )

Draw electrode lead bodies and contacts, opaque and depth-tested. Call inside a pass.

Parameters

[in]	cb	Command buffer.
[in]	electrodes	Pointer to ElectrodeObject.
[in]	uniformOffset	Offset returned by prepareElectrodeDraw().

Definition at line 1538 of file brainrenderer.cpp.

◆ issueNetworkDraw()

void DISP3DLIB::BrainRenderer::issueNetworkDraw	(	QRhiCommandBuffer *	cb,
		NetworkObject *	network,
		int	uniformOffset )

Draw a connectivity network: instanced node spheres and edge cylinders. Call inside a pass.

Parameters

[in]	cb	Command buffer.
[in]	network	Pointer to NetworkObject.
[in]	uniformOffset	Offset returned by prepareNetworkDraw().

Definition at line 1577 of file brainrenderer.cpp.

◆ issuePolylineDraw()

void DISP3DLIB::BrainRenderer::issuePolylineDraw	(	QRhiCommandBuffer *	cb,
		PolylineObject *	polyline,
		int	uniformOffset )

Draw a polyline as connected segments. Call inside a pass.

Parameters

[in]	cb	Command buffer.
[in]	polyline	Pointer to PolylineObject.
[in]	uniformOffset	Offset returned by preparePolylineDraw().

Definition at line 1587 of file brainrenderer.cpp.

◆ issueSliceDraw()

void DISP3DLIB::BrainRenderer::issueSliceDraw	(	QRhiCommandBuffer *	cb,
		int	slotIndex,
		int	uniformOffset )

Draw an MRI slice prepared with prepareSliceDraw(). Call inside a pass.

Parameters

[in]	cb	Command buffer (must be inside a render pass).
[in]	slotIndex	Slot index matching the prepareSliceDraw call.
[in]	uniformOffset	Offset returned by prepareSliceDraw().

Definition at line 1364 of file brainrenderer.cpp.

◆ issueSurfaceDraw()

void DISP3DLIB::BrainRenderer::issueSurfaceDraw	(	QRhiCommandBuffer *	cb,
		BrainSurface *	surface,
		ShaderMode	mode,
		int	uniformOffset )

Draw a surface with the uniforms from prepareSurfaceDraw(). Call inside a pass.

Parameters

[in]	cb	Command buffer.
[in]	surface	Pointer to surface to draw.
[in]	mode	Shader mode.
[in]	uniformOffset	Offset returned by prepareSurfaceDraw().

Definition at line 1435 of file brainrenderer.cpp.

◆ issueVideoOverlayDraw()

void DISP3DLIB::BrainRenderer::issueVideoOverlayDraw	(	QRhiCommandBuffer *	cb,
		DISP3DLIB::VideoOverlay *	overlay,
		BrainSurface *	surface,
		int	uniformOffset )

Draw a video overlay prepared with prepareVideoOverlayDraw(). Call inside a pass.

Parameters

[in]	cb	Command buffer.
[in]	overlay	Pointer to VideoOverlay.
[in]	surface	Same target surface as in prepareVideoOverlayDraw().
[in]	uniformOffset	Offset returned by prepareVideoOverlayDraw().

Definition at line 1113 of file brainrenderer.cpp.

◆ newFrame()

void DISP3DLIB::BrainRenderer::newFrame ( )

Start a new frame: frees all per-draw uniform slots. Call before the frame's first prepare call.

A frame is recorded in two phases. First every prepare*() call writes its uniforms and uploads into resource update batches. Then beginFrame() commits them, and the issue*() calls only bind and draw: QRhi forbids resource updates inside a render pass, and prepare calls made inside one are rejected with a warning.

The renderer owns the GPU copies of the renderables' streams. They are created on the first draw, updated when a stream's generation changes, and freed once the renderable is destroyed or has not been drawn for a while.

Definition at line 581 of file brainrenderer.cpp.

◆ prepareDipoleDraw()

int DISP3DLIB::BrainRenderer::prepareDipoleDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		DipoleObject *	dipoles )

Upload the dipoles' streams if they changed and write the uniforms of their draw.

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms.
[in]	dipoles	Pointer to DipoleObject.

Returns: Uniform buffer offset, or -1 when nothing is drawn.

Definition at line 1490 of file brainrenderer.cpp.

◆ prepareElectrodeDraw()

int DISP3DLIB::BrainRenderer::prepareElectrodeDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		ElectrodeObject *	electrodes )

Upload the electrodes' streams if they changed and write the uniforms of their draws.

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms.
[in]	electrodes	Pointer to ElectrodeObject.

Returns: Uniform buffer offset, or -1 when nothing is drawn.

Definition at line 1525 of file brainrenderer.cpp.

◆ prepareNetworkDraw()

int DISP3DLIB::BrainRenderer::prepareNetworkDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		NetworkObject *	network )

Upload the network's streams if they changed and write the uniforms of its draws.

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms.
[in]	network	Pointer to NetworkObject.

Returns: Uniform buffer offset, or -1 when nothing is drawn.

Definition at line 1501 of file brainrenderer.cpp.

◆ preparePolylineDraw()

int DISP3DLIB::BrainRenderer::preparePolylineDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		PolylineObject *	polyline )

Upload the polyline's streams if they changed and write the uniforms of its draw.

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms.
[in]	polyline	Pointer to PolylineObject.

Returns: Uniform buffer offset, or -1 when nothing is drawn.

Definition at line 1514 of file brainrenderer.cpp.

◆ prepareSlice()

void DISP3DLIB::BrainRenderer::prepareSlice	(	QRhi *	rhi,
		QRhiResourceUpdateBatch *	u,
		DISP3DLIB::SliceObject *	slice,
		int	slotIndex )

Prepare MRI slice GPU resources and upload texture data.

Must be called before a render pass starts. Creates the slice pipeline lazily on first use and uploads the slice texture.

Parameters

[in]	rhi	QRhi pointer.
[in]	u	Resource update batch owned by the caller.
[in]	slice	Pointer to SliceObject; ignored when null.
[in]	slotIndex	Slot index (0=axial, 1=coronal, 2=sagittal).

Definition at line 1146 of file brainrenderer.cpp.

◆ prepareSliceDraw()

int DISP3DLIB::BrainRenderer::prepareSliceDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		int	slotIndex )

Write the uniforms of one MRI slice draw into a resource update batch.

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms (MVP, camera position).
[in]	slotIndex	Slot index (0=axial, 1=coronal, 2=sagittal).

Returns: Uniform buffer offset for this draw, or -1 on failure.

Definition at line 1312 of file brainrenderer.cpp.

◆ prepareSurfaceDraw()

int DISP3DLIB::BrainRenderer::prepareSurfaceDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		BrainSurface *	surface )

Upload the surface's streams if they changed and write the uniforms of one surface draw.

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms (MVP, light, etc).
[in]	surface	Pointer to surface.

Returns: Uniform buffer offset for this draw, or -1 on failure.

Definition at line 1387 of file brainrenderer.cpp.

◆ prepareVideoOverlay()

void DISP3DLIB::BrainRenderer::prepareVideoOverlay	(	QRhi *	rhi,
		QRhiResourceUpdateBatch *	u,
		DISP3DLIB::VideoOverlay *	overlay )

Prepare live video overlay GPU resources and upload the latest frame.

Must be called before a render pass starts. Texture uploads require a blit encoder on Metal and must not be recorded while a render encoder is active.

Parameters

[in]	rhi	QRhi pointer.
[in]	u	Resource update batch owned by the caller.
[in]	overlay	Pointer to VideoOverlay; ignored when null/disabled.

Definition at line 659 of file brainrenderer.cpp.

◆ prepareVideoOverlayDraw()

int DISP3DLIB::BrainRenderer::prepareVideoOverlayDraw	(	QRhiResourceUpdateBatch *	u,
		const SceneData &	data,
		DISP3DLIB::VideoOverlay *	overlay,
		BrainSurface *	surface )

Write the uniforms of one video overlay draw: a camera-facing quad at the focus position, or, with a target surface, a decal projected onto that mesh. Call after prepareVideoOverlay().

Parameters

[in]	u	Resource update batch, committed before the pass.
[in]	data	Scene uniforms (MVP, camera position).
[in]	overlay	Pointer to VideoOverlay; ignored when null/disabled.
[in]	surface	Target surface mesh (typically scalp/head), or nullptr for the quad.

Returns: Uniform buffer offset for this draw, or -1 when nothing is drawn.

Definition at line 939 of file brainrenderer.cpp.

◆ rtClear()

QRhiRenderTarget * DISP3DLIB::BrainRenderer::rtClear ( ) const

Returns: The clearing render target (pass 1).

Definition at line 569 of file brainrenderer.cpp.

◆ rtPreserve()

QRhiRenderTarget * DISP3DLIB::BrainRenderer::rtPreserve ( ) const

Returns: The preserving render target (passes 2+).

Definition at line 574 of file brainrenderer.cpp.

Member Data Documentation

◆ Anatomical

ShaderMode DISP3DLIB::BrainRenderer::Anatomical = DISP3DLIB::Anatomical

staticconstexpr

Definition at line 96 of file brainrenderer.h.

◆ Dipole

ShaderMode DISP3DLIB::BrainRenderer::Dipole = DISP3DLIB::Dipole

staticconstexpr

Definition at line 97 of file brainrenderer.h.

◆ Holographic

ShaderMode DISP3DLIB::BrainRenderer::Holographic = DISP3DLIB::Holographic

staticconstexpr

Definition at line 95 of file brainrenderer.h.

◆ ShowNormals

ShaderMode DISP3DLIB::BrainRenderer::ShowNormals = DISP3DLIB::ShowNormals

staticconstexpr

Definition at line 99 of file brainrenderer.h.

◆ Standard

ShaderMode DISP3DLIB::BrainRenderer::Standard = DISP3DLIB::Standard

staticconstexpr

Definition at line 94 of file brainrenderer.h.

◆ XRay

ShaderMode DISP3DLIB::BrainRenderer::XRay = DISP3DLIB::XRay

staticconstexpr

Definition at line 98 of file brainrenderer.h.

The documentation for this class was generated from the following files:

src/libraries/disp3D/view/brainrenderer.h
src/libraries/disp3D/view/brainrenderer.cpp

Classes

Public Types

Public Member Functions

Static Public Attributes

Detailed Description

Member Typedef Documentation

◆ ShaderMode

Constructor & Destructor Documentation

◆ BrainRenderer()

◆ ~BrainRenderer()

Member Function Documentation

◆ beginFrame()

◆ beginPreservingPass()

◆ cachedMeshCount()

◆ endPass()

◆ ensureRenderTargets()

◆ initialize()

◆ issueDipoleDraw()

◆ issueElectrodeDraw()

◆ issueNetworkDraw()

◆ issuePolylineDraw()

◆ issueSliceDraw()

◆ issueSurfaceDraw()

◆ issueVideoOverlayDraw()

◆ newFrame()

◆ prepareDipoleDraw()

◆ prepareElectrodeDraw()

◆ prepareNetworkDraw()

◆ preparePolylineDraw()

◆ prepareSlice()

◆ prepareSliceDraw()

◆ prepareSurfaceDraw()

◆ prepareVideoOverlay()

◆ prepareVideoOverlayDraw()

◆ rtClear()

◆ rtPreserve()

Member Data Documentation

◆ Anatomical

◆ Dipole

◆ Holographic

◆ ShowNormals

◆ Standard

◆ XRay
